UBMINIATURE
S
UBMINIATURE
F
USES
No. 382 / TR5
®
60127-3/IV,
V,
IEC 60127-3/IV, 250 V, T
lead free
T ime-Current
Time Lag (T)
Specifications
Packaging
Materials
000: Tape/Ammopack (1000 pcs.)
041: Short Leads - Bulk (1000 pcs.)
Base/Cap:
Brown Thermoplastic
Polyamide PA 6.6, UL 94 V0
Round Pins: Copper, Sn plated
-40 ºC to +85 ºC (consider de-rating)
-40 ºC/+85 ºC/21 days
(IEC 60068-1,-2-1,-2-2,-2-78)
+10 ºC to +60 ºC
relative humidity
≤
75 % yearly average,
without dew, maximum value for 30 days-95 %
24 cycles at 15 min. each (EN 60068-6)
10 - 60 Hz at 0.75 mm amplitude
60 - 2000 Hz at 10 g acceleration
10N (IEC 60068-2-21)
Characteristic
Standard
IEC 60127-3/IV
VDE
SEMKO
cULus Recognized
METI-T-Mark
METI-PSE
CCC
Lead Free
100A breaking capacity
Reduced PCB space requirements
Direct solderable or plug-in versions
Internationally approved
Low internal resistance
Shocksafe casing
Vibration resistant
Halogen free
Approvals
Temperature
Operating Temperature
Climatic Category
Stock Conditions
Dimensions (mm)
∅
8,5
max. 8
Features
Vibration Resistance
0,5 min
L
∅
0,6
1 +0,1
5,08
WebLinks
Lead Pull Strength
Solderability
Further info see:
www.wickmanngroup.com
www.wickmanngroup.com/download/
fuseology.pdf
Holes in PCB
Further application info see fuseology:
260 ºC,
≤
3 s (Wave)
350 ºC,
≤
3 s (Soldering Iron)
260 ºC, 10 s (IEC 60068-2-20)
Soldering Heat Resistance
Marking
, 382, 250 V, T, Current Rating, Approvals
Long Leads (L=18.8mm)
Short Leads (L=4.3mm)
Unit Weight
0.82 g (approx.)
Time
Limits for Pre-arcing Time
Rated Current
1.00 A ... 6.30 A
1.5 x I
N
>1h
2.1 x I
N
< 2 min
2.75 x I
N
4 x I
N
10 x I
N
400 ms ... 10 s 150 ms ... 3 s 20 ms ... 150 ms
METI -T-
Mark
METI-PSE
SEMKO
cURus
VDE
1.00 A
1.25 A
1.60 A
2.00 A
2.50 A
3.15 A
4.00 A
5.00 A
6.30 A*
1100
1125
1160
1200
1250
1315
1400
1500
1630
250 V
250 V
250 V
250 V
250 V
250 V
250 V
250 V
250 V
100A / 250 V AC 1
50-60Hz
cos
ϕ
= 1.0
100
95
90
85
80
75
70
65
65
400
465
490
670
750
900
1200
1250
1400
3.0
4.5
9.0
12
22
32
58
90
105
•
•
•
•
•
•
•
G
G
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
1 Breaking capacity at UL: 50A at 250V
G Expert Report
* Conducting path min. 0.2mm
2
Order
Information
050114
Qty.
Qty.
Order-
Order-
Number
Series
382
Amp Code
Packaging
Specifications are subject
to change without notice
China
Tel: +86 21 6432 5146
E-mail: sales@wickmann.cn
WebSite
Europe
Tel: +49 2302 662-107
www.wickmanngroup.com E-mail: sales@wickmann.com
Americas
Tel: +1 404 699-7820
E-mail: service@wickmannusa.com
Asia
Tel: +852 26 14-1108
E-mail: sales@wickmann.com.hk
CCC
Permissible continuous operating current is
≤
100 % at ambient temperature of 23 ºC (73.4 ºF).
Rated
Amp
Voltage
Breaking
Voltage Drop Power Dissipation Melting Integral
Current
Code
Rating
Capacity
1.0 x I
N
1.5 x I
N
10 x I
N
max. (mV)
max. (mW)
min. (A
2
s)
Approvals
•
•
•
•
•
•
•
•
•
