MAX3952EGK-D datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Wireless rf/communication> Telecom circuit> MAX3952EGK-D

MAX3952EGK-D: DescriptionSupport Circuit, Bipolar, 10 X 10 MM, 0.90 MM HEIGHT, QFN-68; CategoryWireless rf/communication Telecom circuit; File Size296KB，10 Pages; ManufacturerMaxim; Websitehttps://www.maximintegrated.com/en.html

Download Datasheet Parametric Compare View All

MAX3952EGK-D Overview

Support Circuit, Bipolar, 10 X 10 MM, 0.90 MM HEIGHT, QFN-68

MAX3952EGK-D Parametric

Parameter Name	Attribute value
Is it Rohs certified?	incompatible
Parts packaging code	QFN
package instruction	HVQCCN,
Contacts	68
Reach Compliance Code	compliant
JESD-30 code	S-XQCC-N68
JESD-609 code	e0
length	10 mm
Humidity sensitivity level	3
Number of functions	1
Number of terminals	68
Maximum operating temperature	85 °C
Minimum operating temperature	-40 °C
Package body material	UNSPECIFIED
encapsulated code	HVQCCN
Package shape	SQUARE
Package form	CHIP CARRIER, HEAT SINK/SLUG, VERY THIN PROFILE
Peak Reflow Temperature (Celsius)	245
Certification status	Not Qualified
Maximum seat height	0.9 mm
Nominal supply voltage	3.3 V
surface mount	YES
technology	BIPOLAR
Telecom integrated circuit types	SUPPORT CIRCUIT
Temperature level	INDUSTRIAL
Terminal surface	TIN LEAD
Terminal form	NO LEAD
Terminal pitch	0.5 mm
Terminal location	QUAD
Maximum time at peak reflow temperature	NOT SPECIFIED
width	10 mm
Base Number Matches	1

Preview

Download Datasheet

View All

19-2405; Rev 0; 4/02

10Gbps 16:1 Serializer

General Description

The MAX3952 16:1 serializer is optimized for 10.3Gbps

and 9.95Gbps Ethernet applications. A serial clock out-

put is provided for retiming the data at the latch input of

the laser driver. Both the high-speed data and clock are

CML outputs. The serializer operates from a single

+3.3V supply, consuming only 1.15W typical power.

The clock multiplier reference clock frequency can be

either 1/16 or 1/64 the serial output clock rate. A FIFO

aligns the phase between the parallel clock input and

the internally synthesized clock. In addition, a 1/16

counterdirectional clock output (LVDS) is provided for

use as the clock signal of the XAUI codec IC or framer.

The operating temperature range is from -40°C to

+85°C. The MAX3952 is available in a 10mm

10mm

68-pin QFN package.

16-Bit LVDS Interface

Single +3.3V Supply

1.15W Power Dissipation

LVDS Source Clock Output

Built-In 2

- 1 PRBS Pattern Generator

Deterministic Jitter: 9ps (max) at 0°C to +85°C

Operating Temperature Range: -40°C to +85°C

68-Pin QFN Package (10mm

10mm)

Features

Operates at 9.953Gbps and 10.3125Gbps

MAX3952

Applications

10Gbps Ethernet LAN

10Gbps Ethernet WAN

PART

MAX3952EGK

Ordering Information

TEMP RANGE

-40°C to +85°C

PIN-PACKAGE

68 QFN

Pin Configuration appears at end of data sheet.

Typical Application Circuit

644.53MHz

REFCLK INPUT

3.3V

100Ω

0.1µF

PDIO+ REFCLK+ REFCLK- CKSET V

_VCO

PDIO-

PDI15+

MAC

PDI15-

PCLKI+

PCLKI-

PCLKO+

PCLKO-

FIFOERR

FIL

SDO+

SDO-

MAX3952

MAX3930

SCLKO+

SCLKO-

RESET

PRBSEN

LOCK

GND

SCLKEN

TTL

THIS SYMBOL REPRESENTS A TRANSMISSION LINE

OF CHARACTERISTIC IMPEDANCE (Z

= 50Ω).

________________________________________________________________

Maxim Integrated Products

For pricing, delivery, and ordering information, please contact Maxim/Dallas Direct! at

1-888-629-4642, or visit Maxim’s website at www.maxim-ic.com.
