BAV21WS-TP-HF Overview

Rectifier Diode,

BAV21WS-TP-HF Parametric

Parameter Name	Attribute value
Is it Rohs certified?	conform to
package instruction	R-PDSO-G2
Reach Compliance Code	compliant
ECCN code	EAR99
application	GENERAL PURPOSE
Configuration	SINGLE
Diode component materials	SILICON
Diode type	RECTIFIER DIODE
Maximum forward voltage (VF)	1.25 V
JESD-30 code	R-PDSO-G2
Humidity sensitivity level	1
Maximum non-repetitive peak forward current	2.5 A
Number of components	1
Phase	1
Number of terminals	2
Maximum operating temperature	150 °C
Minimum operating temperature	-65 °C
Maximum output current	0.2 A
Package body material	PLASTIC/EPOXY
Package shape	RECTANGULAR
Package form	SMALL OUTLINE
Peak Reflow Temperature (Celsius)	260
Maximum power dissipation	0.25 W
Maximum repetitive peak reverse voltage	200 V
Maximum reverse current	0.1 µA
Maximum reverse recovery time	0.05 µs
Reverse test voltage	200 V
surface mount	YES
Terminal form	GULL WING
Terminal location	DUAL
Maximum time at peak reflow temperature	10
Base Number Matches	1

Preview

Download Datasheet

View All

MCC

Micro Commercial Components

omponents

20736 Marilla

Street Chatsworth

!"#

$ % !"#

BAV19WS

THRU

BAV21WS

250mW

Small Signal

Diodes

120 to 250 Volts

Features

•

Halogen

free available upon request by adding suffix "-HF"

Silicon Epitaxial Planar Diodes

For General Purpose

This diode is also available in other case.

Lead Free Finish/RoHS Compliant("P" Suffix

designates RoHS Compliant. See ordering information)

Mechanical Data

•

Epoxy meets UL 94 V-0 flammability rating

Moisture Sensitivity Level 1

Marking code: BAV19WS=A8

BAV20WS=T2

BAV21WS=T3

SOD-323

Maximum Ratings

Symbol

BAV19WS

BAV20WS

BAV21WS

Repetitive Peak Reverse Voltage BAV19WS

BAV20WS

BAV21WS

Non-Repetitive Peak Forward Surge Current@t=1us

@t=1s

Forward Continuous Current (Note1)

Parameters

Continuous Reverse Voltage

RRM

FSM

FRM

tot

Rth

STG

Symbol

Rating

100

150

200

120

200

250

2.5

0.5

400

Unit

Average Rectified Out put Current (Note1)

Repetitive Peak Forward Current at f>50Hz,

Tamb=25

(1)

Power Dissipation at Tamb=25

(1)

Thermal Resistance Junction to Ambient Air

Operating Junction

Temperature

Storage Temperature

Parameter

Forward Voltage

=100mA)

=200mA)

Leakage Current

=100V)

BAV19WS

(VR=100V, Tj=100

BAV19WS

=150V)

BAV20WS

(VR=150V, Tj=100

BAV20WS

=200V)

BAV21WS

(VR=200V, Tj=100 C)

BAV21WS

Capacitance

=0, f=1.0MHz)

Reverse Recovery Time

=30mA, I

=30mA)

(Irr=3.0mA, R =100OHMS)

Min

---

200

625

250

500

-65 to +150

Typ

---

1.5

Max

1.00

1.25

100

---

K/W

Units

DIM

Electrical Characteristics @ 25

C Unless Otherwise Specified

DIMENSIONS

INCHES

MIN

MAX

MIN

MAX

.090

.107

2.30

2.70

.063

.071

1.60

1.80

.045

.053

1.15

1.35

.031

.045

0.80

1.15

.010

.016

0.25

0.40

.004

.018

0.10

0.45

.004

.010

0.10

0.25

-----

.006

-----

0.15

SUGGESTED SOLDER

PAD LAYOUT

0.074"

NOTE

0.027”

tot

0.022”

---

Notes:

Valid provided that leads are kept at ambient temperature

Revision:

www.mccsemi.com

1 of 4

2013/01/01

BAV21WS-TP-HF Related Products

	BAV21WS-TP-HF	BAV19WS-TP-HF	BAV20WS-TP-HF
Description	Rectifier Diode,	Rectifier Diode,	Rectifier Diode,
Is it Rohs certified?	conform to	conform to	conform to
package instruction	R-PDSO-G2	R-PDSO-G2	R-PDSO-G2
Reach Compliance Code	compliant	compliant	compliant
ECCN code	EAR99	EAR99	EAR99
application	GENERAL PURPOSE	GENERAL PURPOSE	GENERAL PURPOSE
Configuration	SINGLE	SINGLE	SINGLE
Diode component materials	SILICON	SILICON	SILICON
Diode type	RECTIFIER DIODE	RECTIFIER DIODE	RECTIFIER DIODE
Maximum forward voltage (VF)	1.25 V	1.25 V	1.25 V
JESD-30 code	R-PDSO-G2	R-PDSO-G2	R-PDSO-G2
Humidity sensitivity level	1	1	1
Maximum non-repetitive peak forward current	2.5 A	2.5 A	2.5 A
Number of components	1	1	1
Phase	1	1	1
Number of terminals	2	2	2
Maximum operating temperature	150 °C	150 °C	150 °C
Minimum operating temperature	-65 °C	-65 °C	-65 °C
Maximum output current	0.2 A	0.2 A	0.2 A
Package body material	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY
Package shape	RECTANGULAR	RECTANGULAR	RECTANGULAR
Package form	SMALL OUTLINE	SMALL OUTLINE	SMALL OUTLINE
Peak Reflow Temperature (Celsius)	260	260	260
Maximum power dissipation	0.25 W	0.25 W	0.25 W
Maximum repetitive peak reverse voltage	200 V	100 V	150 V
Maximum reverse current	0.1 µA	0.1 µA	0.1 µA
Maximum reverse recovery time	0.05 µs	0.05 µs	0.05 µs
Reverse test voltage	200 V	100 V	150 V
surface mount	YES	YES	YES
Terminal form	GULL WING	GULL WING	GULL WING
Terminal location	DUAL	DUAL	DUAL
Maximum time at peak reflow temperature	10	10	10
Base Number Matches	1	1	1
