MK60N256VMC100: DescriptionFLASH, 100MHz, RISC MICROCONTROLLER, PBGA121, 8 X 8 MM, MAPBGA-121; CategoryThe embedded processor and controller Microcontrollers and processors; File Size2MB，72 Pages; ManufacturerNXP; Websitehttps://www.nxp.com

Download Datasheet Parametric Compare View All

MK60N256VMC100 Overview

FLASH, 100MHz, RISC MICROCONTROLLER, PBGA121, 8 X 8 MM, MAPBGA-121

MK60N256VMC100 Parametric

Parameter Name	Attribute value
Parts packaging code	BGA
package instruction	BGA, BGA121,11X11,25
Contacts	121
Reach Compliance Code	unknown
ECCN code	3A001.A.3
Has ADC	YES
Address bus width
bit size	32
CPU series	CORTEX-M4
maximum clock frequency	50 MHz
DAC channel	YES
DMA channel	YES
External data bus width
JESD-30 code	S-PBGA-B121
Number of I/O lines	90
Number of terminals	121
Maximum operating temperature	105 °C
Minimum operating temperature	-40 °C
PWM channel	YES
Package body material	PLASTIC/EPOXY
encapsulated code	BGA
Encapsulate equivalent code	BGA121,11X11,25
Package shape	SQUARE
Package form	GRID ARRAY
power supply	1.8/3.3 V
Certification status	Not Qualified
RAM (bytes)	65536
rom(word)	262144
ROM programmability	FLASH
speed	100 MHz
Maximum supply voltage	3.6 V
Minimum supply voltage	1.71 V
Nominal supply voltage	3.3 V
surface mount	YES
technology	CMOS
Temperature level	INDUSTRIAL
Terminal form	BALL
Terminal pitch	0.635 mm
Terminal location	BOTTOM
uPs/uCs/peripheral integrated circuit type	MICROCONTROLLER, RISC
Base Number Matches	1

Preview

Download Datasheet

View All

Freescale Semiconductor

Data Sheet: Product Preview

Document Number: K60P121M100SF2

Rev. 4, 3/2011

Supports the following:

MK60N256VMC100,

MK60X256VMC100,

MK60N512VMC100

K60 Sub-Family Data Sheet

K60P121M100SF2

Features

• Operating Characteristics

– Voltage range: 1.71 to 3.6 V

– Flash write voltage range: 1.71 to 3.6 V

– Temperature range (ambient): -40 to 105°C

• Performance

– Up to 100 MHz ARM Cortex-M4 core with DSP

instructions delivering 1.25 Dhrystone MIPS per

MHz

• Memories and memory interfaces

– Up to 512 KB program flash memory on non-

FlexMemory devices

– Up to 256 KB program flash memory on

FlexMemory devices

– Up to 256 KB FlexNVM on FlexMemory devices

– 4 KB FlexRAM on FlexMemory devices

– Up to 128 KB RAM

– Serial programming interface (EzPort)

– FlexBus external bus interface

• Clocks

– 3 to 32 MHz crystal oscillator

– 32 kHz crystal oscillator

– Multi-purpose clock generator

• System peripherals

– 10 low-power modes to provide power optimization

based on application requirements

– Memory protection unit with multi-master

protection

– 16-channel DMA controller, supporting up to 64

request sources

– External watchdog monitor

– Software watchdog

– Low-leakage wakeup unit

• Security and integrity modules

– Hardware CRC module to support fast cyclic

redundancy checks

– Hardware random-number generator

– Hardware encryption supporting DES, 3DES, AES,

MD5, SHA-1, and SHA-256 algorithms

– 128-bit unique identification (ID) number per chip

• Human-machine interface

– Low-power hardware touch sensor interface (TSI)

– General-purpose input/output

• Analog modules

– Two 16-bit SAR ADCs

– Programmable gain amplifier (up to x64) integrated

into each ADC

– Two 12-bit DACs

– Three analog comparators (CMP) containing a 6-bit

DAC and programmable reference input

– Voltage reference

• Timers

– Programmable delay block

– Eight-channel motor control/general purpose/PWM

timer

– Two 2-channel quadrature decoder/general purpose

timers

– IEEE 1588 timers

– Periodic interrupt timers

– 16-bit low-power timer

– Carrier modulator transmitter

– Real-time clock

This document contains information on a product under development. Freescale

reserves the right to change or discontinue this product without notice.

Preliminary

Table of Contents

1 Ordering parts...........................................................................5

1.1 Determining valid orderable parts......................................5

2 Part identification......................................................................5

2.1 Description.........................................................................5

2.2 Format...............................................................................5

2.3 Fields.................................................................................5

2.4 Example............................................................................6

3 Terminology and guidelines......................................................6

3.1 Definition: Operating requirement......................................6

3.2 Definition: Operating behavior...........................................7

3.3 Definition: Attribute............................................................7

3.4 Definition: Rating...............................................................8

3.5 Result of exceeding a rating..............................................8

3.6 Relationship between ratings and operating

requirements......................................................................8

3.7 Guidelines for ratings and operating requirements............9

3.8 Definition: Typical value.....................................................9

3.9 Typical value conditions....................................................10

4 Ratings......................................................................................10

4.1 Thermal handling ratings...................................................11

4.2 Moisture handling ratings..................................................11

4.3 ESD handling ratings.........................................................11

4.4 Voltage and current operating ratings...............................11

5 General.....................................................................................12

5.1 Nonswitching electrical specifications...............................12

5.1.1

5.1.2

5.1.3

5.1.4

5.1.5

5.1.6

5.1.7

5.1.8

Voltage and current operating requirements......12

LVD and POR operating requirements...............13

Voltage and current operating behaviors............14

Power mode transition operating behaviors.......14

Power consumption operating behaviors............15

EMC radiated emissions operating behaviors....18

Designing with radiated emissions in mind.........19

Capacitance attributes........................................19

6.8.8

6.8.9

6.8.10

6.8.11

6.8.7

6 Peripheral operating requirements and behaviors....................21

6.1 Core modules....................................................................22

6.1.1

6.1.2

Debug trace timing specifications.......................22

JTAG electricals..................................................22

6.2 System modules................................................................26

6.3 Clock modules...................................................................26

6.3.1

6.3.2

6.3.3

MCG specifications.............................................26

Oscillator electrical specifications.......................28

32kHz Oscillator Electrical Characteristics.........30

6.4 Memories and memory interfaces.....................................31

6.4.1

6.4.2

6.4.3

Flash (FTFL) electrical specifications.................31

EzPort Switching Specifications.........................35

Flexbus Switching Specifications........................36

6.5 Security and integrity modules..........................................39

6.6 Analog...............................................................................39

6.6.1

6.6.2

6.6.3

6.6.4

ADC electrical specifications..............................39

CMP and 6-bit DAC electrical specifications......47

12-bit DAC electrical characteristics...................50

Voltage reference electrical specifications..........53

6.7 Timers................................................................................54

6.8 Communication interfaces.................................................54

6.8.1

6.8.2

6.8.3

6.8.4

6.8.5

6.8.6

Ethernet switching specifications........................55

USB electrical specifications...............................56

USB DCD electrical specifications......................56

USB VREG electrical specifications...................57

CAN switching specifications..............................57

DSPI switching specifications (low-speed

mode)..................................................................58

DSPI switching specifications (high-speed

mode)..................................................................59

I2C switching specifications................................61

UART switching specifications............................61

SDHC specifications...........................................61

I2S switching specifications................................62

5.2 Switching specifications.....................................................19

5.2.1

5.2.2

Device clock specifications.................................19

General switching specifications.........................20

6.9 Human-machine interfaces (HMI)......................................64

6.9.1

TSI electrical specifications................................64

5.3 Thermal specifications.......................................................21

5.3.1

5.3.2

Thermal operating requirements.........................21

Thermal attributes...............................................21

7 Dimensions...............................................................................65

7.1 Obtaining package dimensions.........................................65

8 Pinout........................................................................................65

K60 Sub-Family Data Sheet Data Sheet, Rev. 4, 3/2011.

Freescale Semiconductor, Inc.

Preliminary

MK60N256VMC100 Related Products

	MK60N256VMC100	MK60N256VMC100R	MK60N512VMC100	MK60N512VMC100R	MK60X256VMC100R
Description	FLASH, 100MHz, RISC MICROCONTROLLER, PBGA121, 8 X 8 MM, MAPBGA-121	FLASH, 100 MHz, RISC MICROCONTROLLER, PBGA121, 8 X 8 MM, MAPBGA-121	FLASH, 100MHz, RISC MICROCONTROLLER, PBGA121, 8 X 8 MM, MAPBGA-121	FLASH, 100 MHz, RISC MICROCONTROLLER, PBGA121, 8 X 8 MM, MAPBGA-121	FLASH, 100 MHz, RISC MICROCONTROLLER, PBGA121, 8 X 8 MM, MAPBGA-121
Parts packaging code	BGA	BGA	BGA	BGA	BGA
package instruction	BGA, BGA121,11X11,25	BGA, BGA121,11X11,25	BGA, BGA121,11X11,25	BGA, BGA121,11X11,25	BGA, BGA121,11X11,25
Contacts	121	121	121	121	121
Reach Compliance Code	unknown	unknown	unknown	unknown	unknown
ECCN code	3A001.A.3	3A001.A.3	3A001.A.3	3A001.A.3	3A001.A.3
Has ADC	YES	YES	YES	YES	YES
bit size	32	32	32	32	32
CPU series	CORTEX-M4	CORTEX-M4	CORTEX-M4	CORTEX-M4	CORTEX-M4
maximum clock frequency	50 MHz	50 MHz	50 MHz	50 MHz	50 MHz
DAC channel	YES	YES	YES	YES	YES
DMA channel	YES	YES	YES	YES	YES
JESD-30 code	S-PBGA-B121	S-PBGA-B121	S-PBGA-B121	S-PBGA-B121	S-PBGA-B121
Number of I/O lines	90	90	90	90	90
Number of terminals	121	121	121	121	121
Maximum operating temperature	105 °C	105 °C	105 °C	105 °C	105 °C
Minimum operating temperature	-40 °C	-40 °C	-40 °C	-40 °C	-40 °C
PWM channel	YES	YES	YES	YES	YES
Package body material	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY
encapsulated code	BGA	BGA	BGA	BGA	BGA
Encapsulate equivalent code	BGA121,11X11,25	BGA121,11X11,25	BGA121,11X11,25	BGA121,11X11,25	BGA121,11X11,25
Package shape	SQUARE	SQUARE	SQUARE	SQUARE	SQUARE
Package form	GRID ARRAY	GRID ARRAY	GRID ARRAY	GRID ARRAY	GRID ARRAY
power supply	1.8/3.3 V	1.8/3.3 V	1.8/3.3 V	1.8/3.3 V	1.8/3.3 V
Certification status	Not Qualified	Not Qualified	Not Qualified	Not Qualified	Not Qualified
RAM (bytes)	65536	65536	131072	131072	65536
rom(word)	262144	262144	524288	524288	262144
ROM programmability	FLASH	FLASH	FLASH	FLASH	FLASH
speed	100 MHz	100 MHz	100 MHz	100 MHz	100 MHz
Maximum supply voltage	3.6 V	3.6 V	3.6 V	3.6 V	3.6 V
Minimum supply voltage	1.71 V	1.71 V	1.71 V	1.71 V	1.71 V
Nominal supply voltage	3.3 V	3.3 V	3.3 V	3.3 V	3.3 V
surface mount	YES	YES	YES	YES	YES
technology	CMOS	CMOS	CMOS	CMOS	CMOS
Temperature level	INDUSTRIAL	INDUSTRIAL	INDUSTRIAL	INDUSTRIAL	INDUSTRIAL
Terminal form	BALL	BALL	BALL	BALL	BALL
Terminal pitch	0.635 mm	0.635 mm	0.635 mm	0.635 mm	0.635 mm
Terminal location	BOTTOM	BOTTOM	BOTTOM	BOTTOM	BOTTOM
uPs/uCs/peripheral integrated circuit type	MICROCONTROLLER, RISC	MICROCONTROLLER, RISC	MICROCONTROLLER, RISC	MICROCONTROLLER, RISC	MICROCONTROLLER, RISC
Maker	-	-	NXP	NXP	NXP

Recommended Resources

Pulse shaping circuit b composed of Schmitt shaping integrated circuit

MZ1812 application circuit

How to teach how to install a good voice control circuit

Little Swan CXW-180-99A two-wheel type range hood circuit diagram

Electromagnetic braking control

Household electronic disinfection cabinet circuit

Shortcut: L0 L1 L2 L3 L4 L5 L6 L7 L8 L9 LA LB LC LD LE LF LG LH LI LJ LK LL LM LN LO LP LQ LR LS LT LU LV LW LX LY LZ M0 M1 M2 M3 M4 M5 M6 M7 M8 M9 MA MB MC MD ME MF MG MH MI MJ MK ML MM MN MO MP MQ MR MS MT MU MV MW MX MY MZ N0 N1 N2 N3 N4 N5 N6 N7 N8 NA NB NC ND NE NF NG NH NI NJ NK NL NM NN NO NP NQ NR NS NT NU NV NX NZ O0 O1 O2 O3 OA OB OC OD OE OF OG OH OI OJ OK OL OM ON OP OQ OR OS OT OV OX OY OZ P0 P1 P2 P3 P4 P5 P6 P7 P8 P9 PA PB PC PD PE PF PG PH PI PJ PK PL PM PN PO PP PQ PR PS PT PU PV PW PX PY PZ Q1 Q2 Q3 Q4 Q5 Q6 Q8 Q9 QA QB QC QE QF QG QH QK QL QM QP QR QS QT QV QW QX QY R0 R1 R2 R3 R4 R5 R6 R7 R8 R9 RA RB RC RD RE RF RG RH RI RJ RK RL RM RN RO RP RQ RR RS RT RU RV RW RX RY RZ

Popular Components
