MEDIUM POWER AMPLIFIERS
Advanced Control Components designs and manufactures a
wide variety of high-performance medium power amplifiers
having output 1dB compression points in the ¼ to 2W range
from RF through millimeter-wave frequencies. The tables below
list a small portion of the units we have designed. Most
parameters such as bandwidth, gain, noise figure, compression
point etc. can be tailored to your requirements. Contact the
factory to discuss any modifications or additions of special
functions such as gain control, power monitoring, temperature
compensation, etc.
All models are available with hermetic seal and high-rel
screening for mil and spaced-based applications.
Part
Number
P20D
P30D
P60A
P60F
AP90M31
P100N-1
P100L-1
P100LM
P100A
P150D
P150P
P150M
P200A
AP250M25
P300AM
P360A-3
P400F
P400C
AP10M30
P150M-1
P500A
P500L
P500AL
P500B-2
P500A-2
P500F
P600G
P712A
P720B-3
P750A-1
P750A
P700S
P800A
P800A-3
P960
P1000E
P1G34
P1GB
P10GD
P1000E-4
P1GB-1
P11GH
P1500
P16GA
P18GB
AP1900M30
P19GA-1
P2GS-7
Frequency
Range
(MHz)
0.01 - 20
0.01 - 30
50 - 70
50 - 70
50 - 90
0.01 - 100
0.08 - 100
10 - 100
90 - 110
0.035 - 150
0.08 - 150
0.5 - 150
100 - 200
2 - 250
3 - 300
350 - 372
5 - 400
10 - 400
410 - 430
0.15 - 500
2 - 500
5 - 500
5 - 500
5 - 500
10 - 500
50 - 500
590 - 610
412 - 712
560 - 720
10 - 750
500 - 750
650 - 750
10 - 800
400 - 800
400 - 960
0.02 - 1000
0.02 - 1000
0.05 - 1000
0.5 - 1000
8 - 1000
10 - 1000
900 - 1350
1000 - 1500
1380 - 1580
1700 - 1900
1700 - 1900
1850 - 1970
0.5 - 2000
Gain
(dB min)
16
10
24
30
30
26
30
70
25
27
60
26
40
30
30
16
20
20
15
40
37
17
20
24
33
33
40
30
25
30
30
40
30
33
33
16
22
30
30
33
30
25
22
29
23
28
36
30
Flatness
(+/-dB)
(max)
2.0
2.0
0.5
0.5
0.25
1.0
0.5
0.5
0.5
0.5
0.75
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
1.0
0.5
0.75
0.7
1.0
0.5
1.0
1.0
0.5
0.5
1.0
1dB
Compression
(+dBm min)
25
25.5
20
30
31
23
30
30
33
30
30
30
33
25
30
36
20
30
30
30
30
30
30
33
33
23
30
27
33
28
33
34
25
27
30
21
34
30
33
21
30
23
30
34
23
30
30
30
Noise
Figure
(dB max)
9
9
4.5
4.5
4
7
5
1.4
9
8
1.5
5
6
2
8
8
5
7.8
3
3
3
10
5
6
5
9
6
10
10
8
6
6
10
10
6
8
6
9
5
6
10
9
9
6
5.5
8
8
IP3
(+dBm typ)
35
35
30
40
41
33
40
40
43
40
40
40
43
35
40
46
30
40
40
40
40
40
40
43
43
33
40
37
43
38
43
44
35
37
40
31
44
40
43
31
40
33
40
44
33
50
40
40
Supply
Voltage
(+VDC)
24
20
15
24
20
15
24
24
24
24
24
24
24
12
24
24
15
24
15
24
24
24
24
24
24
15
24
20
24
20
24
24
20
20
24
20
20
20
20
20
20
20
24
24
20
15
15
20
Current
(mA max)
150
130
80
360
650
150
400
500
700
400
500
400
700
500
550
850
120
400
1200
450
500
420
450
700
750
200
400
450
750
500
750
700
450
1000
800
170
1100
600
800
200
500
350
700
950
350
500
800
800
Standard
Case
Style
S020
S019
S004
P002
P008
P002
P002
P007
P002
P002
P002
P002
P002
S018
P002
S004
S004
P002
S002
P002
P002
P002
P002
P002A
P002A
P002
P012
P016
P016
P012
P012
P002A
P002
P012
P012
S001
S003
P012
P012
S001
P012
P010
P012
P012
P011
S002
P013
P013
611 Industrial Way West, Eatontown, NJ 07724
tel: 732-460-0212 fax: 732-460-0214
sales@advanced-control.com
www.advanced-control.com
Part
Number
P2GS-2
P2GF-2
P2GF-3
P2GA
ACAM7932
Frequency
Range
(MHz)
0.5 - 2000
10 - 2000
100 - 2000
1700 - 2300
100 - 4000
Gain
(dB min)
40
32
40
22
20
Flatness
(+/-dB)
(max)
1.0
1.5
1.0
1.0
1.0
1dB
Compression
(+dBm min)
23
30
30
23
30
Noise
Figure
(dB max)
4.3
8
5
5
9
IP3
(+dBm typ)
33
40
40
33
40
Supply
Voltage
(VDC)
15
15
15
15
15
Current
(mA max)
350
1000
1000
240
900
Standard
Case
Style
P013
P013
P013
P010
S009
Notes:
•
•
•
•
•
•
•
All specifications guaranteed at +25°C.
Operating temperature range: -50°C to +70°C. Extended operating temperature range available,
VSWR is specified at 2.0:1 maximum input and output at 50Ω. Typical performance is 1.7:1.
All models can be optimized for different frequency ranges.
Custom packaging is available for all models.
Standard package finish: Chemical film per MIL-C-5541, Class C.
RF connectors per MIL-PRF-39012 (SMA female standard)
ENVIRONMENTAL SPECIFICATIONS:
MIL-E-5400, MIL-STD-202, MIL-E-16400
Operating Temp: -50°C to +70°C
Storage Temp: -65°C to +125°C
Humidity: MIL-STD-202F, M103, Cond B
Shock: MIL-STD-202F, M213, Cond B
Altitude: MIL-STD-202F, M105, Cond B
Vibration: MIL-STD-202F, M204, Cond B
Thermal Shock: MIL-STD-202F, M107, Cond A
Temperature Cycle: MIL-STD-202F, M105C, Cond D
SCREENING :
Standard Screening:
Internal Visual per MIL-STD-883, Method 2017
Temperature Cycle: -65°C to +100°C, 10 cycles
Optional High-Rel Screening (Ref MIL-PRF-38534):
Internal Visual per MIL-STD-883, Method 2017
Stabilization Bake per MIL-STD-883, Method 1008
Temperature Cycle per MIL-STD-883, Method 1010
Constant Acceleration per MIL-STD-883, Method 2001
Burn-in per MIL-STD-883, Method 1015
Leak Test per MIL-STD-883, Method 1014
External Visual per MIL-STD-883, Method 2009
Refer to Standard Amplifier Outline Drawing specification for mechanical details
OPTIONS:
•
Custom frequency ranges available to 40GHz
•
Alternate standard and custom packaging
•
Available as open cards or drop-in modules
•
Hermetic seal
•
Integrated power supplies
•
Multiple outputs
•
Interstage access points
•
Hi-rel screening
•
•
•
•
•
•
•
•
Supply voltage options
Voltage-controlled gain
Temperature compensation
Input and output limiting
Integrated filters
Unit-to-unit gain and phase matching
Detected outputs
Power monitoring
* Contact the factory for price and delivery or to discuss options and custom requirements
Advanced Control Components is your source for custom amplifiers and amplifier assemblies. With complete design
and test capability to 40GHz, we have the resources to help develop and realize a new design, build to an existing
specification or replace an obsolete component. From commercial to space qualified applications, we can help.
In addition to high performance amplifier design capability, Advanced Control Components produces custom
amplifier-based multi-function assemblies to 40GHz. With our extensive expertise, we can integrate a wide variety of
components and functions such as mixers, limiters, switches, attenuators, combiners/dividers, filters, detectors, etc.
Additional capabilities include microprocessor control and monitoring, RF signal monitoring, and power supply
conditioning. Contact the factory to discuss your design and application.
MP-0205
