PH1214-55EL
Radar Pulsed Power Transistor
55W, 1.2-1.4 GHz, 1ms Pulse, 10% Duty
Features
•
•
•
•
•
•
•
•
•
NPN silicon microwave power transistors
Common base configuration
Broadband Class C operation
High efficiency inter-digitized geometry
Diffused emitter ballasting resistors
Gold metallization system
Internal input and output impedance matching
Hermetic metal/ceramic package
RoHS compliant
M/A-COM Products
Released, 30 May 07
Outline Drawing
Absolute Maximum Ratings at 25°C
Parameter
Collector-Emitter Voltage
Emitter-Base Voltage
Collector Current (Peak)
Power Dissipation @ +25°C
Storage Temperature
Junction Temperature
Symbol
V
CES
V
EBO
I
C
P
TOT
T
STG
T
J
Rating
58
3.0
7.0
220
-65 to +200
200
Units
V
V
A
W
°C
°C
Electrical Specifications: T
C
= 25 ± 5°C (
Room Ambient
)
Parameter
Test Conditions
Frequency
Symbol
BV
CES
I
CES
F = 1.2, 1.3, 1.4 GHz
F = 1.2, 1.3, 1.4 GHz
F = 1.2, 1.3, 1.4 GHz
F = 1.2, 1.3, 1.4 GHz
F = 1.2, 1.3, 1.4 GHz
F = 1.2, 1.3, 1.4 GHz
F = 1.2, 1.3, 1.4 GHz
R
TH(JC)
P
OUT
G
P
Min
58
-
-
55
6.6
50
-
-
-
Max
-
6.0
0.8
-
-
-
-10
3:1
1.5:1
Units
V
mA
°C/W
W
dB
%
dB
-
-
Collector-Emitter Breakdown Voltage I
C
= 120mA
Collector-Emitter Leakage Current
Thermal Resistance
Output Power
Power Gain
Collector Efficiency
Input Return Loss
Load Mismatch Tolerance
Load Mismatch Stability
V
CE
= 28V
Vcc = 28V, Pin = 12W
Vcc = 28V, Pin = 12W
Vcc = 28V, Pin = 12W
Vcc = 28V, Pin = 12W
Vcc = 28V, Pin = 12W
Vcc = 28V, Pin = 12W
Vcc = 28V, Pin = 12W
η
C
RL
VSWR-T
VSWR-S
1
ADVANCED:
Data Sheets contain information regarding a product M/A-COM is considering for
•
North America
Tel: 800.366.2266 / Fax: 978.366.2266
development. Performance is based on target specifications, simulated results, and/or prototype
•
Europe
Tel: 44.1908.574.200 / Fax: 44.1908.574.300
measurements. Commitment to develop is not guaranteed.
•
Asia/Pacific
Tel: 81.44.844.8296 / Fax: 81.44.844.8298
PRELIMINARY:
Data Sheets contain information regarding a product M/A-COM has under develop-
Visit www.macom.com for additional data sheets and product information.
ment. Performance is based on engineering tests. Specifications are typical. Mechanical outline has
been fixed. Engineering samples and/or test data may be available. Commitment to produce in
M/A-COM Inc. and its affiliates reserve the right to make changes to the product(s) or
volume is not guaranteed.
information contained herein without notice.
PH1214-55EL
Radar Pulsed Power Transistor
55W, 1.2-1.4 GHz, 1ms Pulse, 10% Duty
RF Test Fixture Impedance
F (GHz)
1.2
1.3
1.4
M/A-COM Products
Released, 30 May 07
Z
IF
(Ω)
5.8 + j1.8
2.4 + j1.3
2.4 + j0.6
Z
OF
(Ω)
5.5 - j3.4
3.3 - j2.3
2.0 - j2.3
Test Fixture Circuit Dimensions
Test Fixture Assembly
2
