KBP005M THRU KBP10M
3N246 THRU 3N252
GLASS PASSIVATED SINGLE-PHASE RECTIFIER BRIDGE
Reverse Voltage -
50 to 1000 Volts
Case Style KBPM
0.600 (15.24)
0.125 x 45
o
(3.2)
0.560 (14.22)
Forward Current -
1.5 Amperes
FEATURES
0.460 (11.68)
0.420 (10.67)
0.500 (12.70)
0.460 (11.68)
60
(15.2)
MIN.
0.060
(1.52)
0.160 (4.1)
0.140 (3.6)
0.50
(12.7)
MIN.
♦
Plastic package has Underwriters Laboratory Flammability
Classification 94V-0
♦
This series is UL listed under Recognized Component Index,
file number E54214
♦
Glass passivated chip junctions
♦
High surge current capability
♦
Ideal for printed circuit board
♦
High temperature soldering guaranteed:
260°C/10 seconds at 5 lbs. (2.3kg) tension
0.034 (8.6)
0.028 (7.6)
DIA.
MECHANICAL DATA
0.105 (2.67)
0.085 (2.16)
0.200 (5.08)
0.180 (4.57)
Polarity shown on front side of case: positive lead by beveled corner
Case:
Molded plastic body over passivated junctions
Terminals:
Plated lead solderable per MIL-STD-750,
Method 2026
Polarity:
Polarity symbols marked on case
Mounting position:
Any
Weight:
0.06 ounce, 1.7 grams
Dimensions in inches and (millimeters)
MAXIMUM RATINGS AND ELECTRICAL CHARACTERISTICS
Ratings at 25°C ambient temperature unless otherwise specified.
KBP
KBP
005M
01M
SYMBOLS 3N246 3N247
KBP
02M
3N248
KBP
04M
3N249
KBP
06M
3N250
KBP
08M
3N251
KBP
10M
3N252
UNITS
* Maximum repetitive peak reverse voltage
* Maximum RMS voltage
* Maximum DC blocking voltage
Maximum average forward output rectified current at T
A
=40°C
* Peak forward surge current single half sine-wave
superimposed on rated load (JEDEC Method)
Rating for fusing (t < 8.3ms)
* Maximum instantaneous forward voltage drop
* Maximum DC reverse current
at rated DC blocking voltage per leg
Typical junction capacitance per leg
(NOTE 1)
Typical thermal resistance per leg
(NOTE 2)
* Operating junction and storage temperature range
at 1.0A per leg
1.57A per leg
T
A
=25°C
T
A
=125°C
T
J
=150°C
V
RRM
V
RMS
V
DC
I
(AV)
I
FSM
I
2
t
V
F
I
R
C
J
R
ΘJA
R
ΘJL
T
J
, T
STG
50
35
50
100
70
100
200
140
200
400
280
400
1.5
50.0
30.0
10.0
1.0
1.3
5.0
500.0
15.0
40.0
13.0
600
420
600
800
560
800
1000
700
1000
Volts
Volts
Volts
Amps
Amps
A
2
sec
Volts
µA
pF
°C/W
°C
-55 to +150
NOTES:
(1) Measured at 1.0 MHz and applied reverse voltage of 4.0 Volts
(2) Thermal resistance from junction to ambient and from junction to lead mounted on P.C.B. with, 0.47 x 0.47" (12 x12mm) copper pads
* JEDEC registered values
4/98
RATINGS AND CHARACTERISTICS CURVES KBP005M THRU KBP10M / 3N246 THRU 3N252
FIG.1 - DERATING CURVE OUTPUT
RECTIFIED CURRENT
PEAK FORWARD SURGE CURRENT,
AMPERES
BRIDGE OUTPUT
FULL WAVE RECTIFIED CURRENT,
AVERAGE AMPERES
FIG. 2 - MAXIMUM NON-REPETITIVE PEAK FORWARD
SURGE CURRENT
1.6
1.4
1.2
1.0
0.8
0.6
0.4
0.2
0
20
CAPACITIVE LOAD
Ipk/I
AV
=5.0
Ipk/I
AV
=10
Ipk/I
AV
=20
(PER LEG)
60 Hz RESISTIVE OR
INDUCTIVE LOAD
P.C.B.
MOUNTED WITH
0.47 x 0.47”
(12 x 12mm)
COPPER PADS
60
50
40
T
A
=25°C
30
20
10
1.0 CYCLE
T
J
=150°C
SINGLE SINE-WAVE
(JEDEC Method)
0
40
60
80
100
120
140 150
1
10
NUMBER OF CYCLES AT 60 H
Z
100
AMBIENT TEMPERATURE, °C
FIG. 3 - TYPICAL FORWARD CHARACTERISTICS
PER LEG
T
J
=25°C
PULSE WIDTH=300µs
1% DUTY CYCLE
FIG. 4 - TYPICAL REVERSE LEAKAGE
CHARACTERISTICS PER LEG
10
INSTANTANEOUS FORWARD CURRENT,
AMPERES
INSTANTANEOUS REVERSE CURRENT,
MICROAMPERES
20
10
T
J
=125°C
1
T
J
=100°C
1
0.1
T
J
=25°C
0.1
0.01
0
20
40
60
80
100
PERCENT OF RATED PEAK REVERSE
VOLTAGE, %
0.01
0.4
0.6
0.8
1.0
1.2
1.4
1.6
INSTANTANEOUS FORWARD VOLTAGE, VOLTS
FIG. 5 - TYPICAL JUNCTION CAPACITANCE
PER LEG
100
JUNCTION CAPACITANCE, pF
T
J
=25°C
f=1.0 MHz
Vsig=50mVp-p
10
1
0.1
1
10
100
REVERSE VOLTAGE, VOLTS
