REC30-2405SRWZ/H Overview

Analog Circuit

REC30-2405SRWZ/H Parametric

Parameter NameAttribute value
Is it lead-free?Lead free
package instruction,
Reach Compliance Codecompliant
Base Number Matches1
Features
Regulated
Converters
30W Package (50.8x11.90x40.6mm)
1.6kVDC Isolation
4:1 Wide Input Range
Regulated Output
UL94V-0 Package Material
Continuous Short Circuit Protection
Vout Trim and ON/OFF Control Function
Efficiency to 87%
ECONOLINE
DC/DC-Converter
REC30-
S_DRWZ
/H Series
30 Watt
Single
&
Dual Output
Selection Guide
Part
Number
Input
Voltage
(VDC)
REC30-xx2.5SRWZ/H
REC30-xx3.3SRWZ/H
REC30-xx05SRWZ/H
REC30-xx12SRWZ/H
REC30-xx15SRWZ/H
REC30-xx24SRWZ/H
REC30-xx05DRWZ/H
REC30-xx12DRWZ/H
REC30-xx15DRWZ/H
4:1
xx = 10-40Vin = 24
xx = 18-75Vin = 48
10-40, 18-75
10-40, 18-75
10-40, 18-75
10-40, 18-75
10-40, 18-75
10-40, 18-75
10-40, 18-75
10-40, 18-75
10-40, 18-75
Output
Voltage
(VDC)
2.5
3.3
5
12
15
24
±5
±12
±15
Output
Current
(mA)
6000
6000
6000
2500
2000
1250
±3000
±1250
±1000
Efficiency
24/48
(%)
80/81
83/85
85/87
83/84
83/84
84/84
81/82
83/84
83/83
* add suffix "CTRL" for optional Remote ON/OFF-Control
Designed to meet EN-60950-1
UL-60950-1 Pending
Specifications
(Core Operating Area)
Input Voltage Range
Input Filter
Output Voltage Accuracy
Line Voltage Regulation
Load Voltage Regulation (10% to 100% full load )
Trim
Ripple
Noise
Operating Frequency
Over Power Protection
Over Voltage Protection
Short Circuit Protection
Remote On/Off
Remote Off input current
Remote Pin drive current
Efficiency at Full Load
Isolation Voltage
Rated Working Voltage
Isolation Capacitance
Isolation Resistance
DC-DC ON
DC-DC OFF
Nominal Vin
Vr=0V
(tested for 1 second)
(long term isolation)
2.5,3.3,5V
All Others
2.5,3.3,5V
All Others
4:1
π
type
±2% max.
±0.5% max.
±1% max.
±10%
±100mV max.
±1% max.
±100mV max.
±1% max.
250kHz typ.
Works over 120% of rating and recovers automatically
Zener diode clamp
Hiccup, auto-recovery
Open or 2.2V>Vr>5V
Short to 0V or 0V>Vr>2.2V
5mA max.
-1.3mA max.
see table
1600VDC min.
see Application Notes
1000pF
100 MΩ min.
Continued on next page.
Derating-Graph
(Ambient Temperature)
120
100
Output Power (%)
80 85
40
Safe Operating Area
All Others
60
20
0
±5V
-25
0
30 40
50
70
100
Operating Temperature (°C)
www.recom-international.com
December-2006
1
