THICK FILM CHIP RESISTORS NETWORK
•
RTN02-10T
■
CONSTRUCTION
Overcoating
473
■
DIMENSIONS
L1
L2
473
Alumina Substrate
Plating(Ni+Sn)
473
L1
L2
H
Q
L
P
S
W
<
Circuits
>
R
T
E
Unit: mm
Type
Dimensions
RTN02-10T
L
3.20
±
0.20
W
1.60
±
0.15
H
0.55
±
0.10
L1
0.30
±
0.15
L2
0.30
±
0.15
P
0.64
±
0.10
Q
0.32
±
0.10
■
Standard electrical specifications
Type
Rated
Power at
70˚C
Max.
Working
Voltage
Max.
Overload
Voltage
Resistance
T.C.R.
(ppm/˚C)
J(
±
5%)
E-12
Number
of
Terminals
Number
of
Resistors
Operating
Temperature
Range
RTN02-10T
1
W
16
25V
50V
±
20
33Ω~1MΩ
10
8
-55˚C ~+125˚C
■
EXPLANATION OF PART NUMBERS
(EX)
RTN
Type
Chip Resistors
Networks
T : Sn(Ti) Process
02
Size
02
10
Number of
Circuits
10
T
Circuit
Structure
(see above)
103
Nominal Resistance
•
3-Digit: E12 Series
Ex 10Ω=100
1KΩ=102
J
Resistance
Tolerance
J =
±
5%
TP
Packing
TP: Taping(Paper)
76
Specifications given herein may be changed at any time without prior notice. Please confirm technical specifications before your order and/or use.
•
RTN02-10T
■
CHARACTERISTICS
Item
Temperature Cycling
Low Temperature Operation
Short Time Overload
Resistance to Soldering Heat
Loading Life in Moisture
Resistance to dry heat
Load Life
Solderability
Dielectric Withstanding Voltage
*RCWV=Rated Continuous Working Voltage
5%
Test Method
JIS-C5202-7.4
Cycle between -55˚C and +125˚C for 5 cycles
MIL-R-55342-D 4.7.4
Followed by 45 Minutes of RCWV.
JIS-C5202-5.5
Apply rated voltage 2.5 times for 5 seconds
JIS-C5202-6.10
Immerse for 10 sec. in solder at 260
±
3˚C
JIS-C5202-7.9
40˚C, 1000Hrs at RCWV, 1.5Hr ON, 0.5Hr OFF
JIS-C5202-7.2
96Hrs at 125˚C
JIS-C5202-7.10
70˚C, 1000Hrs at RCWV, 1.5Hr ON, 0.5Hr OFF
JIS-C5202-6.11
Immerse for 3 sec. in solder at 245
±
3˚C
JIS-C5202-5.7
Apply 300VAC for 1min
±
(1.0% + 0.05Ω)
±
(1.0% + 0.05Ω)
±
(2.0% + 0.10Ω)
±
(1.0% + 0.10Ω)
±
(2.0% + 0.10Ω)
±
(2.0% + 0.10Ω)
±
(3.0% + 0.10Ω)
Coverage
95%
No short or burned on the appearance
■
TAPING SPECIFICATIONS
Carrier Tape
T2
¿
1.5
+0.1
+0
P0
E
T2
B
A
F
W
T1
EMBOSSED
CARRIER
P
P1
DIRECTION OF FEED
PAPER
CARRIER
■
PACKAGING: TP
Type
RTN02-10T
A
3.5
±
0.2
B
1.9
±
0.2
W
8.0
±
0.2
E
1.75
±
0.1
F
3.5
±
0.1
P0
4.0
±
0.1
P
4.0
±
0.1
P1
2.0
±
0.1
T1
-
Unit: mm
T2
0.75
±
0.10
■
REEL SPECIFICATION
Type
RTN02-10T
W
12.5
M
178
A
2.0
B
13.5
C
21.0
Unit: mm
D
60.0
B
C
A
D
M
±
1.5
±
2.0
±
0.5
±
0.5
±
0.5
±
2.0
■
BULK CASE
Type
TP
5,000
TE
-
Unit: pcs
W
RTN02-10T
Specifications given herein may be changed at any time without prior notice. Please confirm technical specifications before your order and/or use.
77
