Voltage Controlled Oscillator
Linear Tuning
Features
Surface Mount
JTOS-535+
JTOS-535
300 to 525 MHz
• wide frequency range, 300 to 525 MHz
• linear tuning characteristics
• excellent harmonic suppression, -28 dBc typ.
• low phase noise, -137 dBc/Hz at 1 MHz offset
• aqueous washable
CASE STYLE: BK377
PRICE: $15.95 ea. QTY (5-49)
Applications
+ RoHS compliant in accordance
with EU Directive (2002/95/EC)
The +Suffix identifies RoHS Compliance. See our web site
for RoHS Compliance methodologies and qualifications.
• VHF/UHF
• instrumentation
• signal generators
FREQUENCY POWER TUNING
(MHz)
OUTPUT VOLTAGE
(dBm)
(V)
Electrical Specifications
PHASE NOISE
(dBc/Hz)
SSB at offset frequencies:
Typ.
1
kHz
-75
10
kHz
-97
100
kHz
-117
1
MHz
-137
PULLING PUSHING
TUNING
HARMONICS
3 dB
pk-pk
(MHz/V) SENSITIVITY
(dBc)
MODULATION
@ 12 dBr
(MHz/V)
BANDWIDTH
(MHz)
(MHz)
DC
OPERATING
POWER
Current
(mA)
Max.
20
Min.
300
Max.
525
Typ.
+9.5
Min.
1
Max.
16
Typ.
2.0
Typ.
0.5
Typ.
10-24
Typ.
-28
Max.
-20
Typ.
0.115
Vcc
(volts)
12
Pin Connections
RF OUT
VCC
V-TUNE
GROUND
13
2
5
1,3,4,6,7,8,9,10,11,12,14
Maximum Ratings
Operating Temperature
Storage Temperature
Absolute Max. Supply Voltage (Vcc)
Absolute Max. Tuning Voltage (Vtune)
all specifications: 50 ohm system
-55°C to 85°C
-55°C to 100°C
+16V
+18V
Outline Drawing
Demo Board MCL P/N: TB-04
Suggested PCB Layout (PL-005)
PCB Land Pattern
Suggested Layout,
Tolerance to be within
±
.002
Outline Dimensions (
inch
)
mm
A
.505
12.83
B
.800
20.32
C
--
--
D
.100
2.54
E
.250
6.35
F
.100
2.54
G
.100
2.54
H
.047
1.19
J
.065
1.65
K
.065
1.65
L
wt
.525 grams
3.0
13.34
Mini-Circuits
ISO 9001 ISO 14001
CERTIFIED
RF/IF MICROWAVE COMPONENTS
®
minicircuits.com
EW
ALL N
P.O. Box 350166, Brooklyn, New York 11235-0003 (718) 934-4500 Fax (718) 332-4661 For detailed performance specs & shopping online see Mini-Circuits web site
The Design Engineers Search Engine
Provides ACTUAL Data Instantly From MINI-CIRCUITS At:
www.minicircuits.com
REV. B
M102713
JTOS-535
ED-3891/2
MM/TD/CP
071219
Page 1 of 2
Performance Data & Curves
V
TUNE
TUNING
SENS.
(MHz/V)
31.50
26.00
20.90
20.90
17.80
16.20
16.80
23.90
20.30
18.00
16.30
11.90
16.80
19.60
17.30
14.60
FREQUENCY (MHz)
-55°C
285.03
310.18
331.32
352.76
370.65
386.75
402.92
427.07
446.98
464.80
480.78
490.28
511.07
531.23
548.65
563.30
+25°C
278.90
304.90
325.80
346.70
364.50
380.70
397.50
421.30
441.60
459.60
476.00
487.90
504.80
524.40
541.70
556.30
+85°C
274.76
301.16
321.53
341.31
358.75
374.87
393.16
416.08
436.50
454.75
471.03
483.67
500.43
519.33
536.06
550.38
POWER OUTPUT (dBm)
-55°C
8.25
8.55
8.49
8.61
8.76
8.70
8.12
7.81
7.73
7.80
7.78
7.40
6.94
7.04
7.34
7.41
+25°C
8.38
8.95
9.23
9.35
9.43
9.37
8.91
8.00
8.53
8.51
8.49
8.25
7.76
7.73
7.96
8.08
+85°C
8.25
8.94
9.33
9.47
9.49
9.34
9.07
8.91
8.63
8.55
8.56
8.35
8.08
7.95
8.11
8.21
JTOS-535+
JTOS-535
JTOS-535
Frequency and Tuning Sensitivity (at +25°C)
700
600
Frequency (MHz)
500
400
300
200
100
0
1
4
7
10
13
16
Tuning Voltage (V)
-55°C
+25°C
+85°C
T SENS.
80
70
60
50
40
30
20
10
Tuning Sensitivity
(MHz/V)
Output Power (dBm)
1.00
2.00
3.00
4.00
5.00
6.00
7.00
8.00
9.00
10.00
11.00
12.00
13.00
14.00
15.00
16.00
JTOS-535
Power Output
12
-55°C
+25°C
+85°C
11
10
9
8
7
1
4
7
10
Tuning Voltage (V)
13
16
V
TUNE
1.00
2.00
3.00
4.00
5.00
6.00
7.00
8.00
9.00
10.00
1
4
7
10
Tuning Voltage (V)
13
16
HARMONICS (dBc)
F2
-26.60
-30.90
-35.30
-38.40
-41.50
-43.30
-45.70
-43.70
-41.60
-39.90
-38.30
-37.60
-37.90
-34.50
-32.70
-29.50
F3
-37.30
-41.30
-40.90
-41.90
-40.00
-36.90
-37.10
-37.40
-40.10
-42.70
-43.30
-42.50
-40.00
-36.70
-35.20
-33.20
F4
-34.10
-33.70
-35.40
-37.00
-41.00
-43.60
-38.60
-35.80
-36.20
-39.70
-35.70
-32.10
-32.60
-33.10
-34.00
-41.10
FREQ. PUSHING
(MHz/V)
0.97
0.64
0.97
0.41
0.07
-0.36
1.04
0.35
-0.14
-0.23
-0.37
-0.58
0.93
0.73
0.38
0.12
JTOS-535
Harmonics Level
-10
F2
F3
F4
JTOS-535
Frequency Pushing
(Supply Voltage 12V)
1.5
Pushing (MHz/V)
1.0
0.5
0.0
-0.5
-1.0
1
4
7
10
Tuning Voltage (V)
13
16
Harmonics (dBc)
-20
-30
-40
-50
-60
11.00
12.00
13.00
14.00
15.00
16.00
Mini-Circuits
ISO 9001 ISO 14001
CERTIFIED
RF/IF MICROWAVE COMPONENTS
®
minicircuits.com
EW
ALL N
P.O. Box 350166, Brooklyn, New York 11235-0003 (718) 934-4500 Fax (718) 332-4661 For detailed performance specs & shopping online see Mini-Circuits web site
The Design Engineers Search Engine
Provides ACTUAL Data Instantly From MINI-CIRCUITS At:
www.minicircuits.com
page 2 of 2
