Pin Pre-amplifier with AGC for 3.3V Fiber Optic Applications
to 622 Mbps
Data Sheet
02009-DSH-001-C 6/03
Information provided in this Data Sheet is subject to change without notice.
Mindspeed Technologies™, Inc, Proprietary and Confidential
M02009
Pin Pre-amplifier with AGC for 3.3V Fiber Optic Applications to 622 Mbps
T
ABLE OF
C
ONTENTS
Features ...........................................................................................................................................................3
Table 1 Ordering Information ............................................................................................................................3
Top Level Diagram ...........................................................................................................................................3
Table 2 Pad Description ...................................................................................................................................4
Table 3 Absolute Maximum Ratings..................................................................................................................4
Table 5 DC Characteristics ...............................................................................................................................4
Table 6 AC Characteristics ...............................................................................................................................5
TIA ....................................................................................................................................................................6
Bare Die Information .........................................................................................................................................10
Bare Die Layout ................................................................................................................................................10
X Y Coordinates ...............................................................................................................................................10
Contact Information ..........................................................................................................................................12
02009-DSH-001-C 6/03
Information provided in this Data Sheet is subject to change without notice.
Mindspeed Technologies™, Proprietary and Confidential
Page 2 of 10
M02009
Pin Pre-amplifier with AGC for 3.3V Fiber Optic Applications to 622 Mbps
F
EATURES
Low cost IC fabricated in CMOS.
Receiver sensitivity better than -32 dBm @ 622
Mbps.
Minimum 340 MHz bandwidth and multi-pole roll off
allows a wide range of operation up to 622 Mbps.
Typical differential transimpedance at low signal
levels of 40 KΩ.
AGC gives continuous operation to +3 dBm
> 33 dB power-supply noise rejection.
Typical 130 mW power comsumption at 3.3V supply.
Monitor output gives linear indication of received
optical power.
Differential output.
D
ESCRIPTION
The MC2009 is a low-noise, transimpedance amplifier
with AGC, manufactured in low-cost CMOS. Its wide
dynamic range, differential output and high PIN bias make
it well suited for telecommunications, especially OC-12/
STM-4. However, the MC2009 is intended to meet the
needs of both Telecom and Datacom users.
The MC2009 is available in die form. For optimum system
performance die should be mounted in close proximity
with the photodetector.
The MC2009 is designed to be used with the Mindspeed
MC2044C Postamplifier IC. When combined with a
photodiode, the chip set forms a high performance, low
cost 3.3V receiver.
T
ABLE
1
A
PPLICATIONS
Part
M2009DIE
M2009DIEW
O
RDERING
I
NFORMATION
Pin Package
Waffle Pack
Expanded whole wafer on a ring
ATM/SDH/SONET
T
OP
L
EVEL
D
IAGRAM
Fig. 1
V
CC
MON
D
OUT
Gnd
Gnd
PIN
K
PIN
A
V
CC
AGC
D
OUT
Gnd
Gnd
02009-DSH-001-C 6/03
Information provided in this Data Sheet is subject to change without notice.
Mindspeed Technologies™, Proprietary and Confidential
Page 3 of 12
M02009
Pin Pre-amplifier with AGC for 3.3V Fiber Optic Applications to 622 Mbps
T
ABLE
2
Name
GND
D
OUT
V
CC
PINK
PINA
D
OUT
MON
AGC
Function
Ground. Connect to the most negative supply. All pads should be connected
Non-Inverted Data Output. Differential output with D
OUT
Power. Connect to most positive supply. Either or both pads may be used.
Photodiode Cathode connection. Connect photodiode between PINK and PINA. Connect de-coupling cap
between PINK and GND (470pF typ).
Photodiode Anode connection. Connect photodiode between PINA and PINK.
Inverted Data Output. Differential output with D
OUT
Optical input power monitor. Current sink output, current flow into pin.
AGC disable/monitor (test mode enable)
P
AD
D
ESCRIPTION
T
ABLE
3
Symbol
V
CC
T
A
T
J
T
STG
Power supply (V
CC
-GND)
Operating ambient
Junction temperature (die)
Storage temperature
Parameter
A
BSOLUTE
M
AXIMUM
R
ATINGS
Rating
4.5
-40 to +85
+150
-65 to +150
Units
V
°C
°C
°C
T
ABLE
4
Symbol
V
CC
T
J
T
A
Power supply (V
CC
-GND)
Junction temperature (die)
Operating ambient temperature
Parameter
R
ECOMMENDED
O
PERATING
C
ONDITIONS
Rating
3.3 ± 10%
-40 to +100
-40 to +85
1
Units
V
°C
°C
T
ABLE
5
Symbol
V
B
V
CM
I
CC
Parameter
PIN Photodiode bias voltage (PINK - PINA)
Common mode output voltage
Supply current (no loads)
Min.
1.5
(V
CC
/ 2) - 0.1V
--
Typ.
1.6
V
CC
/ 2
30
DC C
HARACTERISTICS
Max.
1.8
(V
CC
/ 2) + 0.1V
45
Units
V
V
mA
Notes:
1) Die are tested and guaranteed at 25 °C, and are designed and characterized to operate over the whole temperature range.
02009-DSH-001-C 6/03
Information provided in this Data Sheet is subject to change without notice.
Mindspeed Technologies™, Proprietary and Confidential
Page 4 of 12
M02009
Pin Pre-amplifier with AGC for 3.3V Fiber Optic Applications to 622 Mbps
T
ABLE
6
Symbol
R
OUT
Parameter
Output impedance (single ended)
3
Input referred Noise Current
1,2,8
< 4 pA
Hz
Optical Sensitivity
1,2,8
Input Overload Current
Optical Saturation
2,8
Small signal Transimpedance
3, 4
Single ended
Diffferential
Differential output voltage
3
Bandwidth to -3dB point (optical)
5, 7,8
Pulse width distortion
8
Pulse overshoot
8
AGC Time constant
6
AGC Overshoot
8
Power Supply Rejection Ratio (<4 MHz)
8
Jitter
8
Lower frequency cutoff (-3 dB corner)
8
30
50
0
-
-
-
340
-
-
-
-
33
-31
Min.
-
AC C
HARACTERISTICS
Typ.
50
70
-32
3
+3
20
40
600
415
-
-
32
-
-
-
-
-
-
6
20
-
12
-
200
Max.
-
100
-33
Units
Ω
nA
RMS
dBm
mA
pp
dBm
ΚΩ
mV
MHz
%
%
us
%
dB
ps, p-p
KHz
I
NOISE
PIN(mean), min
I
max
PIN(mean), max
G
V
D
BW
T
PWD
OS
PULSE
T
AGC
O
SAGC
PSSR
Jitter
LF cutoff
Notes:
1. Measured with input capacitance, C
IN
= 0.7 pF
2. Assuming photodiode responsivity of 0.9 A/W, extinction ratio of 10 dB and BER of 10
-10
BW=415 MHz
3. The 2009 is designed to drive a load >500Ω. Measurements are taken into >500Ω
4. Measured at 1 MHz, 10 uA
5. Multi-pole roll off, measured at -30 dBm
6. AGC time constant can be increased by adding a capacitor from AGC pad to ground
7. Over Vcc = Vcc ±5%, temperature -40 - +85 °C
8. Guaranteed by design and characterization.
02009-DSH-001-C 6/03
Information provided in this Data Sheet is subject to change without notice.
Mindspeed Technologies™, Proprietary and Confidential
