ACT86SMX
Compact in size, the Surface Mount, plastic packaged
ACT86SMX
is ideal for high density packing and
automatic placement on circuit boards. The device has, as its core, a heat resisting cylinder type crystal
which makes full use of AT cut crystal characteristics. This device can be used in a variety of applications
such as Communications, Audio Visual, Measurement and Portable Equipments. The footprint is an industry
standard layout and is compatible with other popular plastic crystals in this package.
Specification
Parameter
Frequency Range
Frequency Tolerance @25°C
Temp Operating Range
Stability over Temp Range
Temp Storage Range
Equivalent Series Resistance
Shunt Capacitance
Load Capacitance
Drive Level
Insulation Resistance
Aging (First Year)
Symbol
fo
Δf/fo
Topr
Tc
Tstg
ESR
C0
Cl
DL max
IR
Fa
Frequency (MHz)
3.50
≤
fo ~ <4.00
4.00
≤
fo ~ <6.00
6.00
≤
fo ~ <10.00
10.00
≤
fo ~<36.00
30.00
≤
fo ~<36.00
36.00
≤
fo ~<70.00
Specification
3.5MHz ~ 32MHz
30MHz ~ 70MHz
±30ppm & 50ppm
-10°C ~ +60°C ( -40°C~+85°C available)
±50ppm ( ±30ppm option for 6.00MHz & over)
-55°C ~ +125°C
See table below
7pF max
10 ~ 32pF & SR
50 ~ 100μ W
500MΩ Min
±5ppm
ESR (Ω) max
200
150
100
50
100
80
Mode
Fundamental
Fundamental
Fundamental
Fundamental
3rd Overtone
3rd Overtone
Condition
Fundamental
3rd Overtone
Please specify
Please specify
Please specify
@25°C
Please specify
DC 100V±15V
@25°C ±3°C
Pad Surface Finish
95Sn/5Cu
Dimensions
Dimensions in mm
Recommended Reflow Profile
1.8
1.8
7.6
#3
4.6 max
1.8
1.7
1.8
12.5 max
#4
#1
#2
Suggested Footprint
9.4
3.7 max
1.0
0.8
0.8
TAPE AND REEL SPECIFICATIONS
(Standard Reel Size 1kpcs)
M
G
L
Device Orientation
REEL DIMENSIONS ( Units :mm )
TAPE DIMENSIONS ( Units :mm )
Please note that all parameters can not necessarily be specified in the same device
Customer to specify : Frequency, Frequency Tolerance, Temperature Stability, Operating Temperature Range, Load Capacitance
In line with our ongoing policy of product evolvement and improvement, the above specification may be subject to change without notice
ISO9001:2000 Registered
For quotations or further information please contact us at:
3 The Business Centre, Molly Millars Lane, Wokingham, Berkshire, RG41 2EY, UK
Issue:6 M4 C1E
Date:21-11-2006
http://www.actcrystals.com
K
J
H
I
ACT
