HALF SIZE HCMOS TRI-STATE ENABLE/DISABLE OSCILLATOR
H5C-2E
The H5C-2E Clock Oscillator employs a tri-state function for
control of the output. Applying a logic '1' to pin 1 enables the
oscillator output and a logic '0' to pin 1 disables the output to a
high impedance state called High Z state. This allows for testing
by automated test equipment by having the part appear as removed
from the circuit. The package is all metal with pin 4 as case ground
which provides shielding to help minimize EMI radiation.
FEATURES
8 Pin Dip
50pF HCMOS Load
10TTL Loads
Low Cost
Tri-state Enable/Disable
MODEL NUMBER SELECTION
Frequency Stability
Model Number
±100PPM
±50PPM
±25PPM
H5C-2E
H6C-2E
H7C-2E
OSCILLATORS
Note: -40ºC ~ 85ºC "R" version available
(ex: H5C-2ER)
• ELECTRICAL CHARACTERISTICS (V
DD
= 5.0V, C
L
= 50pF)
PARAMETERS
Frequency Range (Fo)
Frequency Stability
Temperature Range
Operating
(T
OPR
)
Storage
(T
STG
)
Supply Voltage
(V
DD
)
Input Current
(I
DD
)
Output Symmetry
Rise Time
Fall Time
Output Voltage
Output Current
Output Load
(T
R
)
(T
F
)
(V
OL
)
(V
OH
)
(I
OL
)
(I
OH
)
FREQUENCY RANGE
1.000
1.000
1.000
1.000
40.000+
1.000
50.000+
1.000
1.000
1.000
1.000
1.000
1.000
1.000
~ 70.000
~ 70.000
~
~
~
~
~
~
~
~
70.000
40.000
70.000
50.000
70.000
70.000
70.000
70.000
CONDITIONS
All Conditions *
MIN
1.000
-100
0
-55
+4.5
2.5V
0.5V ~ 4.5V
4.5V ~ 0.5V
I
OL
= 16 mA
I
OH
= -16 mA
V
OL
= 0.5 V
V
OH
= 4.5 V
TTL
HCMOS
45
40
MAX
70.000
+100
+70
+125
+5.5
40
60
55
60
10
10
0.5
16
-16
10
50
10
100
UNITS
MHz
PPM
ºC
V
mA
%
nS
V
mA
TTL
pF
mS
nS
OUTPUT (Pin 5)
ACTIVE
ACTIVE
High Z
~ 70.000
~ 70.000
~ 70.000
~ 70.000
4.5
Start-up Time
(T
S
)
Output Enable/Disable Time
* Inclusive of 25ºC tolerance, operating temperature range, input voltage change, load change, aging, shock, and vibration.
*** An internal pullup resistor from pin 1 to pin 8 allows active output if pin 1 is left open.
See page 44 for mechanical specifications, test circuits, and output waveform.
All specifications subject to change without notice. Rev. 03/02/00
ENABLE / DISABLE FUNCTION**
INH (Pin 1)
OPEN ***
'1' Level V
IH
³
2.2 V
'0' Level V
IL
£
0.8 V
All dimensions are in millimeters.
FOXElectronics
5570 Enterprise Parkway
Fort Myers, Florida 33905
941-693-0099
FAX 941-693-1554
http://www.foxonline.com
© 2000 FOX ELECTRONICS
