SB1620D-T3-LF

Description
Rectifier Diode, Schottky, 1 Phase, 1 Element, 16A, 20V V(RRM), Silicon, TO-263AB, TO-263, D2PAK-3/2
CategoryDiscrete semiconductor    diode
File Size44KB，4 Pages
ManufacturerWon-Top Electronics Co., Ltd.
Websitehttps://www.wontop.com/
Download Datasheet Parametric Compare View All

SB1620D-T3-LF Overview

Rectifier Diode, Schottky, 1 Phase, 1 Element, 16A, 20V V(RRM), Silicon, TO-263AB, TO-263, D2PAK-3/2

SB1620D-T3-LF Parametric

Parameter NameAttribute value
package instructionR-PSSO-G2
Reach Compliance Codecompliant
ECCN codeEAR99
Other featuresFREE WHEELING DIODE, LOW POWER LOSS
applicationEFFICIENCY
Shell connectionCATHODE
ConfigurationSINGLE
Diode component materialsSILICON
Diode typeRECTIFIER DIODE
Maximum forward voltage (VF)0.63 V
JEDEC-95 codeTO-263AB
JESD-30 codeR-PSSO-G2
Maximum non-repetitive peak forward current150 A
Number of components1
Phase1
Number of terminals2
Maximum operating temperature150 °C
Minimum operating temperature-55 °C
Maximum output current16 A
Package body materialPLASTIC/EPOXY
Package shapeRECTANGULAR
Package formSMALL OUTLINE
Maximum repetitive peak reverse voltage20 V
Maximum reverse current500 µA
surface mountYES
technologySCHOTTKY
Terminal formGULL WING
Terminal locationSINGLE
Base Number Matches1

Preview

Download Datasheet
®
SB1620D – SB16100D
16A SURFACE MOUNT SCHOTTKY BARRIER RECTIFIER
WON-TOP ELECTRONICS
Pb
Features
Schottky Barrier Chip
Guard Ring for Transient Protection
Low Forward Voltage Drop
Low Power Loss, High Efficiency
High Surge Current Capability
Epoxy Meet UL 94V-0 Classification
For Use in Low Voltage, High Frequency
Inverters, Free Wheeling, and Switching
Power Supplies
A
C
J
B
D
PIN 1
2
3
E
G
H
K
P
P
2
Mechanical Data
Case: D
2
PAK/TO-263, Molded Plastic
Terminals: Plated Leads Solderable per
MIL-STD-202, Method 208
Polarity: See Diagram
Weight: 1.7 grams (approx.)
Mounting Position: Any
Marking: Type Number
Lead Free: For RoHS / Lead Free Version,
Add “-LF” Suffix to Part Number, See Page 4
D PAK/TO-263
Dim
Min
Max
A
B
C
D
9.80
9.60
4.40
8.50
—
1.00
—
1.20
0.30
2.35
10.40
10.60
4.80
9.10
2.80
1.40
0.99
1.40
0.70
2.75
PIN 1
PIN 3
Case, PIN 2
E
G
H
J
K
P
All Dimensions in mm
Maximum Ratings and Electrical Characteristics
@T
A
=25°C unless otherwise specified
Single Phase, half wave, 60Hz, resistive or inductive load. For capacitive load, derate current by 20%.
SB
SB
SB
SB
SB
SB
SB
SB
1620D 1630D 1640D 1645D 1650D 1660D 1680D
16100D
20
14
30
21
40
28
45
32
16
150
0.63
0.57
0.5
20
500
73
2.0
-55 to +150
350
0.75
0.65
0.85
0.75
50
35
60
42
80
56
100
70
Characteristic
Peak Repetitive Reverse Voltage
Working Peak Reverse Voltage
DC Blocking Voltage
RMS Reverse Voltage
Average Rectified Output Current
@T
C
= 100°C
Symbol
V
RRM
V
RWM
V
R
V
R(RMS)
I
O
I
FSM
Unit
V
V
A
A
Non-Repetitive Peak Forward Surge Current
8.3ms Single Half Sine-Wave Superimposed
on Rated Load (JEDEC Method)
Forward Voltage
@I
F
= 16A, T
J
= 25°C
@I
F
= 16A, T
J
= 125°C
@T
J
= 25°C
@T
J
= 100°C
V
FM
I
RM
C
J
R
θJA
R
θJC
T
J
, T
STG
V
mA
pF
°C/W
°C
Peak Reverse Current
At Rated DC Blocking Voltage
Typical Junction Capacitance (Note 1)
Thermal Resistance Junction to Ambient (Note 2)
Thermal Resistance Junction to Case (Note 2)
Operating and Storage Temperature Range
Note: 1. Measured at 1.0 MHz and applied reverse voltage of 4.0V D.C.
2. Mounted on FR-4 PCB with minimum recommended pad size.
© Won-Top Electronics Co., Ltd.
Revision: September, 2012
www.wontop.com
1
