HS2A thru HS2M
SURFACE MOUNT
GLASS HIGH EFFICIENCY RECTIFIERS
FEATURES
●
Low cost
●
Diffused junction
●
Ultra fast switching for high efficiency
●
Low reverse leakage current
●
Low forward voltage drop
●
High current capability
●
The plastic material carries UL recognition 94V-0
REVERSE VOLTAGE
- 50
to
1000
Volts
FORWARD CURRENT
- 2.0
Amperes
SMB
.083(2.11)
.075(1.91)
.155(3.94)
.130(3.30)
.185(4.70)
.160(4.06)
.012(.305)
.006(.152)
.096(2.44)
.084(2.13)
MECHANICAL DATA
●
Case： Molded Plastic
●
Polarity:Color band denotes cathode
●
Weight: 0.003 ounces,0.093 grams
●
Mounting position: Any
.060(1.52)
.030(0.76)
.220(5.59)
.200(5.08)
.008(.203)
.002(.051)
Dimensions in inches and (millimeters)
MAXIMUM RATINGS AND ELECTRICAL CHARACTERISTICS
Rating at 25℃ ambient temperature unless otherwise specified.
Single phase, half wave ,60Hz, resistive or inductive load.
For capacitive load, derate current by 20%
CHARACTERISTICS
Maximum Recurrent Peak Reverse Voltage
Maximum RMS Voltage
Maximum DC Blocking Voltage
Maximum Average Forward
Rectified Current
Peak Forward Surage Current
8.3ms Single Half Sine-Wave
Super Imposed on Rated Load(JEDEC Method)
Peak Forward Voltage at 2.0A DC(Note1)
Maximum DC Reverse Current
at Rated DC Blocking Voltage
@TJ=25℃
@T
J
=100℃
@T
A
=50
℃
SYMBOL
V
RRM
V
RMS
V
DC
I
(AV)
HS2A
50
35
50
HS2B
100
70
100
HS2D
200
140
200
HS2G
400
280
400
2.0
HS2J
600
420
600
HS2K
800
560
800
HS2M
1000
700
1000
UNIT
V
V
V
A
I
FSM
V
F
I
R
T
RR
C
J
R
θJA
T
J
T
STG
50
50
1.0
60
1.3
5.0
100
75
30
25
-50 to +150
-50 to +150
1.7
A
V
uA
nS
pF
℃/W
℃
℃
Maximum Reverse Recovery Time(Note 1)
Typical Junction Capacitance (Note1)
Typical Thermal Resistance (Note2)
Operating Temperature Range
Storage Temperature Range
NOTES: 1.Measured with I
F
=0.5A，I
R
=1A
，I
RR
=0.25A
2.Measured at 1.0 MHz and applied reverse voltage of 4.0V DC
3.Thermal resistance junction to ambient
~ 107 ~
RATING AND CHARACTERTIC CURVES
HS2A thru HS2M
FIG. 1
–
FORWARD CURRENT DERATING CURVE
3.0
AVERAGE FORWARD CURRENT
AMPERES
2.5
2.0
1.5
1.0
0.5
0
25
50
75
100
125
150
175
SINGLE PHASE HALF WAVE 60Hz
RESISTIVE OR INDUCTIVE LOAD
FIG. 2
–
MAXIMUM NON-REPETITIVE SURGE CURRENT
PEAK FORWARD SURGE CURRENT,
AMPERES
60
50
40
30
20
10
0
1
2
5
10
20
50
100
PULSE WIDTH 3.3
ms
SINGLE HALF-SINE-WAVE
(JEDEC METHOD)
AMBIENT TEMPERATURE (℃)
NUMBER OF CYCLES AT 60Hz
FIG.3
–
TYPICAL JUNCTION CAPACITANCE
100
HS2A - HS2G
FIG.4-TYPICAL FORWARD CHARACTERISTICS
10
INSTANTANEOUS FORWARD CURRENT, (A)
HS2A -HS2D
CAPACITANCE, (pF)
1.0
HS2G
HS2J - HS2M
10
0.1
HS2J -HS2M
T
J
= 25°C
f = 1 MHz
1
1
4
10
100
T
J
= 25°C
PULSE WIDTH 300us
0.01
0
0.2
0.4
0.6
0.8
1.0
1.2
1.4
1.6
1.8
REVERSE VOLTAGE ,VOLTS
INSTANTANEOUS FORWARD VOLTAGE,VOLTS
~ 108 ~
