CINTA
Connector
P R O D U C T
S P E C I F I C A T I O N
®
100PNR-CR
Type N male right angle, solder, crimp, for CNT-100 cable
Interface type
Interface mates to
Electrical
Recommended maximum operating frequency, GHz
Peak power, max, kW
Average power, max, kW @ 900 MHz
dc test maximum voltage
RF operating voltage, max, VRMS
RF high potential, max, VRMS
Inner contact resistance, milliohms (Outer)
Insulation resistance, min, Megaohms
Connector impedance, Ohms
Cable impedance, Ohms
Insertion loss, max, dB
Connector Return Loss, dB
Start
Stop
0.00 -
3.00 GHz
3.00 -
6.00 GHz
Mechanical
Inner attachment method
Outer attachment method
Connector weight, g
Customer Support Center:
From North America:
1-800-255-1479
International:
+1-708-873-2307
www.andrew.com
Return Loss
32.00
20.00
N Male
N Female
6.00
0.60
0.05
500.00
173.00
1,500.00
1.00 (0.25)
5,000.00
50.00
50.00
0.05
frequency(GHz)
Cable Limited
Cable Limited
Cable Limited
Cable Limited
Cable Limited
Connector Limited
Solder
Crimp
25.00
This Specification Sheet is for reference only and is subject to change without notice.
Copyright © 2007 Andrew Corporation
10 January 2007
1
CINTA
Connector
P R O D U C T
S P E C I F I C A T I O N
®
100PNR-CR
Type N male right angle, solder, crimp, for CNT-100 cable
Pressurizable
Coupling nut retention force, N (lb)
Method
Minimum coupling nut torque, N-m (lb-in)
Environmental
Operating temperature range, °C
Storage temperature range, °C
Components
Interface {Trimetal Plate}
Inner Contact {Gold Plate}
Body {Trimetal Plate}
Insulator
Crimp Ferrule {Trimetal Plate}
Cap
Hex Coupling Nut
Spring Retaining Ring
Type N Gasket
No
450.00 (101.16)
Hex Nut
1.00 (8.85)
-40.00°C - 85.00°C
-40.00°C - 85.00°C
Material:
Material:
Material:
Material:
Material:
Material:
Material:
Material:
Material:
Brass
Brass
Brass
PTFE
Brass
Brass
Brass
Phosphor Bronze
Silicone Rubber
Exterior finish: Trimetal Plate
Exterior finish: Gold Plate
Exterior finish: Trimetal Plate
Exterior finish: Trimetal Plate
Exterior finish: Trimetal Plate
Exterior finish: Trimetal Plate
Customer Support Center:
From North America:
1-800-255-1479
International:
+1-708-873-2307
www.andrew.com
This Specification Sheet is for reference only and is subject to change without notice.
Copyright © 2007 Andrew Corporation
10 January 2007
