Basic information of LT1202CN amplifier:
LT1202CN is an OPERATIONAL AMPLIFIER. Commonly used packaging methods are PLASTIC, DIP-14
LT1202CN amplifier core information:
The minimum operating temperature of the LT1202CN is and the maximum operating temperature is 70 °C. Maximum bias current at 25°C is: 1 µA Maximum average bias current is 1.2 µA
How to simply check the efficiency of an amplifier? Looking at its slew rate, the LT1202CN has a nominal slew rate of 50 V/us. The maximum slew rate of the LT1202CN given by the manufacturer is 6.4 mA, while the minimum slew rate is 18 V/us. Its minimum voltage gain is 1600. When the op amp is used in closed loop, at a certain closed-loop gain (usually 1 or 2, 10, etc.), the frequency when the LT1202CN gain becomes 0.707 times the low-frequency gain is 12000 kHz.
The nominal supply voltage of the LT1202CN is 15 V, and its corresponding nominal negative supply voltage is -15 V. The power supply range is: +-5/+-15 V. The input offset voltage of LT1202CN is 3000 µV (input offset voltage: the compensation voltage between the two input terminals required to make the output terminal of the operational amplifier 0V (or close to 0V).) The width of LT1202CN is: 7.62 mm.
Related dimensions of LT1202CN:
LT1202CN has 14 terminals. Its terminal position type is: DUAL. Terminal pitch is 2.54 mm. Total pins: 14
LT1202CN amplifier additional information:
LT1202CN adopts the VOLTAGE-FEEDBACK architecture. It does not belong to the low offset class of amplifiers. The frequency compensation status of LT1202CN is: YES. Its temperature grade is: COMMERCIAL. The LT1202CN is not Rohs certified.
The corresponding JESD-30 code is: R-PDIP-T14. The corresponding JESD-609 code is: e0. The packaging code of LT1202CN is: DIP. The materials used in the LT1202CN package are mostly PLASTIC/EPOXY. The package shape is RECTANGULAR.
The LT1202CN package pin format is: IN-LINE. Its terminal form is: THROUGH-HOLE. The maximum seat height is 3.81 mm.
Basic information of LT1202CN amplifier:
LT1202CN is an OPERATIONAL AMPLIFIER. Commonly used packaging methods are PLASTIC, DIP-14
LT1202CN amplifier core information:
The minimum operating temperature of the LT1202CN is and the maximum operating temperature is 70 °C. Maximum bias current at 25°C is: 1 µA Maximum average bias current is 1.2 µA
How to simply check the efficiency of an amplifier? Looking at its slew rate, the LT1202CN has a nominal slew rate of 50 V/us. The maximum slew rate of the LT1202CN given by the manufacturer is 6.4 mA, while the minimum slew rate is 18 V/us. Its minimum voltage gain is 1600. When the op amp is used in closed loop, at a certain closed-loop gain (usually 1 or 2, 10, etc.), the frequency when the LT1202CN gain becomes 0.707 times the low-frequency gain is 12000 kHz.
The nominal supply voltage of the LT1202CN is 15 V, and its corresponding nominal negative supply voltage is -15 V. The power supply range is: +-5/+-15 V. The input offset voltage of LT1202CN is 3000 µV (input offset voltage: the compensation voltage between the two input terminals required to make the output terminal of the operational amplifier 0V (or close to 0V).) The width of LT1202CN is: 7.62 mm.
Related dimensions of LT1202CN:
LT1202CN has 14 terminals. Its terminal position type is: DUAL. Terminal pitch is 2.54 mm. Total pins: 14
LT1202CN amplifier additional information:
LT1202CN adopts the VOLTAGE-FEEDBACK architecture. It does not belong to the low offset class of amplifiers. The frequency compensation status of LT1202CN is: YES. Its temperature grade is: COMMERCIAL. The LT1202CN is not Rohs certified.
The corresponding JESD-30 code is: R-PDIP-T14. The corresponding JESD-609 code is: e0. The packaging code of LT1202CN is: DIP. The materials used in the LT1202CN package are mostly PLASTIC/EPOXY. The package shape is RECTANGULAR.
The LT1202CN package pin format is: IN-LINE. Its terminal form is: THROUGH-HOLE. The maximum seat height is 3.81 mm.
| Parameter Name | Attribute value |
| Is it Rohs certified? | incompatible |
| Parts packaging code | DIP |
| package instruction | PLASTIC, DIP-14 |
| Contacts | 14 |
| Reach Compliance Code | not_compliant |
| ECCN code | EAR99 |
| Amplifier type | OPERATIONAL AMPLIFIER |
| Architecture | VOLTAGE-FEEDBACK |
| Maximum average bias current (IIB) | 1.2 µA |
| Maximum bias current (IIB) at 25C | 1 µA |
| Nominal Common Mode Rejection Ratio | 90 dB |
| frequency compensation | YES |
| Maximum input offset voltage | 3000 µV |
| JESD-30 code | R-PDIP-T14 |
| JESD-609 code | e0 |
| low-dissonance | NO |
| Nominal Negative Supply Voltage (Vsup) | -15 V |
| Number of functions | 4 |
| Number of terminals | 14 |
| Maximum operating temperature | 70 °C |
| Minimum operating temperature | |
| Package body material | PLASTIC/EPOXY |
| encapsulated code | DIP |
| Encapsulate equivalent code | DIP14,.3 |
| Package shape | RECTANGULAR |
| Package form | IN-LINE |
| power supply | +-5/+-15 V |
| Certification status | Not Qualified |
| Maximum seat height | 3.81 mm |
| minimum slew rate | 18 V/us |
| Nominal slew rate | 50 V/us |
| Maximum slew rate | 6.4 mA |
| Supply voltage upper limit | 18 V |
| Nominal supply voltage (Vsup) | 15 V |
| surface mount | NO |
| technology | BIPOLAR |
| Temperature level | COMMERCIAL |
| Terminal surface | Tin/Lead (Sn/Pb) |
| Terminal form | THROUGH-HOLE |
| Terminal pitch | 2.54 mm |
| Terminal location | DUAL |
| Nominal Uniform Gain Bandwidth | 12000 kHz |
| Minimum voltage gain | 1600 |
| width | 7.62 mm |
| Base Number Matches | 1 |
| LT1202CN | LT1202CS | |
|---|---|---|
| Description | IC QUAD OP-AMP, 3000 uV OFFSET-MAX, 12 MHz BAND WIDTH, PDIP14, PLASTIC, DIP-14, Operational Amplifier | IC QUAD OP-AMP, 3000 uV OFFSET-MAX, 12 MHz BAND WIDTH, PDSO16, PLASTIC, SOIC-16, Operational Amplifier |
| Is it Rohs certified? | incompatible | incompatible |
| Parts packaging code | DIP | SOIC |
| package instruction | PLASTIC, DIP-14 | PLASTIC, SOIC-16 |
| Contacts | 14 | 16 |
| Reach Compliance Code | not_compliant | not_compliant |
| ECCN code | EAR99 | EAR99 |
| Amplifier type | OPERATIONAL AMPLIFIER | OPERATIONAL AMPLIFIER |
| Architecture | VOLTAGE-FEEDBACK | VOLTAGE-FEEDBACK |
| Maximum average bias current (IIB) | 1.2 µA | 1.2 µA |
| Maximum bias current (IIB) at 25C | 1 µA | 1 µA |
| Nominal Common Mode Rejection Ratio | 90 dB | 90 dB |
| frequency compensation | YES | YES |
| Maximum input offset voltage | 3000 µV | 3000 µV |
| JESD-30 code | R-PDIP-T14 | R-PDSO-G16 |
| JESD-609 code | e0 | e0 |
| low-dissonance | NO | NO |
| Nominal Negative Supply Voltage (Vsup) | -15 V | -15 V |
| Number of functions | 4 | 4 |
| Number of terminals | 14 | 16 |
| Maximum operating temperature | 70 °C | 70 °C |
| Package body material | PLASTIC/EPOXY | PLASTIC/EPOXY |
| encapsulated code | DIP | SOP |
| Encapsulate equivalent code | DIP14,.3 | SOP16,.4 |
| Package shape | RECTANGULAR | RECTANGULAR |
| Package form | IN-LINE | SMALL OUTLINE |
| power supply | +-5/+-15 V | +-5/+-15 V |
| Certification status | Not Qualified | Not Qualified |
| Maximum seat height | 3.81 mm | 1.75 mm |
| minimum slew rate | 18 V/us | 18 V/us |
| Nominal slew rate | 50 V/us | 50 V/us |
| Maximum slew rate | 6.4 mA | 6.4 mA |
| Supply voltage upper limit | 18 V | 18 V |
| Nominal supply voltage (Vsup) | 15 V | 15 V |
| surface mount | NO | YES |
| technology | BIPOLAR | BIPOLAR |
| Temperature level | COMMERCIAL | COMMERCIAL |
| Terminal surface | Tin/Lead (Sn/Pb) | Tin/Lead (Sn/Pb) |
| Terminal form | THROUGH-HOLE | GULL WING |
| Terminal pitch | 2.54 mm | 1.27 mm |
| Terminal location | DUAL | DUAL |
| Nominal Uniform Gain Bandwidth | 12000 kHz | 12000 kHz |
| Minimum voltage gain | 1600 | 1600 |
| width | 7.62 mm | 3.9 mm |
| Base Number Matches | 1 | 1 |
