ZXCL200
ULTRA SMALL MICROPOWER SC70 2V 100mA REGULATOR
DESCRIPTION
The ZXCL200 is a very small 2 volt regulator designed
for use in low power and severely space limited
applications.
Supply current is minimised with a ground pin current
of only 40µA at full 100mA load. Logic control allows
the device to be shut down, consuming typically less
than 10nA. These features make it ideal for battery
powered applications where power economy is
critical.
The part has been designed with space sensitive
systems in mind. It is available in the ultra small SC70
package, which is half the size of other SOT23 based
regulator devices
For applications requiring improved performance over
alternative devices, the ZXCL200 is also offered in the 5
pin SOT23 package with an industry standard pinout.
The device features thermal overload and over-current
protection.
T h e Z X C L 2 0 0 i s m an u f a ct u r ed u s i n g C M O S
processing, however advanced design techniques
mean that output noise is improved even when
compared to other bipolar devices.
FEATURES
APPLICATIONS
•
5-pin SC70 package for the ultimate in space
saving
•
Cellular and Cordless phones
•
Palmtop and laptop computers
•
PDA
•
Hand held instruments
•
Camera, Camcorder, Personal Stereo
•
PCMCIA cards
•
Portable and Battery-powered equipmenth
•
5-pin SOT23 industry standard pinout
•
40µA ground pin current with full 100mA load
•
Typically less than 10nA ground pin current on
shutdown
•
2 volt output
•
Very low noise, without bypass capacitor
•
Thermal overload and over-current protection
•
-40 to +85°C operating temperature range
PACKAGE FOOTPRINT
TYPICAL APPLICATION CIRCUIT
Total Aea
2.1mm x 2mm
=4.2mm
2
Battery Supply
Output Voltage
ZXCL
Total Aea
2.8mm x 2.9mm
=8.12mm
2
ISSUE 1 - SEPTEMBER 2001
1
ZXCL200
ABSOLUTE MAXIMUM RATINGS
Terminal Voltage with respect to GND
V
IN
E
N
V
O
-0.3V to 7.0V
-0.3V to 10V
-0.3V to 5.5V
Output short circuit duration
Continuous Power Dissipation
Operating Temperature Range
Storage Temperature Range
Infinite
Internally limited
-40 C to + 85 C
-55 C to + 125 C
Package Power Dissipation (T
A
=25°C)
SC70
300mW (Note 1)
SOT23-5
450mW (Note 1)
Stresses beyond those listed under “Absolute Maximum Ratings” may cause permanent damage to the
device. These are stress ratings only, and functional operation of the device at these or any other conditions
beyond those indicated in the operational sections of the specifications is not implied. Exposure to absolute
maximum conditions for extended periods may affect device reliability.
ELECTRICAL CHARACTERISTICS
V
IN
= V
O
+ 0.5V, typical values at T
A
=25°C
(Unless otherwise stated)
SYMBOL
PARAMETER
CONDITIONS
MIN
V
IN
V
O
Input Voltage
Output Voltage
(Note 3)
∆V
O
/∆T
Output Voltage
Temperature
Coefficient
Output Current
Over Current Limit
Ground pin current
Line Regulation
Load Regulation
Output Noise Voltage
Enable pin voltage for
normal operation
Enable pin voltage for
output shutdown
No Load
I
O
= 100mA
V
IN
=(V
O
+0.5V) to 5.5V, I
O
=1mA
I
O
=1mA to 100mA
f=10Hz to 100kHz, C
O
=10µF,
T
A
= -40°C
2
2.2
0
100
105
25
40
0.02
0.01
50
10
0.8
750
50
100
0.1
0.04
T
A
=-40 C
I
O
= 1mA
I
O
= 100mA
V
O
+0.5V < V
IN
< V
IN
max
-15
ppm/°C
(note2)
1.96
1.94
2
LIMITS
TYP
MAX
5.5
2.04
2.06
UNITS
V
V
V
I
O(MAX)
I
OLIM
I
Q
V
LNR
V
LDR
E
N
V
ENH
V
ENL
mA
mA
A
A
%/V
%/mA
µV
rms
V
V
Device testing is performed at T
A
=25 C. Device thermal performance is guaranteed by design.
Note 1: Maximum power dissipation is calculated assuming the device is mounted on a PCB measuring 2
inches square
Note 2: Output Voltage will start to rise when V
IN
exceeds a value or approximately 1.3V. For normal
operation, V
IN
(min) > V
OUT
(nom) + 0.5V.
Note 3: Nominal value of V
O
is defined at V
IN
=V
O
+0.5V.
ISSUE 1 - SEPTEMBER 2001
2
