Kingbright
Features
l
SURFACE MOUNT TYPE.
l
I.C. COMPATIBLE.
®
3.4mm RIGHT ANGLE LED INDICATORS
L-1384QM/1I HIGH EFFICIENCY RED
L-1384QM/1SR SUPER BRIGHT RED
L-1384QM/1G GREEN
L-1384QM/1Y YELLOW
Package Dimensions
l
BLACK CASE ENHANCES CONTRAST
l
RATIO.lAVAILABLE ON TAPE AND REEL.
l
WIDE VIEWING ANGLE.
l
HIGH RELIABILITY LIFE MEASURED IN YEARS.
Description
The Green source color devices are made with Gallium
Phosphide Green Light Emitting Diode.
The High Efficiency Red source color devices are made with
Gallium Arsenide Phosphide on Gallium Phosphide Orange
Light Emitting Diode.
The Yellow source color devices are made with Gallium
Arsenide Phosphide on Gallium Phosphide Yellow Light
Emitting Diode.
The Super Bright Red source color devices are made with
Gallium Aluminum Arsenide Red Light Emitting Diode.
Notes:
1. All dimensions are in millimeters (inches).
2. Tolerance is
±
0.25(0.01") unless otherwise noted.
3. Lead spacing is measured where the lead emer-
ge package.
4. Specifications are subjected to change without notice.
Selection Guide
Part No.
Dice
Lens Type
Iv (mcd)
@ 10 mA
Min.
Max.
50
32
32
*200
Viewing
Angle
2θ1/2
60°
60°
60°
60°
L-1384QM/1ID
L-1384QM/1GD
L-1384QM/1YD
L-1384QM/1SRD
HIGH EFFICIENCY RED (GaAsP/GaP)
GREEN (GaP)
YELLOW (GaAsP/GaP)
SUPER BRIGHT RED (GaAlAs)
RED DIFFUSED
GREEN DIFFUSED
YELLOW DIFFUSED
RED DIFFUSED
12.5
8
8
*70
Notes:
1.
θ
1/2 is the angle from optical centerline where the luminous intensity is 1/2 the optical centerline value.
2. * Luminous intensity with asterisk is measured at 20mA.
3-L1384QM-1
Electrical / Optical Characteristics at T
A
=25°C
Symbol
Parameter
Device
High Efficiency Red
Green
Yellow
Super Bright Red
High Efficiency Red
Green
Yellow
Super Bright Red
High Efficiency Red
Green
Yellow
Super Bright Red
High Efficiency Red
Green
Yellow
Super Bright Red
All
Typ.
625
565
590
660
45
30
35
20
12
45
10
95
2.0
2.2
2.1
1.85
10
Max.
Units
Test Conditions
λ
peak
Peak Wavelength
nm
IF=20mA
∆λ
1/2
Spectral Line
Halfwidth
nm
IF=20mA
C
Capacitance
pF
VF=0V;f=1MHz
v
F
I
R
Forward Voltage
2.5
2.5
2.5
2.5
V
IF=20mA
Reverse Current
uA
VR = 5V
Absolute Maximum Ratings at T
A
=25°C
Parameter
Power dissipation
DC Forward Current
Peak Forward Current [1]
Reverse Voltage
Operating/Storage Temperature
Lead Soldering Temperature [2]
Notes:
1. 1/10 Duty Cycle, 0.1ms Pulse Width.
2. 4mm below package base.
High Efficiency
Red
105
30
150
5
Green
105
25
150
5
Yellow
105
30
150
5
-40 °C To +85 °C
Super Bright Red Units
100
30
150
5
mW
mA
mA
V
260 °C For 5 Seconds
3-L1384QML-2
