SAC8.0-E3/23: DescriptionDIODE 500 W, UNIDIRECTIONAL, SILICON, TVS DIODE, DO-204AC, PLASTIC, DO-15, 2 PIN, Transient Suppressor; CategoryDiscrete semiconductor diode; File Size51KB，3 Pages; ManufacturerVishay; Websitehttp://www.vishay.com; Environmental Compliance

Download Datasheet Parametric View All

SAC8.0-E3/23 Overview

DIODE 500 W, UNIDIRECTIONAL, SILICON, TVS DIODE, DO-204AC, PLASTIC, DO-15, 2 PIN, Transient Suppressor

SAC8.0-E3/23 Parametric

Parameter Name	Attribute value
Is it lead-free?	Lead free
Is it Rohs certified?	conform to
Parts packaging code	DO-15
package instruction	O-PALF-W2
Contacts	2
Reach Compliance Code	unknown
ECCN code	EAR99
Minimum breakdown voltage	8.89 V
Shell connection	ISOLATED
Configuration	SINGLE
Diode component materials	SILICON
Diode type	TRANS VOLTAGE SUPPRESSOR DIODE
JEDEC-95 code	DO-204AC
JESD-30 code	O-PALF-W2
JESD-609 code	e3
Maximum non-repetitive peak reverse power dissipation	500 W
Number of components	1
Number of terminals	2
Maximum operating temperature	175 °C
Minimum operating temperature	-55 °C
Package body material	PLASTIC/EPOXY
Package shape	ROUND
Package form	LONG FORM
Peak Reflow Temperature (Celsius)	NOT APPLICABLE
polarity	UNIDIRECTIONAL
Maximum power dissipation	3 W
Certification status	Not Qualified
Maximum repetitive peak reverse voltage	8 V
surface mount	NO
technology	AVALANCHE
Terminal surface	MATTE TIN
Terminal form	WIRE
Terminal location	AXIAL
Maximum time at peak reflow temperature	NOT APPLICABLE
Base Number Matches	1

Preview

Download Datasheet

View All

SAC5.0 thru SAC50

Series

Low Capacitance T

RANS

ORB

Transient Voltage Suppressor

Peak Pulse Power

500W

Stand-off Voltage

5.0 to 50V

DO-204AC (DO-15)

0.034 (0.86)

0.028 (0.71)

DIA.

Features

• Plastic package has Underwriters Laboratory

Flammability Classification 94V-0

• Glass passivated junction

• 500W peak pulse power capabililty with a

10/1000µs waveform, repetition rate (duty cycle):

0.01%

• Excellent clamping capability

• Low incremental surge resistance

• Very fast response time

• Ideal for data line applications

• High temperature soldering guaranteed:

265

C/10 seconds, 0.375” (9.5mm) lead length,

5lbs. (2.3 kg) tension

1.0 (25.4)

min.

0.300 (7.6)

0.230 (5.8)

0.140 (3.6)

0.104 (2.6)

Dia.

1.0 (25.4)

min.

Mechanical Data

Case:

JEDEC DO-204AC molded plastic body over

passivated junction

Terminals:

Solder plated axial leads, solderable

per MIL-STD-750, Method 2026

Polarity:

Color band denotes TVS cathode

Mounting Position:

Any

Weight:

0.015 ounce, 0.4 gram

Packaging codes/options:

1/4K per Bulk Box, 40K per box

4/4K per 13” Reel, 16K per box

23/2K per Ammo mag., 18K per box

Dimensions in inches and (millimeters)

Schematic

Diode

Transient

Voltage

Suppressor

Maximum Ratings and Thermal Characteristics

Parameter

Peak pulse power dissipation with a 10/1000µs waveform

Steady state power dissipation at T

= 75

C with

lead lengths or 0.375” (9.5mm)

Peak pulse power surge current with a

10/1000µs waveform (Fig. 3)

Operating junction and storage temperature range

Symbol

PPM

M(AV)

PPM

, T

STG

= 25°C unless otherwise noted)

Limit

Minimum 500

(1)

3.0

See Next Table

(1)

–55 to +175

Unit

Notes:

(1) Non-repetitive current pulse, per Fig.3 and derated above T

= 25°C per Fig. 2

7/20/00
