FEC15-24D05 datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Power/power management> The power supply circuit> FEC15-24D05

FEC15-24D05: DescriptionPower Supply Module,; CategoryPower/power management The power supply circuit; File Size94KB，2 Pages; ManufacturerPower Mate Tech; Environmental Compliance

Download Datasheet Parametric Compare View All

FEC15-24D05 Overview

Power Supply Module,

FEC15-24D05 Parametric

Parameter Name	Attribute value
Is it Rohs certified?	conform to
Reach Compliance Code	compliant
ECCN code	EAR99
Maximum input voltage	36 V
Minimum input voltage	18 V
Number of terminals	6
Maximum operating temperature	85 °C
Minimum operating temperature	-40 °C
Maximum output current	1.5 A
Nominal output voltage	5 V
Package body material	METAL
Encapsulate equivalent code	MODULE,6LEAD,0.8
Package form	MICROELECTRONIC ASSEMBLY
Certification status	Not Qualified
Temperature level	INDUSTRIAL
Base Number Matches	1

Preview

Download Datasheet

View All

•

15 WATTS OUTPUT POWER

•

2:1 WIDE INPUT VOLTAGE RANGE

•

INTERNATIONAL SAFETY STANDARD APPROVAL

•

SIX-SIDED CONTINUOUS SHIELD

•

HIGH EFFICIENCY UP TO 88%

•

STANDARD 2” X 1” X 0.4” PACKAGE

•

FIXED SWITCHING FREQUENCY

The FEC15 series offer 15 watts of output power from a 2 x 1 x 0.4 inch package. The

FEC15 series with 2:1 wide input voltage of 9-18, 18-36 and 36-75VDC. The FEC15

features 1600VDC of isolation, short-circuit and over-voltage protection, as well as six

sided shielding. A safety approval to EN60950 and UL1950. All models are particularly

suited to telecommunications, industrial, mobile telecom and test equipment applications.

UL E193009

TUV R2054607

CB JPTUV-001421

CE MARK

T E C H N I C A L S P E C I F I C AT I O N

OUTPUT SPECIFICATIONS

Output power

Voltage accuracy

Minimum load (Note 1)

Line regulation

Load regulation

LL to HL at Full Load

10% to 100% FL

Single

Dual

Single

Dual

Full load and nominal Vin

All specifications are typical at nominal input, full load and 25ºC otherwise noted

GENERAL SPECIFICATIONS

15 Watts max

± 1%

10% of FL

± 1%

± 2%

± 5%

50mVp-p

75mVp-p

I0.02%

/ ºC, max

500uS

3.9V

6.2V

15V

18V

150% typ

Efficiency

Isolation voltage

Isolation resistance

Isolation capacitance

Switching frequency

Approvals and standard

Case material

Base material

Potting material

Dimensions

Weight

MTBF (Note 4)

Single output

Dual output

See table

1600VDC, min

10 ohms, min

300pF, max

500KHz, typ

300KHz, typ

IEC60950, UL1950, EN60950

Nickel-coated copper

Non-conductive black plastic

Epoxy (UL94-V0)

2.00 X 1.00 X 0.40 Inch

(50.8 X 25.4 X 10.2 mm)

27g (0.95oz)

2.041 x 10

hrs

Cross regulation (Dual) Asymmetrical load 25% / 100% FL

Ripple and noise

Temperature coefficient

3.3V output

Over voltage protection 5V output

(Zener diode clamp)

12V output

15V output

Over load protection

% of FL at nominal input

Short circuit protection

20MHz bandwidth

Transient response recovery time 25% load step change

Hiccup, automatics recovery

ENVIRONMENTAL SPECIFICATIONS

Operating temperature range

-40ºC ~ +85ºC (with derating)

100ºC

-55ºC ~ +105ºC

Nature convection

Nature convection with heat-sink

12ºC/Watt

10ºC/Watt

Maximum case temperature

Storage temperature range

Thermal impedance (Note 5)

Thermal shock

Vibration

Relative humidity

INPUT SPECIFICATIONS

Input voltage range

Input filter

Input surge voltage

100mS max

Input reflected ripple (Note 2)

12V input

24V input

48V input

Nominal Vin and full load

12V nominal input

24V nominal input

48V nominal input

9 – 18VDC

18 – 36VDC

36 – 75VDC

Pi type

36VDC

50VDC

100VDC

20mAp-p

20mS typ

MIL-STD-810D

10~55Hz, 2G, 30minutes along X,Y and Z

5% to 95% RH

Start up time Nominal Vin and constant resistor load

Remote ON/OFF (Note 3)

(Positive logic)

DC-DC ON

DC-DC OFF

(Negative logic)

DC-DC ON

DC-DC OFF

Remote off input current

Nominal input

EMC CHARACTERISTICS

Conducted emissions

Radiated emissions

ESD

Radiated immunity

Fast transient

Surge

Conducted immunity

EN55022

EN61000-4-2

EN61000-4-3

EN61000-4-4

EN61000-4-5

EN61000-4-6

Level A

Perf. Criteria2

Open or 3.5V < Vr < 12V

Short or 0V < Vr < 1.2V

Open or 3.5V < Vr < 12V

2.5mA

FEC15-24D05 Related Products

	FEC15-24D05	FEC15-48S33	FEC15-24D15	FEC15-12S12	FEC15-12D12	FEC15-48D15	FEC15-12S33	FEC15-24D12	FEC15-48S15
Description	Power Supply Module,	Power Supply Module,	Power Supply Module,	Power Supply Module,	Power Supply Module,	Power Supply Module,	Power Supply Module,	Power Supply Module,	Power Supply Module,
Is it Rohs certified?	conform to	conform to	conform to	conform to	conform to	conform to	conform to	conform to	conform to
Reach Compliance Code	compliant	compliant	compliant	compliant	compliant	compliant	compliant	compliant	compliant
ECCN code	EAR99	EAR99	EAR99	EAR99	EAR99	EAR99	EAR99	EAR99	EAR99
Maximum input voltage	36 V	75 V	36 V	18 V	18 V	75 V	18 V	36 V	75 V
Minimum input voltage	18 V	36 V	18 V	9 V	9 V	36 V	9 V	18 V	36 V
Number of terminals	6	6	6	6	6	6	6	6	6
Maximum operating temperature	85 °C	85 °C	85 °C	85 °C	85 °C	85 °C	85 °C	85 °C	85 °C
Minimum operating temperature	-40 °C	-40 °C	-40 °C	-40 °C	-40 °C	-40 °C	-40 °C	-40 °C	-40 °C
Maximum output current	1.5 A	4 A	0.5 A	1.25 A	0.625 A	0.5 A	4 A	0.625 A	1 A
Nominal output voltage	5 V	3.3 V	15 V	12 V	12 V	15 V	3.3 V	12 V	15 V
Package body material	METAL	METAL	METAL	METAL	METAL	METAL	METAL	METAL	METAL
Encapsulate equivalent code	MODULE,6LEAD,0.8	MODULE,6LEAD,0.8	MODULE,6LEAD,0.8	MODULE,6LEAD,0.8	MODULE,6LEAD,0.8	MODULE,6LEAD,0.8	MODULE,6LEAD,0.8	MODULE,6LEAD,0.8	MODULE,6LEAD,0.8
Package form	MICROELECTRONIC ASSEMBLY	MICROELECTRONIC ASSEMBLY	MICROELECTRONIC ASSEMBLY	MICROELECTRONIC ASSEMBLY	MICROELECTRONIC ASSEMBLY	MICROELECTRONIC ASSEMBLY	MICROELECTRONIC ASSEMBLY	MICROELECTRONIC ASSEMBLY	MICROELECTRONIC ASSEMBLY
Certification status	Not Qualified	Not Qualified	Not Qualified	Not Qualified	Not Qualified	Not Qualified	Not Qualified	Not Qualified	Not Qualified
Temperature level	INDUSTRIAL	INDUSTRIAL	INDUSTRIAL	INDUSTRIAL	INDUSTRIAL	INDUSTRIAL	INDUSTRIAL	INDUSTRIAL	INDUSTRIAL
Maker	-	Power Mate Tech	Power Mate Tech	-	Power Mate Tech	Power Mate Tech	Power Mate Tech	Power Mate Tech	Power Mate Tech
