YAGEO CORPORATION
SMD INDUCTOR / BEADS
Wound Chip Inductors
NL Series
applICaTIOns
Microtelevisions, liquid crystal televisions, video cameras, portable VCRs, car radios, car stereos,
thin tape radios, television tuners, mobile telephones, radio and other electronic devices.
OuTlIne
These revolutionary, highly reliable wound chip inductors for automatic mounting have been devel-
oped in response to the trend toward high density in electronic equipment.
pROduCT IdenTIFICaTIOn
NL
-
-
Internal No.
Tolerance
Inductance
Packaging Style (*)
Dimensions (A, B, C)
Product Symbol
FeaTuRes
Very strong solderability by reflow soldering, soldering iron or wave soldering.
Highly accurate dimensions can be mounted automatically.
Terminals are highly resistant to pull forces.
Highly resistant to mechanical shocks and pressure.
Highly reliable in environments of sudden temperature change and humidity.
Superior Q characteristics and the broadest L selections among peers
* T : Tape and Reel ; B : Bulk
Tolerance : J = ±5% ; K= ±10%
YAGEO will start to release lead-free that meet
SONY SS-00259's criteria, and Internal No. well
be changed to "N" as identification.
Ex. NL322522T-R10K-N
ReCOMMended paTTeRn
Dimensions : mm
INDUCTOR
B
B
PATTERN
shapes and dIMensIOns
Dimensions : mm
B
C
C
E
D
A
A
TYpe
NL322522
NL453232
NL565050
a
1.6
3.0
4.0
B
1.2
1.5
2.0
C
2.0
2.8
4.5
TYpe
NL322522
NL453232
NL565050
a
3.2 ± 0.2
4.5 ± 0.3
5.6 ± 0.3
B
2.5 ± 0.2
3.2 ± 0.3
5.0 ± 0.3
C
2.2 ± 0.2
3.2 ± 0.3
5.0 ± 0.3
d
1.2 ± 0.4
1.4 ± 0.4
1.8 ± 0.3
e
0.6 ± 0.1
0.9 ± 0.2
1.3 ± 0.2
78
eleCTRICal ChaRaCTeRIsTICs
nl322522 seRIes
paRT nO.
InduCTanCe
(µH)
NL322522T-4R7K-S
NL322522T-5R6K-S
NL322522T-6R8K-S
NL322522T-8R2K-S
NL322522T-100K-S
NL322522T-120K-S
NL322522T-150K-S
NL322522T-180K-S
NL322522T-220K-S
NL322522T-270K-S
NL322522T-330K-S
NL322522T-390K-S
NL322522T-470K-S
NL322522T-560K-S
NL322522T-680K-S
NL322522T-820K-S
NL322522T-101K-S
NL322522T-121K-S
NL322522T-151K-S
NL322522T-181K-S
NL322522T-221K-S
NL322522T-271K-S
NL322522T-331K-S
• S R F : HP4291A
• RDC : CH502BC / HP4338B
• IDC : HP4284A + HP42841A
4.70
5.60
6.80
8.20
10
12
15
18
22
27
33
39
47
56
68
82
100
120
150
180
220
270
330
TOleRanCe
(±%)
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
q
Min.
30
30
30
30
30
30
30
30
30
30
30
30
30
30
30
30
20
20
20
20
20
20
20
TesT FRequenCY
(MHz)
7.960
7.960
7.960
7.960
2.520
2.520
2.520
2.520
2.520
2.520
2.520
2.520
2.520
2.520
2.520
2.520
0.796
0.796
0.796
0.796
0.796
0.796
0.796
sRF
(MHz) Min.
32
30
28
25
23
20
19
17
16
14
13
12
10
9
9
8
7
7
6
6
5
6
5
dC ResIsTanCe
(Ω) Max.
1.50
1.60
1.80
2.00
2.10
2.50
2.80
3.30
3.70
5.00
5.60
6.40
7.00
8.00
9.00
10.0
10.0
11.0
15.0
17.0
21.0
22.0
34.0
IdC
(mA) Max.
220
200
180
170
150
140
130
120
110
80
70
65
60
55
50
45
40
70
65
60
50
45
40
• L/Q : HP4287A(0.10µ H MAX)
• L /Q : HP4285A + HP16034E (0.12µ H MIN)
• IDC: ∆ L /L : -10%
79
eleCTRICal ChaRaCTeRIsTICs : lead-FRee & ROhs COMplIanCe
paRT nO.
NL322522T-010
NL322522T-012
NL322522T-015
NL322522T-018
NL322522T-022
NL322522T-027
NL322522T-033
NL322522T-039
NL322522T-047
NL322522T-056
NL322522T-068
NL322522T-082
NL322522T-R10
NL322522T-R12
NL322522T-R15
NL322522T-R18
NL322522T-R22
NL322522T-R27
NL322522T-R33
NL322522T-R39
NL322522T-R47
NL322522T-R56
NL322522T-R68
NL322522T-R82
NL322522T-1R0
NL322522T-1R2
NL322522T-1R5
NL322522T-1R8
NL322522T-2R2
NL322522T-2R7
NL322522T-3R3
NL322522T-3R9
NL322522T-4R7
NL322522T-5R6
NL322522T-6R8
NL322522T-8R2
NL322522T-100
NL322522T-120
NL322522T-150
NL322522T-180
NL322522T-220
NL322522T-270
NL322522T-330
NL322522T-390
NL322522T-470
NL322522T-560
NL322522T-680
NL322522T-820
NL322522T-101
NL322522T-121
NL322522T-151
NL322522T-181
NL322522T-221
NL322522T-271
NL322522T-331
-N
-N
-N
-N
-N
-N
-N
-N
-N
-N
-N
-N
-N
-N
-N
-N
-N
-N
-N
-N
-N
-N
-N
-N
-N
-N
-N
-N
-N
-N
-N
-N
-N
-N
-N
-N
-N
-N
-N
-N
-N
-N
-N
-N
-N
-N
-N
-N
-N
-N
-N
-N
-N
-N
-N
InduCTanCe TesT FReq
(µH)
(MHz)
0.01
0.012
0.015
0.018
0.022
0.027
0.033
0.039
0.047
0.056
0.068
0.082
0.1
0.12
0.15
0.18
0.22
0.27
0.33
0.39
0.47
0.56
0.68
0.82
1
1.2
1.5
1.8
2.2
2.7
3.3
3.9
4.7
5.6
6.8
8.2
10
12
15
18
22
27
33
39
47
56
68
82
100
120
150
180
220
270
330
100
100
100
100
100
100
100
100
100
100
100
100
100
25.2
25.2
25.2
25.2
25.2
25.2
25.2
25.2
25.2
25.2
25.2
7.96
7.96
7.96
7.96
7.96
7.96
7.96
7.96
7.96
7.96
7.96
7.96
2.52
2.52
2.52
2.52
2.52
2.52
2.52
2.52
2.52
2.52
2.52
2.52
0.796
0.796
0.796
0.796
0.796
0.796
0.796
q
Min.
15
17
19
21
23
23
25
25
26
26
27
27
28
30
30
30
30
30
30
30
30
30
30
30
30
30
30
30
30
30
30
30
30
30
30
30
30
30
30
30
30
30
30
30
30
30
30
30
20
20
20
20
20
20
20
sRF
(MHz) Min.
2500
2300
2100
1900
1700
1500
1400
1300
1200
1100
1000
900
700
500
450
400
350
320
300
250
220
180
160
140
90
85
70
60
50
45
40
37
32
30
28
25
23
20
19
17
16
14
13
12
10
9
9
8
7
7
6
6
5
6
5
RdC
(Ω) Max.
0.13
0.14
0.16
0.18
0.2
0.22
0.24
0.27
0.3
0.33
0.36
0.4
0.44
0.22
0.25
0.28
0.32
0.36
0.4
0.45
0.5
0.55
0.6
0.65
0.7
0.75
0.85
0.9
1
1.1
1.2
1.3
1.5
1.6
1.8
2
2.1
2.5
2.8
3.3
3.7
5
5.6
6.4
7
8
9
10
10
11
15
17
21
22
34
IdC
(mA) Max.
450
450
450
450
450
450
450
450
450
450
450
450
450
450
450
450
450
450
450
450
450
450
450
450
400
390
370
350
320
290
260
250
220
200
180
170
150
140
130
120
110
80
70
65
60
55
50
45
40
70
65
60
50
45
40
TOleRanCe
(±%)
10
10
10
10
10
10
10
10
10
10
10
10
5,10,20
5,10,20
5,10,20
5,10,20
5,10,20
5,10,20
5,10,20
5,10,20
5,10,20
5,10,20
5,10,20
5,10,20
5,10
5,10
5,10
5,10
5,10
5,10
5,10
5,10
5,10
5,10
5,10
5,10
5,10
5,10
5,10
5,10
5,10
5,10
5,10
5,10
5,10
5,10
5,10
5,10
5,10
5,10
5,10
5,10
5,10
5,10
5,10
NOTE:
-tolerance J= ±5% / K= ±10% / M=± 20%
1.Operating temperature range -25°C~85°C
2.IDC:Applied the current to coils,the inductance shall be less than 10% initial value.
3.L , Q (010~R10)Test OSC@502mV / L , Q(R10~331)Test OSC@1V
"-N" FOR COMPLETELY LEAD FREE TYPE(INCLUDING FERRITE BODY & SOLDER)
