REVISION Y
DO NOT
SCALE FROM
THIS PRINT
C
((No OF POS / 16) x .840[21.34] + .040[1.02]
C
QFS-XXX-XX.XX-X-D-DP-XX-XXX-XX
No OF POSITIONS
-016, -032, -048,
-064, * -080
(PER ROW)
LEAD STYLE
-04.25 (SEE NOTE 9)
PLATING SPECIFICATION
-L: LIGHT GOLD (USE C-181-04.25-L)
-H: HEAVY GOLD (USE C-181-04.25-H)
-S: SELECTIVE GOLD (USE C-181-04.25-S)
-SL: LIGHT SELECTIVE GOLD
(USE C-181-04.25-SL)
(ALL PLATING STYLES
USE T-1G20-04.25-L)
ROW SPECIFICATION
-D: DOUBLE
PACKAGING OPTION
-TR: TAPE & REEL PACKAGING
(-016 THRU -048 WITH NO OPTIONS)
(-016 & -032 WITH -GP, -PXX, -RF1, RT1)
(-016 WITH RF2)
(No OF POS / 16) x .840[21.34]) - .290[7.37]
.108 2.731
REF
.8400 21.34 (TYP)
.3250 8.26
(TYP)
C
3 EQ SPACES @
.075[1.91] (TYP)
"A"
02
.320 8.13
REF
"A"
.0250 0.635 REF
.075 1.91 REF
.708 17.97
.009 0.23 REF
-DP: DIFFERENTIAL PAIRS
01
OPTION
-A: ALIGNMENT PIN
(NOT AVAILABLE WITH -PXX OR -RFX)
-GP: GUIDE HOLES
(SEE FIG 2, SHEET 2)
(NOT AVAILABLE WITH -PXX, -RFX,
OR -RT1)
* = NOT TOOLED
.278 7.06
REF
OPTION
-PC4: 4 POWER POS PER END (.062" THICK BOARD)
(SEE FIG 3, SHEET 3)
-PC8: 8 POWER POS PER END (.062" THICK BOARD)
(SEE FIG 3, SHEET 3)
-PT4: 4 POWER POS PER END (.093" THICK BOARD"
(SEE FIG 3, SHEET 3)
-PT8: 8 POWER POS PER END (.093" THICK BOARD)
(SEE FIG 3, SHEET 3)
-RF1: 1 RF POS PER END
(SEE FIG 4, SHEET 4)
-RF2: 2 RF POS PER END
(SEE FIG 5, SHEET 4)
-RT1: 1 RT POS PER END
(SEE FIG 6, SHEET 5)
-P: PICK AND PLACE PAD
(USE PPP-51, SEE FIG 7, SHEET 2)
[-PXX NOT AVAILABLE IN
COMBINATION WITH -A OR -GP]
[-PXX AVAILABLE ON POSITIONS
-016, -032 & -048 ONLY]
C
.035 0.89
REF
C
.004 0.10
T-1G20-04.25-L
.040 1.02 REF
((No OF POS / 16) x .840[21.34]) - .030[0.76] REF
+.004
+0.10
.1340±.005 3.403±0.127
(MEASURED CONTACT
TO CONTACT)
QFSS-26-04.25-D-XX-A
FIG 1
QFS-032-04.25-X-D-DP-A SHOWN
C
.293
- .002
7.44
- 0.05
(SEE NOTES 5, 6, & 7)
C
C-181-04.25-X
SEE NOTE 4
.320±.006 8.13±0.15
SEE TABLE 1
(SEE NOTE 6)
.051 1.30 REF
NOTES:
1.
C
REPRESENTS A CRITICAL DIMENSION.
2. MAXIMUM BURR ALLOWANCE: .0015[0.038].
3. MINIMUM PUSHOUT FORCE: SIGNAL: .5 LB, GROUND: 1 LB, POWER: .5 LB, RF: .5 LB.
4. CONTACTS WILL BE SHEARED FOR ALL POSITIONS & ALL STYLES FOR THE QFS.
5. MAXIMUM VARIANCE OF .002[0.05].
6. DIMENSION APPLIES TO CONTACTS & GROUND PLANE.
7. GROUND PLANE PRESS HEIGHT MUST BE .003 [.08] LESS THAN THE MAX HEIGHT
OR .001 [.03] GREATER THAN THE MINIMUM HEIGHT OF THE TERMINAL.
8. PARTS TO BE PACKAGED IN TRAYS
9. LEADSTYLE -01 MAY BE SUBSTITUTED IN PART CALLOUT FOR -04.25 FOR EXISTING CUSTOMERS ONLY.
F:\dwg\misc\mktg\QFS-XXX-XX.XX-X-D-DP-XX-XXX-XX-MKT.SLDDRW
SECTION "A"-"A"
SCALE 5 : 1
UNLESS OTHERWISE SPECIFIED,
DIMENSIONS ARE IN INCHES.
TOLERANCES ARE:
DECIMALS
PROPRIETARY NOTE
THIS DOCUMENT CONTAINS INFORMATION
CONFIDENTIAL AND PROPRIETARY TO
SAMTEC, INC. AND SHALL NOT BE REPRODUCED
OR TRANSFERRED TO OTHER DOCUMENTS OR
DISCLOSED TO OTHERS OR USED FOR ANY
PURPOSE OTHER THAN THAT WHICH IT WAS
OBTAINED WITHOUT THE EXPRESSED WRITTEN
CONSENT OF SAMTEC, INC.
.XX: .01 [.3]
2
.XXX: .005 [.13]
.XXXX: .0020 [.051]
ANGLES
520 PARK EAST BLVD, NEW ALBANY, IN 47150
PHONE: 812-944-6733
FAX: 812-948-5047
e-Mail: info@SAMTEC.com
code: 55322
MATERIAL:
INSULATOR: VECTRA E130, COLOR: BLACK
CONTACTS & GROUND PLANE:
PHOS BRONZE
DO NOT SCALE DRAWING
SHEET SCALE: 2.25:1
.635mm DIFFERENTIAL PAIRS TERMINAL STRIP
DWG. NO.
DESCRIPTION:
QFS-XXX-XX.XX-X-D-DP-XX-XXX-XX
SHEET
1
OF
5
BY:
BRATCHER 08/08/2003
REVISION Y
IN-PROCESS 1
.0165±.004 0.42±0.102
(TYP)
C
CONTACT DETAILS
SEE NOTE
(ALL CONTACTS SHEARED FOR QFS)
.002[0.05] MAX
BURR
.293
- .002
7.44
- 0.05
(SEE NOTE 5)
+.004
+0.10
.008 0.20
C-181-04.25-X
SEE TABLE 1
FIG 2
-GP: GUIDE HOLE OPTION
(QFS-032-04.25-X-D-DP-A-GP SHOWN)
(NOT AVAILABLE WITH -PXX, RFX, OR -RT1 OPTIONS)
"B" REF
(SEE TABLE 2)
-P: PICK & PLACE PAD OPTION
FIG 7
"A" REF
(SEE TABLE 2)
.253 6.43
REF (2 PLCS)
"B"
("G" -.535)/2±.020
QFSS-26-04.25-D-XX-A-GP
"B"
.140 3.56 REF (2 PLCS)
SECTION "B"-"B"
SCALE 1.75 : 1
"G" = MEASURED SIZE
PPP-51
.535 13.59 REF
.275 6.99
REF
PROPRIETARY NOTE
THIS DOCUMENT CONTAINS INFORMATION
CONFIDENTIAL AND PROPRIETARY TO
SAMTEC, INC. AND SHALL NOT BE REPRODUCED
OR TRANSFERRED TO OTHER DOCUMENTS OR
DISCLOSED TO OTHERS OR USED FOR ANY
PURPOSE OTHER THAN THAT WHICH IT WAS
OBTAINED WITHOUT THE EXPRESSED WRITTEN
CONSENT OF SAMTEC, INC.
.373 9.47
REF
520 PARK EAST BLVD, NEW ALBANY, IN 47150
PHONE: 812-944-6733
FAX: 812-948-5047
e-Mail: info@SAMTEC.com
code: 55322
DO NOT SCALE DRAWING
SHEET SCALE: 2.5:1
.635mm DIFFERENTIAL PAIRS TERMINAL STRIP
DWG. NO.
DESCRIPTION:
F:\dwg\misc\mktg\QFS-XXX-XX.XX-X-D-DP-XX-XXX-XX-MKT.SLDDRW
BY:
BRATCHER 08/08/2003
QFS-XXX-XX.XX-X-D-DP-XX-XXX-XX
SHEET
2
OF
5
REVISION Y
.069 1.76
"D" REF
("E" EQ SPACE(S) @ .07874[2.000]) (TYP)
C
L
POWER PIN 2
.1000 2.54
C
L
"C"
POWER COMBO OPTIONS
(QFS-032-04.25-X-D-DP-PC4 SHOWN)
(SAME AS FIG 1, UNLESS OTHERWISE STATED)
(NOT AVAILABLE WITH -A OR -GP OPTION)
(AVAILABLE ON POS -016, -032, -048 ONLY)
FIG 3
POWER PIN 1
"C"
"F" REF (TYP)
POWER PIN 3
QFSS-26-04.25-D-XX-PCX
(SEE TABLE 3)
C
L
C-79-XX-S
.113 2.87 REF
C
C
C
"R" REF
2 MAX SWAY
(TYP)
.07874±.0050 2.000±0.127 (TYP)
C
'G'
3 MAX TOE
(TYP)
C
"C"
C
SECTION "C"-"C"
'D'
.100±.005 2.54±0.13
.0190 0.48
REF (TYP)
DETAIL 'D'
SCALE 8 : 1
.005 MAX BURR
THIS DIRECTION
ONLY, OTHERWISE
SEE NOTE 2
DETAIL 'G'
SCALE 10 : 1
PROPRIETARY NOTE
THIS DOCUMENT CONTAINS INFORMATION
CONFIDENTIAL AND PROPRIETARY TO
SAMTEC, INC. AND SHALL NOT BE REPRODUCED
OR TRANSFERRED TO OTHER DOCUMENTS OR
DISCLOSED TO OTHERS OR USED FOR ANY
PURPOSE OTHER THAN THAT WHICH IT WAS
OBTAINED WITHOUT THE EXPRESSED WRITTEN
CONSENT OF SAMTEC, INC.
520 PARK EAST BLVD, NEW ALBANY, IN 47150
PHONE: 812-944-6733
FAX: 812-948-5047
e-Mail: info@SAMTEC.com
code: 55322
DESCRIPTION:
DWG. NO.
DO NOT SCALE DRAWING
SHEET SCALE: 2.5:1
.635mm DIFFERENTIAL PAIRS TERMINAL STRIP
F:\dwg\misc\mktg\QFS-XXX-XX.XX-X-D-DP-XX-XXX-XX-MKT.SLDDRW
BY:
BRATCHER 08/08/2003
QFS-XXX-XX.XX-X-D-DP-XX-XXX-XX
SHEET
3
OF
5
REVISION Y
-RF1 OPTION
(QFS-032-04.25-X-D-DP-RF1 SHOWN)
(SAME AS FIG 3, UNLESS OTHERWISE STATED)
(NOT AVAILABLE WITH -A OR -GP OPTIONS)
(AVAILABLE ON POSITIONS -016, -032, & -048 ONLY)
"H" REF (SEE TABLE 5)
02
"E"
FIG 4
"E"
01
RF01
SUB-GRF1-J-P-X-XX-TH2
.100 2.54 REF
C
.140 3.56 (TYP)
"J"
.070 1.78 REF
C
.003[0.08] (SEE TABLE 5)
.028 0.70 REF
C
.140 3.56 (TYP)
C
.020 0.50 SQ REF
SECTION "E"-"E"
"H" REF (SEE TABLE 5)
.250±.002 6.35±0.051
C
02
FIG 5
-RF2 OPTION
(QFS-032-04.25-X-D-DP-RF2 SHOWN)
(SAME AS FIG 4, UNLESS OTHERWISE STATED)
(NOT AVAILABLE WITH -A OR -GP OPTIONS)
(AVAILABLE ON POSITIONS -016, -032, & -048 ONLY)
01
RF02
RF01
PROPRIETARY NOTE
THIS DOCUMENT CONTAINS INFORMATION
CONFIDENTIAL AND PROPRIETARY TO
SAMTEC, INC. AND SHALL NOT BE REPRODUCED
OR TRANSFERRED TO OTHER DOCUMENTS OR
DISCLOSED TO OTHERS OR USED FOR ANY
PURPOSE OTHER THAN THAT WHICH IT WAS
OBTAINED WITHOUT THE EXPRESSED WRITTEN
CONSENT OF SAMTEC, INC.
520 PARK EAST BLVD, NEW ALBANY, IN 47150
PHONE: 812-944-6733
FAX: 812-948-5047
e-Mail: info@SAMTEC.com
code: 55322
DESCRIPTION:
DWG. NO.
DO NOT SCALE DRAWING
.635mm DIFFERENTIAL PAIRS TERMINAL STRIP
"J" .003[0.08] (SEE TABLE 5)
C
SHEET SCALE: 2.5:1
QFS-XXX-XX.XX-X-D-DP-XX-XXX-XX
SHEET
4
OF
5
F:\dwg\misc\mktg\QFS-XXX-XX.XX-X-D-DP-XX-XXX-XX-MKT.SLDDRW
BY:
BRATCHER 08/08/2003
REVISION Y
FIG 6
-RT1 OPTION
(QFS-032-04.25-X-D-DP-A-RT1 SHOWN)
(SAME AS FIG 3, UNLESS OTHERWISE STATED)
(NOT AVAILABLE WITH -GP OR -RFX OPTIONS)
(AVAILABLE ON POSITIONS -016 & -032 WITH -A OPTION ONLY)
"K" REF (SEE TABLE 6)
02
"F"
"F"
01
"L" (SEE TABLE 6)
.082 2.08
REF
2 MAX SWAY
(TYP)
QFSS-26-04.25-02-A-RT1
C
T-1R32-10-F-T
C
.100 2.54 REF
.062 1.57
REF
SECTION "F"-"F"
FLUSH TO .002
.055 1.40 REF
PROPRIETARY NOTE
THIS DOCUMENT CONTAINS INFORMATION
CONFIDENTIAL AND PROPRIETARY TO
SAMTEC, INC. AND SHALL NOT BE REPRODUCED
OR TRANSFERRED TO OTHER DOCUMENTS OR
DISCLOSED TO OTHERS OR USED FOR ANY
PURPOSE OTHER THAN THAT WHICH IT WAS
OBTAINED WITHOUT THE EXPRESSED WRITTEN
CONSENT OF SAMTEC, INC.
520 PARK EAST BLVD, NEW ALBANY, IN 47150
PHONE: 812-944-6733
FAX: 812-948-5047
e-Mail: info@SAMTEC.com
code: 55322
DO NOT SCALE DRAWING
SHEET SCALE: 2.5:1
.635mm DIFFERENTIAL PAIRS TERMINAL STRIP
DWG. NO.
DESCRIPTION:
QFS-XXX-XX.XX-X-D-DP-XX-XXX-XX
SHEET
5
OF
5
F:\dwg\misc\mktg\QFS-XXX-XX.XX-X-D-DP-XX-XXX-XX-MKT.SLDDRW
BY:
BRATCHER 08/08/2003
