Dimensions
Global Connector Technology Ltd. - BF112: 2.00mm Pitch Socket, Dual Row, Surface Mount, Horizontal
A
Contacts
A
4.3
6.3
8.3
10.3
12.3
14.3
16.3
18.3
20.3
22.3
24.3
26.3
28.3
30.3
32.3
34.3
36.3
38.3
40.3
42.3
44.3
46.3
48.3
50.3
52.3
54.3
56.3
58.3
60.3
62.3
64.3
66.3
68.3
70.3
72.3
74.3
76.3
78.3
80.3
B
2
4
6
8
10
12
14
16
18
20
22
24
26
28
30
32
34
36
38
40
42
44
46
48
50
52
54
56
58
60
62
64
66
68
70
72
74
76
78
B ±0.25
5.16
Max. Insertion Depth
0.25mm Max. Sway
(Either direction)
4
Pin 0.5x0.5
2.00
1.60
Min. Insertion Depth
2.50
0.80
6
8
10
B
6.50
0.20mm Max. Sway
(Either direction)
12
14
16
18
Recommended PCB Layout
(Tolerance:±0.05mm)
Solder Area
20
22
24
26
28
C
A ±0.30
6.35
6.90±0.25
30
32
34
4.00
36
D
0.15
1.27±0.25
1.80±0.25
3.20±0.25
38
40
42
44
46
48
50
52
54
56
58
60
2.00±0.13
E
F
Specifications
规格
Current Rating
电流额定值
: 2 Amp
Insulation Resistance
绝缘电阻值
: 1000M Ω min.
Dielectric Withstanding
耐电压
: 500V AC
Contact Resistance
接触电阻值
: 20mΩ max.
Operating Temperature
工½温度
: -40°C to +105°C
Contact Material
端子物料
: Phosphor Bronze
Insulation Material
绝缘½物料
: Polyamide
聚醯胺
Nylon 6T, UL 94V-0
Soldering Process
可焊性
: Nylon 6T
IR Reflow
回流焊
: 260°C for 10 sec.
Manual Solder
人工焊接
: 350°C for 3-5 sec.
Mates with
配套之母座
(Subject to pin length
在端子长度适合的条件下
):
BF030
BF045
BF050
Perfect planar mating with:
BF060
BF135
By
DETAIL
REV
DATE
AJO
Drawing
Release
A
23/04/14
Ordering Grid
62
BF112
XX
X
N
X
REQUEST SAMPLES
AND QUOTATION
64
66
68
70
72
74
76
78
80
G
No. of Contacts
04 to 80
Plating Options
A = Gold Flash All Over
(Standard)
B = Selective Gold Flash Contact Area/
Tin On Tail
C = Tin All Over
Tolerances
(Except as noted)
Packing
D = Tube
(Standard)
A = Tape and Reel
G = Box
Insulator Material
N = Nylon 6T
Part Number:-
Date:-
Dimensions in mm
BF112
Description:-
23 APR 14
H
X. ± 0.30
X.X ± 0.25
X.XX ± 0.15
X.XXX ± 0.10
X.°±5°
.X°±3°
.XX°±2°
.XXX°±1°
2.00mm Pitch Socket, Dual Row,
Surface Mount, Horizontal
GC
Scale
NTS
www.gct.co
Drawn by
AJO
E & OE
1
2
3
4
Third Angle Projection
C
THIS DRAWING IS CONFIDENTIAL AND MUST NOT BE
COPIED OR DISCLOSED WITHOUT WRITTEN CONSENT
Revision
A
Material
See Note
Sheet No.
1/1
5
6
7
8
