F-213
JW–13–04–T–S–550–150
(3,96 mm) .156"
FWJ, HFWJ, JW SERIES
FWJ–08–01–T–S
FWJ–05–02–T–S–RA
POWER HEADERS & BOARD STACKERS
Mates with:
FHP
TYPE
STRIP
NO. OF
PINS
LEAD
STYLE
PLATING
OPTION
S
OTHER
OPTION
SPECIFICATIONS
For complete specifications and
recommended PCB layouts see
www.samtec.com?FWJ
FWJ
= Standard
Header
FWJ
Insulator Material:
Black Glass Filled
Polyester
Terminal Material:
Phosphor Bronze
Plating:
Sn over 50µ" (1,27 µm) Ni
Operating Temp Range:
-55°C to +105°C
RoHS Compliant:
Yes
Lead–Free Solderable:
Wave only
HFWJ
= High Temp
Header
CURRENT RATING
(PER CONTACT)
FHP/HFWJ
AMBIENT
TEMP
4 PINS
2 PINS
19.5A
15.5A
20°C
17A
14A
40°C
14A
11.5A
60°C
11.2A
9.2A
75°C
–T
= Matte Tin
Leave
blank for
Through-hole
–RA
Specify LEAD STYLE
from chart below.
E
(0,51)
.020
Note:
Some lengths, styles
and options are non-standard,
non-returnable.
= Right Angle
(Style –02 &
–04 only)
A
C
F
(2,54)
.100
(1,02) .040
–VS
= Surface Mount
Requires HFWJ
(2 pins/row
minimum)
Style –05
not available.
HFWJ
For complete specifications
and recommended PCB layouts
see www.samtec.com?HFWJ
Same as FWJ except:
Insulator Material:
Natural Liquid Crystal
Polymer
01 thru 24
(1,14) .045
SQ TYP
(3,96)
.156
TYP
(6,35)
.250
B
D
LEAD
STYLE
A
B
–01
(3,18)
.125
Processing:
Lead–Free Solderable:
Yes
SMT Lead Coplanarity:
(0,20 mm) .008" max (02-16)
(0,25 mm) .010" max (17-24)
–02
–04
–05
*
No. of Positions x (3,96) .156
(11,43)
LEAD
.450 (4,45)
STYLE
C
(10,46)
LEAD
(12,70) .175
E
F
–01
.412
STYLE
D
.500
(11,73)
(8,13)
(20,55) (3,96)
–02
.462
–02
(4,45) .320 (2,54)
.809 .156
.175
.100
(19,10)
(3,81) (12,07)
(3,96) (13,56) (4,95)
–04
.752
–04
.156 .534 .195
.150 .475
–P
= Pick & Place
Pad (3 Pos. min.)
(6,98 mm) .275"
min. post height
(–VS only)
*FWJ Only
Mates with:
FHP
JW
NO. OF
PINS
04
PLATING
OPTION
S
STACK
HEIGHT
POST
HEIGHT
OTHER
OPTION
Leave
blank for
Through-hole
SPECIFICATIONS
For complete specifications and
recommended PCB layouts see
www.samtec.com?JW
Insulator Material:
Natural Liquid Crystal
Polymer
Terminal Material:
Phosphor Bronze
Plating:
Sn over 50µ" (1,27 µm) Ni
RoHS Compliant:
Yes
–T
= Matte Tin
–“XXX”
= Stacker Height
(in inches) (0,13 mm) .005" increments
Example: –250 = (6,35 mm) .250"
–VS
–“XXX”
= Surface
Mount
(2 pins/row
minimum)
= Post Height
(in inches)
02 thru 24
(3,96)
.156
TYP
POST
HEIGHT
(0,00)
.000
MIN
STACKER
HEIGHT
(29,21) 1.15
MAX WITH
(0,00) .000 POST
(8,89) .350
MIN
STACKER
HEIGHT
(27,43) 1.080
MAX WITH
(0,00) .000 POST
(6,35) .250
(3,18)
MIN
.125
(2,29)
.090
(1,14) .045 SQ
Processing:
Lead–Free Solderable:
Yes
SMT Lead Coplanarity:
(0,20 mm) .008" max (02-16)
(0,25 mm) .010" max (17-24)
–P
= Pick &
Place Pad
(3 Pos. min.)
(6,98 mm)
.275" min.
post height
(–VS only)
Note:
This Series is
non-standard, non-returnable.
