F-212-1
LSS–120–03–FM–DV–A
TM
LSS–130–02–LM–DV–A–K
(0,635mm) .025"
LSS SERIES
SYSTEM
LSS–140–01–LM–DV–A
HIGH SPEED HERMAPHRODITIC STRIP
High Speed/High Density
SPECIFICATIONS
For complete specifications and
recommended PCB layouts
see www.samtec.com?LSS
Insulator Material:
Black Liquid Crystal
Polymer
Contact Material:
Phosphor Bronze
Plating:
Au or Sn over
50µ" (1,27µm) Ni
Current Rating:
1.7A @ 30°C Temperature Rise
Operating Temp Range:
-55°C to +125°C
RoHS Compliant:
Yes
Mates with:
LSS
Low cost
Blade &
Beam
contact
Audible click when
properly mated
Self-mating
system can
reduce
inventory
costs
• High retention
contacts
• Audible click
when mated
• Shrouded
Slim row-to-row
design
Mated height
variety/flexibility
Processing:
Lead-Free Solderable:
Yes
SMT Lead Coplanarity:
(0,10mm) .004" max
Board Stacking:
For applications requiring more
than two connectors per board,
contact ipg@samtec.com
LSS/LSS
Rated @ 3dB Insertion Loss*
6mm Stack Height
Single-Ended Signaling
10 GHz / 20 Gbps
Differential Pair Signaling
9 GHz / 18 Gbps
*Performance data includes effects of a non-optimized PCB.
Performance data for other stack heights and complete test data
available at www.samtec.com?LSS or contact sig@samtec.com
(0,635mm)
.025" pitch
LSS
APPLICATION
1
NO. PINS
PER ROW
LEAD
STYLE
Specify
LEAD
STYLE
from
chart
PLATING
OPTION
DV
A
OPTION
LSS
MATED
HEIGHT
10, 20, 30, 40, 50
–FM
= Gold flash on contact,
Matte Tin on tail
–K
= (3,50mm) .138" DIA
Polyimide film
Pick & Place Pad
–LM
LEAD
STYLE
MATED
HEIGHT*
(6,00)
.236
(7,00)
.276
(8,00)
.315
(9,00)
.354
(10,00)
.394
(12,00)
.472
=10µ" (0,25µm)
Gold on contact,
Matte Tin on tail
–TR
= Tape & Reel
–01 & –01
–01 & –03
–03 & –03
–01 & –02
–02 & –03
–02 & –02
LEAD
STYLE
(No. of positions x
(0,635) .025)
+ (4,75) .187
(4,14)
.163
(0,635)
.025
(0,20)
.008
A
B
–01
–02
–03
(4,50) (1,60)
.177
.063
(7,49) (4,59)
.295
.181
(5,49) (2,59)
.216
.102
APPLICATION
SPECIFIC OPTION
• Locking Clip on –02 or –03 lead style.
• Other Gold plating options available.
• Other pin counts available.
Call Samtec.
*Processing conditions will
affect mated height.
B
A
(No. of positions
x (0,635) .025)
+ (1,50) .059
(4,60)
.181
(0,85)
.033
(0,75)
.030
DIA
Note:
Some lengths,
styles and options are
non-standard, non-returnable.
–A OPTION
WWW.SAMTEC.COM
