SERIES
SMV
MICRO-D METAL SHELL
SURFACE MOUNT VERTICAL
NO. OF
CONTACTS
9
15
21
25
31
37
MAX
.785
.935
1.085
1.185
1.335
1.485
A
B
.565
.715
.865
.965
1.115
1.265
C
.65
.80
.95
1.05
1.20
1.35
±.010
.325
.400
.475
.525
.600
.675
D
A
B
.308 MAX
.095 DIA
REF
PIN #1
PLUG
.182
SOCKET #1
RECEPTACLE
.020 TYP
.195 .003
RECEPT
.183 .003
PLUG
OPTIONAL
JACKPOST
.300
MAX
.225
TYP
.025 DIA
.001
.416
MAX .516
MAX
A
.236 .020
.050
LEADS TO BE COPLANAR
TO DATUM -A- WITHIN .005
.060 (FLAT) TYP
.040
SMV
X XXX
X X 0
SURFACE MOUNT METAL SHELL
VERTICAL MICRO-D
GENDER
1 = RECEPTACLE, SOCKET CONTACTS
2 = PLUG, PIN CONTACTS
.244
.562
.528
NUMBER OF CONTACTS
009 025
015 031
021 037
SHELL HARDWARE
0 = NO HARDWARE
1 = JACKPOST
SHELL FINISH
A = CADMIUM
B = NICKEL
TBD
4. ADDITIONAL INFORMATION:
C
.125
.125
.025 TYP
.050 TYP
MATERIALS AND FINISHES ARE IAW MIL-DTL-83513 WHERE APPLICABLE
FOR DETAILS SEE MIL SPEC OR WWW.CRISTEK.COM
1. MATERIALS:
SHELL - ALUMINUM ALLOY
INSULATOR - GLASS FILLED THERMOPLASTIC
PIN/SOCKET CONTACT - COPPER ALLOY
INTERFACIAL SEAL - FLUOROSILICONE BLEND
LOCATING PIN - STAINLESS STEEL
SHELL - ELECTROLESS NICKEL OR CADMIUM
OVER ELECTROLESS NICKEL
PIN/SOCKET CONTACT - GOLD OVER NICKEL
LEADS - HOT SOLDER DIPPED
LOCATING PIN - PASSIVATED
3. SPECIFICATIONS:
2. FINISH:
DESIGN AND PERFORMANCE IN GENERAL
CURRENT RATING ------------------ 3 AMPS MAX
ACCORDANCE WITH M83513 WHERE APPLICABLE.
TEMPERATURE RATING ---------- -55° C TO +125° C
INSULATION RESISTANCE -------- 5000 MEGOHMS MIN
DWV AT SEA LEVEL ---------------- 600 VAC
DWV AT 70,000 FT ALTITUDE --- 150 VAC
CONTACT RESISTANCE ------------ 8 MILLIOHMS MAX AT 2.5 AMPS
LOW LEVEL CONTACT ------------- 10 MILLIOHMS MAX
RESISTANCE
CONTACT RETENTION ------------- 5 lb MINIMUM AXIAL LOAD
ENGAGEMENT FORCE ------------- 6 oz MAX
SEPARATION FORCE --------------- 0.5 oz MIN
TOLERANCE: .XXX ±.005
.XX ±.01
ANGLE ±1°
TITLE
MICRO-D METAL SHELL
SURFACE MOUNT VERTICAL
DWG. NO.
SHT
REV
1
OF
3
SMV
K
CRISTEK.COM
888.265.9162
