F-213-1
FTS–110–02–F–DV
FTS–111–02–L–DV–SA
FTS–122–01–F–DV
(1,27 mm) .050"
FTS SERIES
FTS–116–02–L–D
MICRO LOW PROFILE TERMINAL STRIPS
SPECIFICATIONS
For complete specifications and
recommended PCB layouts see
www.samtec.com?FTS
Insulator Material:
Black Liquid Crystal Polymer
Terminal Material:
Phosphor Bronze
Current Rating:
1.75A per contact
@ 80°C ambient
Operating Temp Range:
-55°C to +125°C
Plating:
Sn or Au over 50µ"
(1,27 µm) Ni
RoHS Compliant:
Yes
Lead–Free Solderable:
Yes
SMT Lead Coplanarity:
.004" (0,10 mm) max
Mates with:
FFSD, CLP, FLE,
SFMC (LIF)
Mates with
socket strips
or IDC cable
Low profile
(1,27 mm) .050"
OPTIONS
–S OPTION
–SA OPTION
Surface
mount or
through-hole
Shrouded and
alignment pin
options available
Micro pitch
.050" x .050"
(1,27 mm x 1,27 mm)
–P OPTION
–TR OPTION
ALSO
AVAILABLE
Impedance matched for
high speed applications
Single row
(Mates to CLP Series).
Call Samtec.
APPLICATION
SPECIFIC OPTION
Alignment Pin.
Call Samtec.
FTS
1
NO. PINS
PER ROW
LEAD
STYLE
PLATING
OPTION
ROW
OPTION
OTHER
OPTION
–01
02 thru 50
(except –S & –SA
option = 05 thru 46)
(5,84)
.230
02
–F
= Gold flash
on post,
Matte Tin
on tail
–D
= Double
Through-hole
(–D & –DV only)
= .120"
(3,05 mm)
Post
(Mates with
FFSD)
–SA
= End Shroud with
Alignment Pin
(05 thru 46
positions. Style
-02 & -03 only)
–DV
= Double
Vertical SMT
No. of positions x .050 (1,27)
50
–02
(3,42)
.135
–L
= 10µ" (0,25 µm)
Gold on post,
Matte Tin
on tail
(1,27)
.050
49
= .075"
(1,91 mm)
Post
(Mates with
FLE)
–S
= Single
Through-hole
–S
= End Shroud
(05 thru 46
positions. Style
-02 & -03 only)
01
(1,27) .050
–SV
= Single
Vertical SMT
(3,56)
.140
–03
(2,16)
.085
01
(4,57)
.180
50
No of positions x .050 (1,27)
+ .325 (8,25) = –SA
No of positions x .050 (1,27)
+ .200 (5,08) = – S
02
46
= .065"
(1,65 mm)
Post
(Mates with
CLP)
–P
(4,06)
.160
–SA OPTION
(1,59)
.0625
(1,40)
.055
(1,27)
.050
DIA
(3,30)
.130
X
(5,08)
.200
= Pick &
Place Pad
(05 positions
minimum)
–TR
= Tape & Reel
(-DV only)
(Required callout
for positions
2 thru 4)
(4,70)
.185
45
(3,48)
.137
LEAD
A
STYLE
– 01
(3,05) .120
– 02
(1,91) .075
– 03
(1,65) .065
(0,41)
.016
SQ
(2,29)
.090
–P OPTION
(0,86)
.034
01
A
(1,27)
.050
A
(3,56)
.140
Note:
Some lengths,
styles and options are
non-standard, non-returnable.
–SV
–D
–DV
–S OPTION
(Shrouded options removed for clarity)
–S
WWW.SAMTEC.COM
