5mm FLANGE BASED LED LAMP
BLFA054SYCK-6V-P
SUPER BRIGHT YELLOW
Features
BUILT-IN CURRENT LIMITING RESISTOR FOR DIRECT
APPLICATION OF DIFFERENT ACROSS CURRENT.
LONG LIFE.
LOW MAINTENANCE.
DIFFERENT COLOR AVAILABLE.
SOLID STATE, HIGH VIBRATION RESISTANT.
6V INTERNAL RESISTOR.
RoHS COMPLIANT.
Description
The Super Bright Yellow source color devices are
made with DH InGaAlP on GaAs substrate Light
Emitting Diode.
Package Dimensions
Notes:
1. All dimensions are in millimeters (inches).
2. Tolerance is
±0.25(0.01")
unless otherwise noted.
3. Specifications are subject to change without notice.
SPEC NO: DSAD0379
APPROVED: J. Lu
REV NO: V.2
CHECKED: Allen Liu
DATE:JAN/08/2005
DRAWN:Y.CHENG
PAGE: 1 OF 3
Selection Guide
Part No.
Dice
Lens Type
Iv (mcd)
V=6V
Min.
BLFA054SYCK-6V-P
SUPER BRIGHT YELLOW (InGaAIP) WATER CLEAR
36
Typ.
130
Viewing
Angle
2θ1/2
θ
110
°
Note:
1.
θ1/2
is the angle from optical centerline where the luminous intensity is 1/2 the optical centerline value.
Electrical / Optical Characteristics at T
A
=25°C
Symbol
λpeak
λD
∆λ1/2
I
F
I
R
Parameter
Peak Wavelength
Dominant Wavelength
Spectral Line Half-width
Forward Current
Reverse Current
Device
Super Bright Yellow
Super Bright Yellow
Super Bright Yellow
Super Bright Yellow
Super Bright Yellow
Typ.
590
590
20
20
10
Max.
Units
nm
nm
nm
mA
uA
Test Conditions
V
F
=6V
V
F
=6V
V
F
=6V
V
F
=6V
V
R
= 5V
Absolute Maximum Ratings at T
A
=25°C
Parameter
Power dissipation
Forward Voltage
Reverse Voltage
Operating Temperature
Storage Temperature
Super Bright Yellow
140
7
5
-40°C To +70°C
-40°C To +85°C
Units
mW
V
V
SPEC NO: DSAD0379
APPROVED: J. Lu
REV NO: V.2
CHECKED: Allen Liu
DATE:JAN/08/2005
DRAWN:Y.CHENG
PAGE: 2 OF 3
