KBPC2500IP ... KBPC2510IP
KBPC2500IP ... KBPC2510IP
Silicon-Bridge-Rectifiers
Silizium-Brückengleichrichter
Version 2007-11-05
28.5
±0.2
10
±0.2
Nominal current
Nennstrom
Alternating input voltage
Eingangswechselspannung
Plastic case – Plastikgehäuse
Weight approx. – Gewicht ca.
25 A
35...700 V
28.5 x 28.5 x 10 [mm]
17 g
+
~
~
Type
Ø 5.2
5
5
5
17
=
1.2
=
2.0
±0.5
Compound has classification UL94V-0
Vergussmasse nach UL94V-0 klassifiziert
Standard packaging bulk
Standard Lieferform lose im Karton
Dimensions - Maße [mm]
Recognized Product – Underwriters Laboratories Inc.® File E175067
Anerkanntes Produkt – Underwriters Laboratories Inc.® Nr. E175067
Maximum ratings
Type
Typ
KBPC2500IP
KBPC2501IP
KBPC2502IP
KBPC2504IP
KBPC2506IP
KBPC2508IP
KBPC2510IP
Max. alternating input voltage
Max. Eingangswechselspannung
V
VRMS
[V]
35
70
140
280
420
560
700
Grenzwerte
Repetitive peak reverse voltage
Periodische Spitzensperrspannung
V
RRM
[V]
1
)
50
100
200
400
600
800
1000
Repetitive peak forward current
Periodischer Spitzenstrom
Peak forward surge current 50 Hz half sine-wave
Stoßstrom für eine 50 Hz Sinus-Halbwelle
Peak forward surge current 60 Hz half sine-wave
Stoßstrom für eine 60 Hz Sinus-Halbwelle
Rating for fusing, t < 10 ms
Grenzlastintegral, t < 10 ms
Operating junction temperature – Sperrschichttemperatur
Storage temperature – Lagerungstemperatur
f > 15 Hz
T
A
= 25°C
T
A
= 25°C
T
A
= 25°C
I
FRM
I
FSM
I
FSM
i
2
t
T
j
T
S
60 A
2
)
270 A
300 A
375 A
2
s
-50...+150°C
-50...+150°C
1
2
Valid per diode – Gültig pro Diode
Valid, if the temperature of the case is kept to T
C
= 120°C – Gültig, wenn die Gehäusetemperatur auf T
C
= 120°C gehalten wird
http://www.diotec.com/
© Diotec Semiconductor AG
1
KBPC2500IP ... KBPC2510IP
Characteristics
Max. current with cooling fin 300 cm²
1
Dauergrenzstrom mit Kühlblech 300 cm²
Forward voltage – Durchlass-Spannung
Leakage current – Sperrstrom
Isolation voltage terminals to case
Isolationsspannung Anschlüsse zum Gehäuse
Thermal resistance junction to case
Wärmewiderstand Sperrschicht – Gehäuse
Admissible torque for mounting
Zulässiges Anzugsdrehmoment
10-32 UNF
M5
T
A
= 50°C
T
j
= 25°C
T
j
= 25°C
R-load
C-load
I
F
= 12.5 A
V
R
= V
RRM
I
FAV
I
FAV
V
F
I
R
V
ISO
R
thC
Kennwerte
25 A
20 A
< 1.2 V
2
)
< 25 µA
> 2500 V
< 2.0 K/W
18 ± 10% lb.in.
2 ± 10% Nm
120
[%]
100
10
2
[A]
10
T
j
= 125°C
80
T
j
= 25°C
60
1
40
10
-1
20
I
FAV
0
0
T
A
50
100
150
[°C]
1
I
F
10
-2
270a-(12a-1.2v)
0.4
V
F
0.8
1.0
1.2
1.4
[V] 1.8
Rated forward current versus ambient temperature )
Zul. Richtstrom in Abh. von der Umgebungstemp.
1
)
Forward characteristics (typical values)
Durchlasskennlinien (typische Werte)
1
2
Valid, if the temperature of the case is kept to T
C
= 120°C – Gültig, wenn die Gehäusetemperatur auf T
C
= 120°C gehalten wird
Valid per diode – Gültig pro Diode
