BL
Galaxy Electrical
Dual series switching diode
FEATURES
Fast switching speed.
High conductance
Connected in series
Surface mount package ideally suited
for automatic insertion
Production specification
BAV99W
Pb
Lead-free
APPLICATIONS
For general purpose switching appilication.
SOT-323
ORDERING INFORMATION
Type No.
BAV99W
Marking
KGJ
Package Code
SOT-323
MAXIMUM RATING
@ Ta=25℃ unless otherwise specified
Parameter
Non repetitive peak reverse voltage
Repetitive peak reverse voltage
Working peak reverse voltage
DC Reverse voltage
Symbol
V
RM
V
RRM
V
RWM
V
R
1.0
2.0
300
150
200
-65-150
Value
100
Unit
V
75
V
Peak forward surge current @t=1.0s
@t=1.0μs
Forward continuous current
Average rectified output current
Power dissipation
Operating and storage temperature range
I
FSM
A
I
FM
I
O
P
d
T
j
,T
STG
mA
mA
mW
℃
Document number: BL/SSSDF007
Rev.A
www.galaxycn.com
1
BL
Galaxy Electrical
Dual series switching diode
Production specification
BAV99W
ELECTRICAL CHARACTERISTICS
@ Ta=25℃ unless otherwise specified
Parameter
Reverse voltage leakage current
Symbol
I
R
Test
V
R
=75V
V
R
=20V
I
F
=1mA
I
F
=10mA
I
F
=50mA
I
F
=150mA
V
R
=0V f=1MHz
I
F
=I
R
=10mA
V
R
=5V
R
C
=100Ω
conditions
MIN
MAX
2.5
25
715
855
1000
1250
2.0
4
UNIT
A
nA
Forward voltage
V
F
mV
Junction capacitance
Reverse recovery time
C
j
t
rr
然
pF
nS
TYPICAL CHARACTERISTICS
@ Ta=25℃ unless otherwise specified
Document number: BL/SSSDF007
Rev.A
www.galaxycn.com
2
BL
Galaxy Electrical
Dual series switching diode
PACKAGE OUTLINE
Plastic surface mounted package
Production specification
BAV99W
SOT-323
SOT-323
Dim
A
B
C
D
E
G
H
J
K
Min
1.8
1.15
0.15
0.25
1.2
0.02
2.1
Max
2.2
1.35
0.35
0.40
1.4
0.1
2.3
1.0Typical
0.1Typical
All Dimensions in mm
PACKAGE INFORMATION
Device
BAV99W
Package
SOT-323
Shipping
3000/Tape&Reel
Document number: BL/SSSDF007
Rev.A
www.galaxycn.com
3
