S40KR: DescriptionRectifier Diode, 1 Phase, 1 Element, 40A, 800V V(RRM), Silicon, DO-5,; CategoryDiscrete semiconductor diode; File Size932KB，2 Pages; ManufacturerDaco Semiconductor Co., Ltd.

Download Datasheet Parametric View All

S40KR Online Shopping

Suppliers	Part Number	Price	MOQ	In stock
	S40KR	-	-	View	Buy Now

S40KR Overview

Rectifier Diode, 1 Phase, 1 Element, 40A, 800V V(RRM), Silicon, DO-5,

S40KR Parametric

Parameter Name	Attribute value
package instruction	O-MUPM-D1
Reach Compliance Code	unknown
application	GENERAL PURPOSE
Shell connection	ANODE
Configuration	SINGLE
Diode component materials	SILICON
Diode type	RECTIFIER DIODE
Maximum forward voltage (VF)	1.1 V
JEDEC-95 code	DO-5
JESD-30 code	O-MUPM-D1
Maximum non-repetitive peak forward current	595 A
Number of components	1
Phase	1
Number of terminals	1
Maximum operating temperature	175 °C
Minimum operating temperature	-55 °C
Maximum output current	40 A
Package body material	METAL
Package shape	ROUND
Package form	POST/STUD MOUNT
Maximum repetitive peak reverse voltage	800 V
Maximum reverse current	10 µA
surface mount	NO
Terminal form	SOLDER LUG
Terminal location	UPPER
Base Number Matches	1

Preview

Download Datasheet

View All

DACO SEMICONDUCTOR CO., LTD.

Features

High Surge Capability

Types Up to 1600V V

RRM

S40B(R)

THRU

S40Y(R)

STANDARD RECOVERY DIODE STUD TYPES

40A

40 Amp Recti er

100-1600 Volts

Maximum Ratings

Operating Temperature:

Storage Temperature:

-55 C to +175

DO-5

M

-55 C to +175

J

Part Number

S40B(R)

S40D(R)

S40G(R)

S40J(R)

S40K(R)

S40M(R)

S40Q(R)

S40V(R)

S40Y(R)

Maximum

Recurrent

Peak Reverse

Voltage

100V

200V

400V

600V

800V

1000V

1200V

1400V

1600V

Maximum

RMS Voltage

70V

140V

280V

420V

560V

700V

840V

990V

1130V

Maximum DC

Blocking

Voltage

100V

200V

400V

600V

800V

1000V

1200V

1400V

1600V

K

P

D

B

N

C

G

F

A

E

Electrical Characteristics @ 25

Average Forward

Current

(Per pkg)

Peak F orward Sur ge

Cur rent

Maximum

Instantaneous

Forward Voltage *

Maximum

Instantaneous

Reverse Current At

Rated DC Blocking

Voltage

(Per leg)

Unless Otherwise Specified

40 A

595A

1.1V

T

C

= 140

DIM

Notes :

1.Standard Polarity Stud is Cathod

2.Reverse Polarity: Stud is Anode

Inches

Min

A

B

C

D

E

F

0.669

-----

0.422

0.115

-----

0.236

-----

0.140

0.687

0.794

1.020

0.453

0.200

0.460

0.280

-----

0.589

0.063

0.175

Max

1/4 –28 UNF

17.19

-----

10.72

2.93

-----

6.00

-----

3.56

17.44

20.16

25.91

11.50

5.08

11.68

7.00

-----

14.96

1.60

4.45

Min

I

F(AV)

I

FSM

V

F

Millimeters

Max

8.3ms , half sine

I

FM

= 40A

T

J

= 25

T

J

= 25

T

J

= 175

I

R

μ

10 A

12 mA

Maximum Thermal

Resistance Junction

To Case

Mounting torque

R jc

Inch pounds

(in-pb)

1.35 C/W

30

G

J

K

M

N

Pulse Test: Pulse Width 300

μsec.

Duty Cycle

<

2%

P

www.dacosemi.com.tw

-1-
