CAM-C3188A
Sept. 2004
1/3 ” Color Camera Module with Digital Output
The CAM-C3188A is a 1/3” color camera module with digital
output. It uses OmniVision ’s CMOS image sensor Ov7620.
Combining CMOS technology together with an easy to use
digital interface makes CAM-C3188A a low cost solution for
higher quality video image application. The digital video port
supplies a continuous 8/16 bit-wide image data stream. All
camera functions,such as exposure, gamma,gain,white
balance,color matrix,windowing,are programmable through
Specification
Imager
Pixels
Array Size
Pixel size
Scanning
8/16 bit video data
Data format
A/D converter
Synchronization
Effective image area
Exposure
Electronic Exposure
Gamma Correction
S/N Ratio
Min Illumination
Operation Voltage
Operation Current
Lens (Optional)
Size
Interface
Image enhancement
Applications
OV7620, CMOS image sensor
326688 pixels, VGA/CIF
Video Conferencing
664 × 492 pixels
PC Multimedia
7.6 × 7.6 µm
Video Phone
Progressive / interlace
Video Mail
CCIR601, CCIR656, ZV port
Still Image
-YCrCb 4:2:2, GRB 4:2:2, RGB
Machine Vision
Built in 10bit 2 ch A/D converter
Process control
Internal / external
4.86mm × 3.64mm
Frame exposure / line exposure option
Electronic exposure / Gain / White balance control
500:1
128 curve settings
>48dB
2.5Lux, F1.4
5 VDC
120mW Active / 10µW Standby
f6mm, F1.6
40 mm x 28 mm
I2C interface
brightness, contrast, gamma, saturation, sharpness, window, etc.
Monochrome composite video signal output 50Hz
Pin Description
1–8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23 –30
31
32
Y0 – Y7
PWDN
RST
SDA
FODD
SCL
HREF
AGND
VSYN
AGND
PCLK
EXCLK
VCC
AGND
VCC
UV0 – UV7
GND
VTO
Digital output Y Bus
Power down mode
Reset
I2C Serial data
Odd Field flag
I2C Serial clock input
Horizontal window reference output
Analog Ground
Vertical Sync output
Analog Ground
Pixel clock output
External clock input (remove crystal)
Power Supply 5VDC
Analog Ground
Power Supply 5VDC
Digital output UV bus
Common Ground
Video Analog Output (75 Ohm monochrome)
PCB Layout (Top view)
For programming see OV7620 datasheet
