IDC Systems
Female Sockets
FEMALE SOCKET
CONNECTORS
.100" x .100" CENTERS
LR92984
E60980
P
HYSICAL
P
ROPERTIES
I
NSULATION
M
ATERIAL
:
Glass reinforced
thermoplastic rated UL 94V-0
C
OLOR
:
Blue
C
ONTACTS
:
Beryllium copper 30µ inches minimum
gold over 50µ inches nickel in contact zone;
tin/lead over nickel in termination area
“Unique Tulip
©
Design”
E
LECTRICAL
P
ROPERTIES
C
URRENT
R
ATING
:
1 Amp
I
NSULATION
R
ESISTANCE
:
>1 x 10
9
0hms @
500VDC
D
IELECTRIC
S
TRENGTH
:
> 500 VRMS at sea level
E
NVIRONMENTAL
P
ROPERTIES
T
EMPERATURE
R
ATING
:
-55˚C TO 125°C
A
PPLICATION
T
OOLING
779-
Ordering Information
SOCKET
CONN.
609-0600M
609-1000M
609-1400M
609-1600M
609-2000M
609-2400M
609-2600M
609-3400M
609-3600M
609-4000M
609-4400M
609-5000M
609-5600M
609-6000M
609-6400M
SOCKET
CONN. W/
STRAIN RELIEF
609-0601M
609-1001M
609-1401M
609-1601M
609-2001M
609-2401M
609-2601M
609-3401M
609-3601M
609-4001M
609-4401M
609-5001M
609-5601M
609-6001M
609-6401M
CATALOG NUMBERS
POLARIZED
POLARIZED
SOCKET
SOCKET W/
CONN.
STRAIN RELIEF
609-0630
609-1030
609-1430
609-1630
609-2030
609-2430
609-2630
609-3430
609-3630
609-4030
609-4430
609-5030
609-5630
609-6030
609-6430
609-0641
609-1041
609-1441
609-1641
609-2041
609-2441
609-2641
609-3441
609-3641
609-4041
609-4441
609-5041
609-5641
609-6041
609-6441
DIMENSIONS IN MM (INCHES)
NO.
OF
POS.
6
10
14
16
20
24
26
34
36
40
44
50
56
60
64
A
12.09(.476
17.17(.676)
22.25(.876)
24.79(.976)
29.87(1.176)
34.95(1.376)
37.49(1.476)
47.65(1,876)
50.19(1.976)
55.27(2.176)
60.35(2.376)
67.97(2.676)
75.59(2.976)
80.67(3.176)
85.75(3.376)
B
5.08(.200)
10.16(.400)
15.24(.600)
17.78(.700)
22.86(.900)
27.94(1.100)
30.48(1.200)
40.64(1.600)
43.18(1.700)
48.26(1.900)
53.34(2.100)
60.95(2.400)
68.58(2.700)
73.66(2.900)
78.74(3.100)
C
12.19(.480)
17.27(.680)
22.35(.880)
24.89(.980)
29.97(1.180)
35.05(1.380)
37.59(1.480)
47.75(1.880)
50.29(1.980)
55.37(2.180)
60.45(2.380)
68.07(2.680)
75.69(2.980)
80.77(3.180)
86.05(3.380)
Thomas & Betts Electronics/OEM Division Tel: 901-252-5000 Fax: 901-252-1312
Dimensions shown are for reference only. Dimensions are in millimeters (inches).
