STK433-760-E Overview

IC AUDIO AMPLIFIER, Audio/Video Amplifier

STK433-760-E Parametric

Parameter Name	Attribute value
Is it Rohs certified?	conform to
Reach Compliance Code	compliant
ECCN code	EAR99
Commercial integrated circuit types	AUDIO AMPLIFIER
JESD-609 code	e2
Terminal surface	Tin/Nickel/Copper (Sn/Ni/Cu)
Base Number Matches	1

Preview

Download Datasheet

View All

Ordering number : EN*A1476A

Thick-Film Hybrid IC

STK433-760-E

Overview

2-channel class AB audio power IC,

50W+50W

The STK433-760-E is a hybrid IC designed to be used in 50W

50W (2-channel) class AB audio power amplifiers.

Applications

•

Audio power amplifiers.

Features

•

Miniature package (47.0mm

25.6mm

9.0mm)

•

Output load impedance: RL = 6Ω to 4Ω supported

•

Built-in stand-by circuit, output limiting circuit for substrate overheating, and load short-circuit protection

circuit constituted by monolithic ICs

Series Models

STK433-730-E

Output 1 (10%/1kHz)

Output 2 (0.4%/20Hz to 20kHz)

Max. rated VCC (quiescent)

Max. rated VCC (6Ω)

Max. rated VCC (4Ω)

Recommended operating VCC (4Ω)

Dimensions (excluding pin height)

30W×2 channels

15W×2 channels

±30V

±28V

±25V

±18V

47.0mm×25.6mm×9.0mm

STK433-760-E

50W×2 channels

35W×2 channels

±50V

±40V

±33V

±23V

Any and all SANYO Semiconductor Co.,Ltd. products described or contained herein are, with regard to

"standard application", intended for the use as general electronics equipment (home appliances, AV equipment,

communication device, office equipment, industrial equipment etc.). The products mentioned herein shall not be

intended for use for any "special application" (medical equipment whose purpose is to sustain life, aerospace

instrument, nuclear control device, burning appliances, transportation machine, traffic signal system, safety

equipment etc.) that shall require extremely high level of reliability and can directly threaten human lives in case

of failure or malfunction of the product or may cause harm to human bodies, nor shall they grant any guarantee

thereof. If you should intend to use our products for applications outside the standard applications of our

customer who is considering such use and/or outside the scope of our intended standard applications, please

consult with us prior to the intended use. If there is no consultation or inquiry before the intended use, our

customer shall be solely responsible for the use.

Specifications of any and all SANYO Semiconductor Co.,Ltd. products described or contained herein stipulate

the performance, characteristics, and functions of the described products in the independent state, and are not

guarantees of the performance, characteristics, and functions of the described products as mounted in the

customer

s products or equipment. To verify symptoms and states that cannot be evaluated in an independent

device, the customer should always evaluate and test devices mounted in the customer

s products or

equipment.

O2109HKIM/52709HKIM No. A1476-1/12

STK433-760-E

[Remarks]

*1:

Maximum ratings are limits beyond which damage to the device may occur.

Exceeding the maximum ratings, even momentarily, may cause damage to the hybrid IC.

In SANYO Semiconductor's test processes, operation at the maximum supply voltage is checked.

(Test conditions) VCC max (2)=±33V, RL=4Ω, f=1kHz, Po=35W, 1ch Drive, ton=25ms, Tc=25°C

*2:

For 1-channel operation

*3:

-Pre VCC (pin 7) must be connected to the lowest stable potential to prevent the current flowing into the pin 1 due to

reverse bias, etc.

*4:

Thermal design must be implemented based on the conditions under which the customer’s end products are expected

to operate on the market.

*5:

Use the hybrid IC so that the voltage applied to the stand-by pin (pin 13) never exceeds the maximum rating. The

power amplifier is turned on by applying +2.5V to +5.5V to the stand-by pin (pin 13).

*6:

An output limiting circuit for H-IC overheating is incorporated to protect the hybrid IC from the heat generation

exceeding the maximum rating. Thermal design must be implemented from the maximum loss Pd max and "Pd-Tc"

derating curve based on the conditions under which the customer's end products are expected to operate on the

market. When deviating from the "Pd-Tc" derating curve, the desired output is not obtained, but the prescribed

output is generated again by reducing H-IC temperature to within the recommended operating region.

*7:

The load short-circuit protection is designed based on the specification test condition.

The load short-circuit protection circuit is activated when it has detected an overcurrent in the output transistors. So

if any deviation from the "Pd-Tc" derating curve occurs, the protection circuit is activated and the circuit shuts down

in order to protect the output transistors. When the load short-circuit protection circuit has been activated and the

circuit shuts down, approximately +5.5V of voltage will be placed at the MONITOR pin (pin 10) (normally 0V).

The protection circuit operation is released by establishing the stand-by mode (pin 13: 0V).

*8:

The substrate temperature protection rating is the design guarantee value using the specification test circuit of

SANYO Semiconductor.

The output limiting circuit for H-IC overheating (*6) and the load short-circuit protection circuit (*7) are the only

protection functions incorporated.

The thermal design and overcurrent protection level must be verified based on the conditions under which the

customer's end products are expected to operate on the market.

*9:

A thermoplastic adhesive resin is used to secure the case and aluminum substrate. For this reason, the hybrid IC

must be fixed to the heat sink before soldering and mounted. The heat sink must be installed or removed at room

temperature.

*10:

Use the designated transformer power supply circuit shown in the figure below for the measurement of allowable

load shorted time and output noise voltage level.

*11:

Weight of independent hybrid IC: 12.2g

Outer box dimensions: 452(D)

325(W)

192(H) mm

DBA40C

10000μF

+VCC

500Ω

-VCC

10000μF

Designated transformer power supply

(MG-200 equivalent)

No. A1476-3/12
