BL
FEATURES
GALAXY ELECTRICAL
OOO
VOLTAGE
UGP20A --- UGP20K
RANGE: 50 --- 800 V
CURRENT: 2.0
ULTRA FAST
RECTIFIER
Low cost
Diffusde junction
low leakage current
High current capability
Easily cleaned with alcohol,Isopropanol
and similar solvents
Plastic package has underwriters laboratory
flammability classification 94v-0
DO - 15
MECHANICAL DATA
Case:JEDEC DO--15,molded plastic
Terminals: Axial lead ,solderable per
MIL- STD-202,Method 208
Polarity: Color band denotes cathode
Weight: 0.014 ounces,0.39 grams
Mounting position: Any
MAXIMUM RATINGS AND ELECTRICAL CHARACTERISTICS
Ratings at 25 ambient temperature unless otherwise specified.
Single phase,half wave,60Hz,resistive or inductive load. For capacitive load,derate by 20%.
UGP
20A
Maximum recurrent peak reverse voltage
Maximum RMS voltage
Maximum DC blocking voltage
Maximum average forward rectified current
9.5mm lead length,
@T
A
=75
UGP
20B
100
70
100
UGP
20D
200
140
200
UGP
20F
300
210
300
2.0
UGP
20G
400
280
400
UGP
20J
600
420
600
UGP
20K
800
560
800
UNITS
V
V
V
A
V
RRM
V
RMS
V
DC
I
F(AV)
50
35
50
Peak forward surge current
8.3ms single half-sine-w ave
superimposed on rated load
@T
J
=125
I
FSM
V
F
I
R
trr
C
J
R
θ
JA
T
J
T
STG
0.95
65.0
60.0
A
Maximum instantaneous forw ard voltage
@ 2.0A
Maximum reverse current
@T
A
=25
at rated DC blocking voltage @T
A
=100
Maximum reverse recovery time (Note1)
Typical junction capacitance
Typical thermal resistance
(Note2)
(Note3)
1.25
5.0
100.0
35
22
40
- 55 ----- + 150
- 55 ----- + 150
1.70
2.20
V
z
A
ns
pF
／Ｗ
Operating junction temperature range
Storage temperature range
NOTE: 1. Measured with I
F
=0.5A, I
R
=1A, I
rr
=0.25A.
www.galaxycn.com
2. Measured at 1.0MHz and applied rev erse v oltage of 4.0V DC.
3.Thermal resistance junction to ambient
Document Number 0264025
BL
GALAXY ELECTRICAL
1.
RATINGS AND CHARACTERISTIC CURVES
FIG.1 -- FORWARD DERATING CURVE
PEAK FORWARD SURGE CURRENT
AMPERES
AVERAGE FORWARD CURRENT
UGP20A --- UGP20K
FIG.2 --PEAK FORWARD SURGE CURRENT
2.0
70
60
8.3ms Single Half
Sine-Wave
AMPERES
1.5
50
40
30
20
10
0
UGP20J-UGP20K
UGP20A-UGP20G
1.0
0.5
Single Phase
Half Wave 60H
Z
Resistive or
Inductive Load
0.375"(9.5mm)Lead Length
0
25
50
75
100
125
150
175
0
1
5
10
50
100
AMBIENT TEMPERATURE,
NUMBER OF CYCLES AT 60Hz
FIG.4--TYPICAL REVERSE CHARACTERISTICS
INSTANTANEOUS REVERSE LEAKAGE
CURRENT,MICROAMPERES
FIG.3 --TYPECAL FORWARD CHARACTERISTICS
INSTANTANEOUS FORWARD CURRENT
10
0D
P2
100
-UG
0A
-U
GP
4
2
1
0.4
0.2
0.1
0.04
0.02
0.01
0.2
0.6
UG
20
G
0F
P2
0J
P2
P2
UG
UG
UG
P2
0K
10
AMPERES
1
T
J
=25
Pulse Width=300
µ
s
1.0
1.4
1.8
2.2
T
J
=100
T
J
=125℃
0.1
10
20
40
60
80
100 110
INSTANTANEOUS FORWARD VOLTAGE,VOLTS
PERCENT OF RATED PEAK REVERSE VOLTAGE,%
FIG.5--TYPICAL JUNCTION CAPACITANCE
JUNCTION CAPACITANCE,pF
100
60
40
20
10
6
4
2
T
J
=25
f=1.0MH
Z
0.1 0.2
0.4
1
2
4
10
20
40
100
1
REVERSE VOLTAGE,VOLTS
www.galaxycn.com
Document Number 0264025
BL
GALAXY ELECTRICAL
