Bussmann
®
Tron Time-Delay Fuses
13/32˝ x 1-1/2˝ Midget
500 Volt, 1/10-30 Amps
FNQ
• Nickel plated brass endcaps.
• For motor control transformers and other circuits with in-rush
currents.
Time-Current Characteristic Curve–Average Melt
1-6/10
2
3-2/10
100
4
5
6
7
10
10
TIME IN SECONDS
1
.1
1.5"
( 0.031)
38.1mm
.41"
( 0.004)
10.3mm
100
Catalog Symbol:
FNQ (5AG)
TIME-DELAY
1/10 TO 30A
500Vac (OR LESS)
Interrupting Rating:10,000A
UL LISTED, STD 248-14, (GUIDE # JDYX, FILE # E19180)
CSA CERTIFIED (CLASS 1422-01; FILE 53787)
Catalog Symbol and Ampere Ratings
FNQ-1/10
FNQ-1/8
FNQ-3/16
FNQ-2/10
FNQ-1/4
FNQ-1/2
FNQ-3/10
FNQ-4/10
FNQ-6/10
Ampere
Ratings
1-30
FNQ-15/100
FNQ-8/10
FNQ-1
FNQ-1-1/8
FNQ-1-1/4
FNQ-1-1/2
FNQ-2
FNQ-3
FNQ-2-1/4
FNQ-1-6/10
FNQ-2-1/2
FNQ-3-2/10
FNQ-4
FNQ-5
FNQ-6
FNQ-7
FNQ-8
Weight*
Lbs.
.180
FNQ-4-1/2
FNQ-3-1/2
FNQ-9
FNQ-12
FNQ-15
FNQ-25
—
—
FNQ-5-6/10
FNQ-6-1/4
FNQ-14
FNQ-20
FNQ-30
CURRENT IN AMPERES
100
200
100
200
10
RMS SYMMETRICAL IN AMPERES
CURRENT IN AMPERES
Carton Quantity and Weight
* Weight per carton.
Carton
Qty
10
.082
Kg.
Recommended fuseblocks/fuseholders for
13/32” x 1-1/2” fuses
See Data Sheets listed below
• Open fuseblocks - 1104, 2104
• Finger-safe fuseholders - 1109, 1102, 1103, 1151
• Panel-mount fuseholders - 2114, 2113, 2108,
2112, 2109, 2140
• In-line fuseholders - 2127, 2126
CE logo denotes compliance with European Union Low Voltage
Directive (50-1000Vac, 75-1500Vdc). Refer to Data Sheet: 8002 or
contact Bussmann Application Engineering at 636-527-1270 for more
information.
The only controlled copy of this Data Sheet is the electronic read-only version located on the Bussmann Network Drive. All other copies of this Data Sheet are by definition uncontrolled. This bulletin is intended to clearly
present comprehensive product data and provide technical information that will help the end user with design applications. Bussmann reserves the right, without notice, to change design or construction of any products
and to discontinue or limit distribution of any products. Bussmann also reserves the right to change or update, without notice, any technical information contained in this bulletin. Once a product has been selected, it
should be tested by the user in all possible applications.
10-29-12
SB02295
Form No. FNQ
Page 1 of 1
Data Sheet: 1012
600
20
FNQ-10
TIME IN SECONDS
.6
10
20
.01
1/2
300
10
1
.1
6
.01
1
15
20
25
30
1
