MPS-080917P-02

864 to 899 MHz Linear Amplifier

Preliminary Data Sheet

Features:

S -0

809

1.1 dB NF

+44 dBm IP3

14.5 dB Gain

17P

-02

+28 dBm P1dB

Single Positive Bias

Leadless Surface Mount Package

The MPS-080917P-02

is a low cost high linearity modular amplifier designed to meet the

ultra-linear transmitter driver requirements for commercial 2G, 2.5G, 3G, GSM, TDMA,

EDGE, UMTS, WCDMA, CDMA2000, and TD-SCDMA applications. Key advantages are

low intermodulation performance for multi-carrier and CDMA systems and exceptionally

low input/output return loss for ease of integration.

Electrical Specifications

@ 25°C, Vdd = 7.5 V, Zo = 50 ohms

P1dB @ 25C

SYMBOL PARAMETERS

Freq.

SSG

P1 dB

IP3

VSWR

GOF

GOT

Idd

Frequency Range

Small Signal Gain

Pout at 1 dB Comp Point

Third-Order Intercept

Noise Figure

VSWR (Input/Output)

Gain Var. over Frequency

Gain Var. over Temp

DC Current

Min

864

13.0

Typical

14.5

+28.0

44.0

1.1

2.0:1

± 0.2

-0.015

330

Max

899

Unit

MHz

P1dB (dBm)

23.8

23.6

23.4

23.2

22.8

22.6

22.4

22.2

dBm

1.5

± 0.5

dB/°C

800

810

820

830

840

850

400

Freq. (MHz)

IP3 @ 25C

800

825

850

875

900

Absolute Maximum Ratings

Maximum Bias Voltage

Maximum Continuous RF Input Power

Maximum Peak Input Power

Maximum Case Operating Temperature

Maximum Storage Temperature

7.0 V

+25 dBm

+27 dBm

+85 °C

- 65 to + 150 °C

IP3 (dBm)

Freq. (MHz)

MicroWave Technology, Inc. an IXYS Company, 4268 Solar Way, Fremont, CA 94538

510-651-6700

FAX

510-651-2208

info@mwtinc.com
