24IPR20-05-SIR: DescriptionDC-DC Regulated Power Supply Module, 1 Output, 20W, Hybrid, METAL PACKAGE-7; CategoryPower/power management The power supply circuit; File Size184KB，1 Pages; ManufacturerIBEK Electronic Ag

Download Datasheet Parametric View All

24IPR20-05-SIR Overview

DC-DC Regulated Power Supply Module, 1 Output, 20W, Hybrid, METAL PACKAGE-7

24IPR20-05-SIR Parametric

Parameter Name	Attribute value
Is it lead-free?	Contains lead
Is it Rohs certified?	incompatible
Parts packaging code	MODULE
package instruction	, MODULE,8LEAD,1.8
Contacts	7
Reach Compliance Code	compliant
ECCN code	EAR99
Analog Integrated Circuits - Other Types	DC-DC REGULATED POWER SUPPLY MODULE
Maximum input voltage	36 V
Minimum input voltage	9 V
Nominal input voltage	24 V
JESD-30 code	S-MDMA-P7
length	50.8 mm
Number of functions	1
Output times	1
Number of terminals	7
Maximum operating temperature	85 °C
Minimum operating temperature	-40 °C
Maximum output current	3.3 A
Maximum output voltage	5.05 V
Minimum output voltage	4.95 V
Nominal output voltage	5 V
Package body material	METAL
Encapsulate equivalent code	MODULE,8LEAD,1.8
Package shape	SQUARE
Package form	MICROELECTRONIC ASSEMBLY
Peak Reflow Temperature (Celsius)	NOT SPECIFIED
Certification status	Not Qualified
Maximum seat height	12.8 mm
surface mount	NO
technology	HYBRID
Temperature level	INDUSTRIAL
Terminal form	PIN/PEG
Terminal location	DUAL
Maximum time at peak reflow temperature	NOT SPECIFIED
Maximum total power output	20 W
Fine-tuning/adjustable output	YES
width	50.8 mm
Base Number Matches	1

Preview

Download Datasheet

View All

IBEK

€

www.ibek.ch

Single & triple outputs

Input to output isolated

High performance

•

20 Watt

DC-DC-Converter

Family IPR20 / IPS20

1:2 and 1:4 wide input voltage ranges

Very high efficiency up to 89%

IPR20: Synchronous rectifier

Low output voltage noise

Continuous no-load and short-circuit proof

IPR20: Extended ambient temperature range -40…+85‚C

2" x 2" x 0.5” case with standard pinning

Made in Switzerland, accordingly ISO 9001:2000

2 years warranty

Electromagnetic emission EN 55022 < A

Conducted and radiated emissions

24 IPR

No load input current

Switching frequency

200

Input current in shutdown condition

Output voltage accuracy

48 IPR

24 IPS

48 IPS

Standard Types

Single output

xx IPR20-03-UI

xx IPR20-05-UI

xx IPR20-03-SI

xx IPR20-05-SI

Single output

xx IPS20-03-UI

xx IPS20-05-UI

xx IPS20-12-UI

xx IPS20-15-UI

xx IPS20-24-UI

Triple output

xx IPS20-051212-UI

xx IPS20-051515-UI

Input voltage

VDC

9…36

(nominal 24)

18…75

(nominal 48)

18…36

(nominal 24)

36…75

(nominal 48)

Output 1

VDC mA

3.3

6000

4000

5000

3300

4000

1660

1330

833

2660

Output 2

VDC mA

mA typ.

200

400

kHz typ.

3 mA typ.

• 1% max.

+Vo1

+Vo2

-Vo3

Static line regulation

• 20mV • 3%

• 3% max.

Static load regulation FL to 10%

• 30mV • 3%

• 3% max.

Output voltage noise (20 MHz BW) All outputs 100 mVpp max.

Efficiency

up to 89% typ.

I/O Electric strength test voltage

1500 VDC

Coupling capacitance

1000 pF

Shutdown input (SD)

Apply -0.3…+0.6 VDC to shut down (switch off) the

output voltage(s). Normal operation with open pin.

Ambient temperature range

-U: -40…+71‚C;

-S: -40…+85‚C

;

Case temperature range

-U: -40…+95‚C

-S: -40…+105‚C

Storage temperature range

-U: -55…+105‚C;

-S: -55…+105‚C

Case material

Metal with plastic bottom cover, UL94 V-0 rated

MTBF, GB @ 40‚C case



500.000 hours

(MIL-HDBK-217F, Notice 2)

IPS20:

• 12 • 277

• 15 • 222

To complete type number replace "xx" by the required nominal

input voltage, e.g. 48 IPS20-051515-UI.

Extended ambient temperature range -40…+85‚C.

Modifications and customs are available upon request.

-40…+100‚C

Option R: Trim function for single outputs.

The output voltage can be adjusted with an external resistor in the

range of • 10%.

Dimensions in mm (inches)

Pin Configuration

Single output

+Vi

-Gi

No Pin

+Vo

Trim

Triple output

+Vi

-Gi

+Vo2

+Vo1

-Vo3

Optional Trim pin. If required add R to type number,

e.g. 24 IPS20-03-UIR.

Specifications subject to change without notice

20.07.2004
