2x3mm RECTANGULAR SOLID LAMP
W169XPGTL
PURE
GREEN
Features
!
LOW
Description
The Pure Green source color devices are made with
Gallium Phosphide Pure Green Light Emitting Diode.
POWER CONSUMPTION.
BRIGHTNESS IS AVAILABLE .
AND RUGGED.
UNIFORMITY OF LIGHT OUTPUT.
!
ULTRA
!
RELIABLE
!
EXCELLENT
!
SUITABLE
!
LONG
FOR LEVEL INDICATOR.
LIFE - SOLID STATE RELIABILITY.
Package Dimensions
Notes:
1. All dimensions are in millimeters (inches).
2. Tolerance is
±0.25(0.01")
unless otherwise noted.
3. Lead spacing is measured where the lead emerge package.
4. Specifications are subject to change without notice.
SPEC NO: DSAD1881
APPROVED : J. Lu
REV NO: V.1
CHECKED : Allen Liu
DATE: APR/15/2003
DRAWN: F.Y.YUAN
PAGE: 1 OF 3
Selection Guide
P ar t N o .
Dic e
L en s Ty p e
Iv (m c d )
@ 10m A
Min .
W169XPGTL
PURE GREEN (GaP)
GREEN TRANSPARENT
3
Ty p .
8
V i ew i n g
An g l e
2
θ 1 / 2
30
°
Note:
1.
θ1/2
is the angle from optical centerline where the luminous intensity is 1/2 the optical centerline value.
Electrical / Optical Characteristics at T
A
=25°C
°
Sy m b o l
λ
peak
λ
D
∆λ
1/2
C
V
F
I
R
P ar am et er
Peak Wavelength
Dominate Wavelength
D ev i c e
Pure Green
Pure Green
Ty p .
555
555
30
45
2.25
2.5
10
Max .
Un its
nm
nm
nm
pF
V
uA
Tes t Co n d it io n s
I
F
= 2 0 m A
I
F
= 2 0 m A
I
F
= 2 0 m A
V
F
= 0 V;f= 1 M Hz
I
F
= 2 0 m A
V
R
= 5V
Spectral Line Half-width Pure Green
Capacitance
Forward Voltage
Reverse Current
Pure Green
Pure Green
Pure Green
Absolute Maximum Ratings at T
A
=25°C
°
P ar am et er
Power dissipation
DC Forward Current
Peak Forward Current [1]
Reverse Voltage
Operating/Storage Temperature
Lead Solder Temperature [2]
Notes:
1. 1/10 Duty Cycle, 0.1ms Pulse Width.
2. 2mm below package base.
Pu r e Gr een
105
25
135
5
-40
°
C To +85
°C
260
°
C For 5 Seconds
Un its
mW
mA
mA
V
SPEC NO: DSAD1881
APPROVED : J. Lu
REV NO: V.1
CHECKED : Allen Liu
DATE: APR/15/2003
DRAWN: F.Y.YUAN
PAGE: 2 OF 3
