RE20S
Panel Cutout
9.5
Ø9.2
RE20V
9.5
Ø6.0
©
C U I Stack, Inc.,
1997
Panel Cutout/PCB Layout
7
24.5
Ø6.0
8.2
Ø9.2
11.5
12
15.0
M9
8-Ø1
13
M9
1.5
8
13
Ø3.2
L
8
3
12
19.2
L
9
2.5x3
15
18.0
RE20F
9.5
Ø6.0
PC Board
Panel Cutout/PCB Layout
6
RE20C
9.5
8
Panel Cutout
Ø9.2
Ø6.0
8.2
24.5
11.5
Ø9.2
13
M9
8-Ø1
8
11
15.0
M9
L
150
12
19.2
L
9
2.5x3
18.6
18.0
SPECIFICATIONS
OUTPUT CIRCUIT
1 (+5V)
2 (ch A)
ORDERING INSTRUCTIONS
ELECTRICAL
1. Input Power: 5.0 VDC ±5% @ 7mA
3.3VDC ±5% @ 8mA
2. Output Voltage: H = Vcc- 0.4V
L
≤
0.4V
3. Resolution: 20PPR, 25 PPR
3. Output Type: TTL/CMOS Compatible
4. Max. Freq. Response: 500 Hz
RE20X
N: Non-Drip Proof
P: Drip Proof
S: Solder Hole
C: Lead wire
V: Vertical Mount
F: Front Mount
X
XX
20: 20 PPR
25: 25 PPR
X
XX
16: 16mm shaft
20: 20mm shaft
X
A: 5VDC@7mA
B: 3.3VDC @ 8mA
C: Detent
No Entry: No Detent
3 (ch B)
4 (GND)
MECHANICAL
1. Max Shaft Load, radial: 1.0 kgf
axial: 1.0 kgf
2. Rotational Angle: 360° continuous
3. Click Torque: 100 gf•cm max.
4. Rotational Life: 2.5 x 10
6
cycles
OUTPUT WAVEFORM
Counter clockwise rotation viewed from front
ENVIRONMENTAL
1.
2.
3.
4.
5.
Operating Temp: 0° to +60° C
Storage Temp: -20° to +80° C
Humidity:
≤85%
RH, no condensation
Vibration: 10~55 Hz, 1.5 mm, 2 hrs
Shock: 50G, 6ms, 3 axes, 3 reps
Signal A
CUI Stack, Inc.
9615 SW Allen Blvd. #103
Beaverton, OR 97005
Tel: 503/643-4899 FAX: 503/643-6129
DRAWN BY
UPDATED
CHECKED
RELEASED
→
Signal B
Detent stop, 25PPR
←
90°
±
45°
Detent stop, 20PPR
PART NO.
REV.
RE20XXXXXXXX
A
