POWER SWITCH
Power Supply Snap-in Rocker Switch, JW Series
■
Features
1. General purpose AC250V 10A make and break rocker
switches can cope with a current surge of 51A.
2. Approved standard:UL,CSA,VDE,TÜV,S,D.
3. Terminals conform to faston number 187(t0.8)product
specifications.
B Type
ROCKER SWITCH
■
Specifications
1. Rating
2. Contact Resistance
3. Insulation Resistance
4. Withstanding Voltage
5. Operating Force
: 10A 250V AC
: 20m max.
: 100M min. 500V DC
: 2000V AC for one minute
: 9.8N max.
Safety Standard Approval List
Safety Standard Approval No.
Cat. No.
Terminal Type
UL
Rating
CSA
Rating
VDE
Rating
SEMKO
Rating
DEMKO
Rating
TÜV
Rating
JWZ1120-20
JA43 (SPST)
JWZ2120-16
JA43 (DPST)
JWZ2120-33
JA43 (DPST)
Faston
( 187t0.8)
AC125V 10A AC125V 10A 10(4)A/250V
Class II
( 187t0.8) AC250V 10A AC250V 10A
Lead Wiring
Faston
10(4)A/250V
Class II
10(4)A/250V
Class II
10(4)A/250V
Class II
Terminal (t=0.8)
3.0
1.6
3.2
Lead wiring
4.75
Faston
Variation
Color
Indication
Case
01
02
03
04
05
Black
Black
Black
Art Gray
Black
Knob
Black
Black
Black
Art Gray
Orange
Hot Stamp
Without
White
White
Without
Without
Without
Without
Y
Size of Mounting Hole
Thickness of mounting board
Without
1.0 1.5
1.5 2.0
X
22.2
+0.1
0
+0.1
22.3
0
Y
14.6
+0.1
0
+0.1
14.6
0
X
16
POWER SWITCH
Rocker Switch, JW Series
JWZ1120-20
ROCKER SWITCH
17
(SPST)
Faston Type
24
18
5.8
17
11
2
4.8
6 6
22
8.5
17
14.0
JWZ2120-16
(DPST)
Faston Type
24
18
5.8
17
11
2
4.8
6 6
22
8.5
17
9
14.0
JWZ2120-33
(DPST)
Lead Wiring
24
18
2
5.8
17
11
3.2
6 6
22
8.5
17
9
14.0
Refer to the following drawing for a mounting hole.
Stamping direction
Switch operation side
■
Precaution when mounting a switch
Switch design is on the basis of mounting on a SPCC(steel)panel. If
use of soft materials such as plastic panels in place of standard
SPCC panels is planned,decision should be made after verification
of usability,particularly mounting strength for an extended period of
time,under actual application conditions.
