F-209-1
MW–16–03–G–D–235–075–P
MW–16–03–G–D–185–125
MW–25–03–G–D–210–100
MW–10–03–G–D–150–160
Surface
SMT
Mount
(1,00
mm
) .0394" STACKER
Mates with:
CLM, MLE
MW
SERIES
SPECIFICATIONS
For complete specifications and
recommended PCB layouts
see www.samtec.com?MW
Insulator Material:
Top: Black LCP
Bottom: Natural LCP
Terminal Material:
Phosphor Bronze
Current Rating:
1.5A @ 80°C ambient
Operating Temp Range:
-55°C to +125°C
Plating:
Sn or Au over
50µ"(1,27µm) Ni
RoHS Compliant:
Yes
APPLICATIONS
EXAMPLES
Lead Style
BOARD
SPACE
MW
CLM
MW
BOARD
SPACE
CLM
-163-065
-233-065
– 02
(6,35) .250
(8,13) .320
(2,21)
.087
Available with
optional end
shrouds and
pick-and-place
pads
APPLICATION
SPECIFIC OPTION
Alignment pins,
end shrouds and
end shrouds with
guide posts available.
Call Samtec.
Processing:
Max Processing Temp:
230°C for 60 seconds, or
260°C for 20 seconds 3x
Lead-Free Solderable:
Yes
SMT Lead Coplanarity:
(0,10mm) .004" max (02-30)
(0,15mm) .006" max (31-50)
(1,00mm) .03937"
micro pitch
Surface
Mount
MW
NO. PINS
PER ROW
03
PLATING
OPTION
D
STACKER
HEIGHT
POST
HEIGHT
OPTION
–“XXX”
02 thru 50
–G
= 10µ" (0,25µm) Gold
= Stacker
Height
(in inches)
(2,41) .095
to
(6,22) .245
No. of positions
x (1,00) .03937
–“XXX”
= Post
Height
(in inches)
(1,65) .065
minimum
Example:
–065
= (1,65)
.065"
–P
= Pick &
Place Pad
(7 positions
minimum)
–TR
= Tape &
Reel
02
100
B o a rd
S t a ck i n g
01
SO C K E T
P R O FI LE
P O ST
BOARD
SP A C E
O V ER A LL
P IN
(O A L)
ST A C K ER
H EI G H T
Example:
–245
= (6,22mm)
.245"
(3,18) (5,21)
.125 .205
(1,00) .0394
(1,00)
.03937
99
(0,30) .012 SQ TYP
POST HEIGHT
(1,65) .065
MIN
(3,18)
.125
STACKER
HEIGHT
(2,41)
.095
to
(6,22)
.245
(5,08)
.200
x
(3,18)
.125
(7,87)
.310
MAX
OVERALL
LENGTH
(1,49)
.059
(1,80)
.071
–P OPTION
Note:
This Series is
non-standard, non-returnable.
WWW.SAMTEC.COM
