RN2410(TE85R2) datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Discrete semiconductor> The transistor> RN2410(TE85R2)

RN2410(TE85R2): DescriptionTRANSISTOR 100 mA, 50 V, PNP, Si, SMALL SIGNAL TRANSISTOR, 2-3F1A, 3 PIN, BIP General Purpose Small Signal; CategoryDiscrete semiconductor The transistor; File Size323KB，5 Pages; ManufacturerToshiba Semiconductor; Websitehttp://toshiba-semicon-storage.com/

Download Datasheet Parametric Compare View All

RN2410(TE85R2) Overview

TRANSISTOR 100 mA, 50 V, PNP, Si, SMALL SIGNAL TRANSISTOR, 2-3F1A, 3 PIN, BIP General Purpose Small Signal

RN2410(TE85R2) Parametric

Parameter Name	Attribute value
package instruction	SMALL OUTLINE, R-PDSO-G3
Contacts	3
Reach Compliance Code	unknown
ECCN code	EAR99
Other features	BUILT-IN BIAS RESISTOR
Maximum collector current (IC)	0.1 A
Collector-emitter maximum voltage	50 V
Configuration	SINGLE WITH BUILT-IN RESISTOR
Minimum DC current gain (hFE)	120
JESD-30 code	R-PDSO-G3
Number of components	1
Number of terminals	3
Package body material	PLASTIC/EPOXY
Package shape	RECTANGULAR
Package form	SMALL OUTLINE
Polarity/channel type	PNP
Certification status	Not Qualified
surface mount	YES
Terminal form	GULL WING
Terminal location	DUAL
transistor applications	SWITCHING
Transistor component materials	SILICON
Nominal transition frequency (fT)	200 MHz
Base Number Matches	1

Preview

Download Datasheet

View All

RN2410,RN2411

TOSHIBA Transistor Silicon PNP Epitaxial Type (PCT Process)

RN2410, RN2411

Switching, Inverter Circuit, Interface Circuit

And Driver Circuit Applications

With built-in bias resistors

Simplified circuit design

Reduce a quantity of parts and manufacturing process

Complementary to RN1410, RN1411

Unit: mm

Equivalent Circuit

Absolute Maximum Ratings

(Ta = 25°C)

Characterisstic

Collector-base voltage

Collector-emitter voltage

Emitter-base voltage

Collector current

Collector power dissipation

Junction temperature

Storage temperature range

Symbol

CBO

CEO

EBO

stg

Rating

−50

−5

−100

200

150

−55~150

Unit

°C

JEDEC

TO-236MOD

EIAJ

SC-59

TOSHIBA

2-3F1A

Weight: 0.012g

Electrical Characteristics

(Ta

25°C)

Characteristic

Collector cut-off current

Emitter cut-off current

DC current gain

Collector-emitter saturation voltage

Translation frequency

Collector output capacitance

Input resistor

RN2410

RN2411

Symbol

CBO

EBO

CE (sat)

Test

Circuit

―

Test Condition

−50

V, I

= 0

−5

V, I

= 0

−5

V, I

−1

−5

mA, I

−0.25

−10

V, I

−5

−10

V, I

= 0, f = 1 MHz

―

Min

―

120

―

3.29

Typ.

―

−0.1

200

4.7

Max

−100

400

−0.3

―

6.11

Unit

―

MHz

kΩ

2006-03-14
