TLV2432AQDG4 datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Analog mixed-signal IC> Amplifier circuit> TLV2432AQDG4

TLV2432AQDG4: DescriptionTLV2432AQDG4 amplifier basic information: TLV2432AQDG4 is an OPERATIONAL AMPLIFIER. Commonly used packaging methods are GREEN, PLASTIC, MS-012AA, SOIC-8 TLV2432AQDG4 amplifier core information: The minimum operating temperature of the TLV2432AQDG4 is -40 °C and the maximum operating temperature is 125 °C. Its peak reflow temperature is 260°C and its maximum average bias current is 0.0003 µA How to simply check the efficiency of an amplifier? Looking at its slew rate, the TLV2432AQDG4 has a nominal slew rate of 0.25 V/us. When the op amp is used in a closed loop, at a certain closed-loop gain (usually 1 or 2, 10, etc.), the frequency when the TLV2432AQDG4 gain becomes 0.707 times the low-frequency gain is 500 kHz. The nominal supply voltage of the TLV2432AQDG4 is 3 V. The upper limit of its supply voltage is 12. The input offset voltage of VTLV2432AQDG4 is 2000 µV (input offset voltage: the compensation voltage added between the two input terminals to make the output terminal of the operational amplifier 0V (or close to 0V).) Related dimensions of TLV2432AQDG4: The width of TLV2432AQDG4 is: 3.9 mm and the length is 4.9 mm. TLV2432AQDG4 has 8 terminals. Its terminal position type is: DUAL. Terminal pitch is 1.27 mm. Total pins: 8 TLV2432AQDG4 amplifier additional information: Its temperature grade is: AUTOMOTIVE. And its humidity sensitivity level is: 1. TLV2432AQDG4 is not Rohs compliant. It contains lead. The corresponding JESD-30 code is: R-PDSO-G8. The corresponding JESD-609 code is: e4. The packaging code of TLV2432AQDG4 is: SOP. The materials used for TLV2432AQDG4 packaging are mostly PLASTIC/EPOXY. The package shape is RECTANGULAR. The TLV2432AQDG4 package pin formats are: SMALL OUTLINE. Its terminal forms are: GULL WING. The maximum seat height is 1.75 mm.; CategoryAnalog mixed-signal IC Amplifier circuit; File Size2MB，46 Pages; ManufacturerRochester Electronics; Websitehttps://www.rocelec.com/; Environmental Compliance; Alternative parts：TLV2432AQDG4

Download Datasheet Parametric View All

TLV2432AQDG4 Online Shopping

Suppliers	Part Number	Price	MOQ	In stock
	TLV2432AQDG4	-	-	View	Buy Now

TLV2432AQDG4 Overview

TLV2432AQDG4 amplifier basic information:

TLV2432AQDG4 is an OPERATIONAL AMPLIFIER. Commonly used packaging methods are GREEN, PLASTIC, MS-012AA, SOIC-8

TLV2432AQDG4 amplifier core information:

The minimum operating temperature of the TLV2432AQDG4 is -40 °C and the maximum operating temperature is 125 °C. Its peak reflow temperature is 260°C and its maximum average bias current is 0.0003 µA

How to simply check the efficiency of an amplifier? Looking at its slew rate, the TLV2432AQDG4 has a nominal slew rate of 0.25 V/us. When the op amp is used in a closed loop, at a certain closed-loop gain (usually 1 or 2, 10, etc.), the frequency when the TLV2432AQDG4 gain becomes 0.707 times the low-frequency gain is 500 kHz.

The nominal supply voltage of the TLV2432AQDG4 is 3 V. The upper limit of its supply voltage is 12. The input offset voltage of VTLV2432AQDG4 is 2000 µV (input offset voltage: the compensation voltage added between the two input terminals to make the output terminal of the operational amplifier 0V (or close to 0V).)

Related dimensions of TLV2432AQDG4:

The width of TLV2432AQDG4 is: 3.9 mm and the length is 4.9 mm. TLV2432AQDG4 has 8 terminals. Its terminal position type is: DUAL. Terminal pitch is 1.27 mm. Total pins: 8

TLV2432AQDG4 amplifier additional information:

Its temperature grade is: AUTOMOTIVE. And its humidity sensitivity level is: 1. TLV2432AQDG4 is not Rohs compliant. It contains lead. The corresponding JESD-30 code is: R-PDSO-G8.

The corresponding JESD-609 code is: e4. The packaging code of TLV2432AQDG4 is: SOP. The materials used for TLV2432AQDG4 packaging are mostly PLASTIC/EPOXY. The package shape is RECTANGULAR. The TLV2432AQDG4 package pin formats are: SMALL OUTLINE.

Its terminal forms are: GULL WING. The maximum seat height is 1.75 mm.

TLV2432AQDG4 Parametric

Parameter Name	Attribute value
Is it lead-free?	Contains lead
Is it Rohs certified?	conform to
Parts packaging code	SOIC
package instruction	GREEN, PLASTIC, MS-012AA, SOIC-8
Contacts	8
Reach Compliance Code	unknown
Amplifier type	OPERATIONAL AMPLIFIER
Maximum average bias current (IIB)	0.0003 µA
Nominal Common Mode Rejection Ratio	83 dB
Maximum input offset voltage	2000 µV
JESD-30 code	R-PDSO-G8
JESD-609 code	e4
length	4.9 mm
Humidity sensitivity level	1
Number of functions	2
Number of terminals	8
Maximum operating temperature	125 °C
Minimum operating temperature	-40 °C
Package body material	PLASTIC/EPOXY
encapsulated code	SOP
Package shape	RECTANGULAR
Package form	SMALL OUTLINE
Peak Reflow Temperature (Celsius)	260
Maximum seat height	1.75 mm
Nominal slew rate	0.25 V/us
Supply voltage upper limit	12 V
Nominal supply voltage (Vsup)	3 V
surface mount	YES
technology	CMOS
Temperature level	AUTOMOTIVE
Terminal surface	NICKEL PALLADIUM GOLD
Terminal form	GULL WING
Terminal pitch	1.27 mm
Terminal location	DUAL
Maximum time at peak reflow temperature	NOT SPECIFIED
Nominal Uniform Gain Bandwidth	500 kHz
width	3.9 mm
Base Number Matches	1

Preview

Download Datasheet

View All
