GS8182T19BD-300I datasheet, PDF

Datasheet> All Categories > storage> storage> GS8182T19BD-300I

GS8182T19BD-300I: DescriptionDDR SRAM, 1MX18, 0.45ns, CMOS, PBGA165, 13 X 15 MM, 1 MM PITCH, FPBGA-165; Categorystorage storage; File Size337KB，27 Pages; ManufacturerGSI Technology; Websitehttp://www.gsitechnology.com/

Download Datasheet Parametric View All

GS8182T19BD-300I Online Shopping

Suppliers	Part Number	Price	MOQ	In stock
	GS8182T19BD-300I	-	-	View	Buy Now

GS8182T19BD-300I Overview

DDR SRAM, 1MX18, 0.45ns, CMOS, PBGA165, 13 X 15 MM, 1 MM PITCH, FPBGA-165

GS8182T19BD-300I Parametric

Parameter Name	Attribute value
Is it lead-free?	Contains lead
Is it Rohs certified?	incompatible
Parts packaging code	BGA
package instruction	LBGA, BGA165,11X15,40
Contacts	165
Reach Compliance Code	not_compliant
ECCN code	3A991.B.2.B
Maximum access time	0.45 ns
Other features	PIPELINED ARCHITECTURE
Maximum clock frequency (fCLK)	300 MHz
I/O type	COMMON
JESD-30 code	R-PBGA-B165
JESD-609 code	e0
length	15 mm
memory density	18874368 bit
Memory IC Type	DDR SRAM
memory width	18
Number of functions	1
Number of terminals	165
word count	1048576 words
character code	1000000
Operating mode	SYNCHRONOUS
Maximum operating temperature	85 °C
Minimum operating temperature	-40 °C
organize	1MX18
Output characteristics	3-STATE
Package body material	PLASTIC/EPOXY
encapsulated code	LBGA
Encapsulate equivalent code	BGA165,11X15,40
Package shape	RECTANGULAR
Package form	GRID ARRAY, LOW PROFILE
Parallel/Serial	PARALLEL
Peak Reflow Temperature (Celsius)	NOT SPECIFIED
power supply	1.5/1.8,1.8 V
Certification status	Not Qualified
Maximum seat height	1.4 mm
Maximum standby current	0.165 A
Minimum standby current	1.7 V
Maximum slew rate	0.425 mA
Maximum supply voltage (Vsup)	1.9 V
Minimum supply voltage (Vsup)	1.7 V
Nominal supply voltage (Vsup)	1.8 V
surface mount	YES
technology	CMOS
Temperature level	INDUSTRIAL
Terminal surface	Tin/Lead (Sn/Pb)
Terminal form	BALL
Terminal pitch	1 mm
Terminal location	BOTTOM
Maximum time at peak reflow temperature	NOT SPECIFIED
width	13 mm
Base Number Matches	1

Preview

Download Datasheet

View All

GS8182T19/37BD-435/400/375/333/300

165-Bump BGA

Commercial Temp

Industrial Temp

Features

• 2.0 Clock Latency

• Simultaneous Read and Write SigmaDDR-II™ Interface

• Common I/O bus

• JEDEC-standard pinout and package

• Double Data Rate interface

• Byte Write (x36 and x18) function

• Burst of 2 Read and Write

• 1.8 V +100/–100 mV core power supply

• 1.5 V or 1.8 V HSTL Interface

• Pipelined read operation with self-timed Late Write

• Fully coherent read and write pipelines

• ZQ pin for programmable output drive strength

• IEEE 1149.1 JTAG-compliant Boundary Scan

• 165-bump, 13 mm x 15 mm, 1 mm bump pitch BGA package

• RoHS-compliant 165-bump BGA package available

18Mb SigmaDDR-II+

Burst of 2 SRAM

435 MHz–300 MHz

1.8 V V

1.8 V and 1.5 V I/O

just one element in a family of low power, low voltage HSTL

I/O SRAMs designed to operate at the speeds needed to

implement economical high performance networking systems.

Clocking and Addressing Schemes

The GS8182T19/37BD SigmaDDR-II+ SRAMs are

synchronous devices. They employ two input register clock

inputs, K and K. K and K are independent single-ended clock

inputs, not differential inputs to a single differential clock input

buffer.

Each internal read and write operation in a SigmaDDR-II+ B2

RAM is two times wider than the device I/O bus. An input data

bus de-multiplexer is used to accumulate incoming data before

it is simultaneously written to the memory array. An output

data multiplexer is used to capture the data produced from a

single memory array read and then route it to the appropriate

output drivers as needed. Therefore the address field of a

SigmaDDR-II+ B2 RAM is always one address pin less than

the advertised index depth (e.g., the 2M x 8 has a 1M

addressable index).

SigmaDDR-II™ Family Overview

The GS8182T19/37BD are built in compliance with the

SigmaDDR-II+ SRAM pinout standard for Common I/O

synchronous SRAMs. They are 18,874,368-bit (18Mb)

SRAMs. The GS8182T19/37BD SigmaDDR-II SRAMs are

Parameter Synopsis

-435

tKHKH

tKHQV

2.3 ns

0.45 ns

-400

2.5 ns

0.45 ns

-375

2.67 ns

0.45 ns

-333

3.0 ns

0.45 ns

-300

3.3 ns

0.45 ns

Rev: 1.03a 11/2011

1/27

Specifications cited are subject to change without notice. For latest documentation see http://www.gsitechnology.com.

GS8182T19/37BD-435/400/375/333/300

Background

Common I/O SRAMs, from a system architecture point of view, are attractive in read dominated or block transfer applications.

Therefore, the SigmaDDR-II+ SRAM interface and truth table are optimized for burst reads and writes. Common I/O SRAMs are

unpopular in applications where alternating reads and writes are needed because bus turnaround delays can cut high speed

Common I/O SRAM data bandwidth in half.

Burst Operations

Read and write operations are "burst" operations. In every case where a read or write command is accepted by the SRAM, it will

respond by issuing or accepting two beats of data, executing a data transfer on subsequent rising edges of K and K, as illustrated in

the timing diagrams. This means that it is possible to load new addresses every K clock cycle. Addresses can be loaded less often,

if intervening deselect cycles are inserted.

Deselect Cycles

Chip Deselect commands are pipelined to the same degree as read commands. This means that if a deselect command is applied to

the SRAM on the next cycle after a read command captured by the SRAM, the device will complete the two beat read data transfer

and then execute the deselect command, returning the output drivers to high-Z. A high on the LD pin prevents the RAM from

loading read or write command inputs and puts the RAM into deselect mode as soon as it completes all outstanding burst transfer

operations.

SigmaDDR-II+ B2 SRAM Read Cycles

The SRAM executes pipelined reads. The status of the Address, LD and R/W pins are evaluated on the rising edge of K. The read

command (LD low and R/W high) is clocked into the SRAM by a rising edge of K.

SigmaDDR-II+ B2 SRAM Write Cycles

The status of the Address, LD and R/W pins are evaluated on the rising edge of K. The SRAM executes "late write" data transfers.

Data in is due at the device inputs on the rising edge of K following the rising edge of K clock used to clock in the write command

(LD and R/W low) and the write address. To complete the remaining beat of the burst of two write transfer, the SRAM captures

data in on the next rising edge of K, for a total of two transfers per address load.

Rev: 1.03a 11/2011

5/27

Specifications cited are subject to change without notice. For latest documentation see http://www.gsitechnology.com.
