The ACTF480-9/479.5/TO39 is a two channel IF filter for DSB receivers with
constant group delay.
1.Package Dimension
(TO-39)
2.
Pin
1
2
3
4
Dimensions
A
B
C
D
E
Configuration
Input / Output
Output 2 / Input 2
Output 1 / Input 1
Ground
Data (Unit: mm)
9.35±0.10
5.08±0.10
3.40±0.10
3.00±0.20
4-Φ0.45±0.20
3.Equivalent LC Model
4.Performance
4-1.Maximum Ratings
Rating
AC Voltage Between Any Two Pins
DC Voltage Between Any Two Pins
Storage temperature range
Operable temperature range
V
PP
V
DC
T
stg
T
A
Value
5
Units
V
V
°C
°C
0
-40 to +85
-25 to +85
In keeping with our ongoing policy of product evolvement and improvement, the above specification is subject to change without notice.
ISO9001: 2000 Registered - Registration number 6830/2
For quotations or further information please contact us at:
3 The Business Centre, Molly Millars Lane, Wokingham, Berks, RG41 2EY, UK
Issue : 1 C1
Date : SEPT 04
http://www.actcrystals.com
Tel : +44 118 979 1238
Fax : +44 118 979 1283
Email: info@actcrystals.com
4-2.Electronic Characteristics
T
A
= 25
°C
Reference temperature:
Terminating source impedance:
Z
S
= 50
Ω
Terminating load impedance:
Z
L
= 50
Ω
0.25MHz
Group delay aperture:
Characteristics of Channel 1
Characteristic
Center Frequency
Insertion attenuation
479.50 MHz
(Reference level for the following data)
Pass bandwidth
Relative attenuation
466.00 MHz
493.00 MHz
430.00 ….455.00 MHz
504.00 … 530.00 MHz
α
rel
≤3dB
fc
α
B
3dB
α
rel
Min.
478.50
--
--
Typ.
479.50
22.0
27.0
Max.
480.50
24.5
--
Units
MHz
dB
MHz
Lower sidelobe
Upper sidelobe
--
--
34.0
34.0
40.0
Δα
Δ
τ
TC
f
--
--
--
3.2
3.5
39.0
39.0
45.0
0.6
10
-86
5.0
5.0
--
--
--
1.2
18
--
dB
dB
dB
dB
dB
dB
ns
ppm/K
Reflected wave signal suppression
0.135μs … 2.0μs after main pulse
Amplitude ripple (p-p)
Group delay ripple (p-p)
471.00 … 488.00 MHz
466.00 … 493.00 MHz
Temperature coefficient of frequency
In keeping with our ongoing policy of product evolvement and improvement, the above specification is subject to change without notice.
ISO9001: 2000 Registered - Registration number 6830/2
For quotations or further information please contact us at:
3 The Business Centre, Molly Millars Lane, Wokingham, Berks, RG41 2EY, UK
Issue : 1 C1
Date : SEPT 04
http://www.actcrystals.com
Tel : +44 118 979 1238
Fax : +44 118 979 1283
Email: info@actcrystals.com
Characteristics of Channel 2
Characteristic
Center Frequency
Insertion attenuation
479.50 MHz
(Reference level for the following data)
Pass bandwidth
Relative attenuation
461.50 MHz
497.50 MHz
430.00 ….449.00 MHz
510.00 … 530.00 MHz
α
rel
≤3dB
fc
α
B
3dB
α
rel
Min.
478.50
--
--
Typ.
479.50
25.0
36.0
Max.
480.50
26.5
--
Units
MHz
dB
MHz
Lower sidelobe
Upper sidelobe
--
--
34.0
30.0
40.0
Δα
Δ
τ
TC
f
--
--
--
3.5
2.3
39.0
36.0
45.0
0.6
12
-86
4.8
4.8
--
--
--
1.2
18
--
dB
dB
dB
dB
dB
dB
ns
ppm/K
Reflected wave signal suppression
0.13μs … 2.0μs after main pulse
Amplitude ripple (p-p)
Group delay ripple (p-p)
468.50 … 490.50 MHz
461.50 … 497.50 MHz
Temperature coefficient of frequency
i
CAUTION: Electrostatic Sensitive Device. Observe precautions for handling!
1.
Unless noted otherwise, all measurements are made with the filter installed in the specified test fixture that is
connected to a 50Ω test system with VSWR≤1.2: 1. The test fixture L and C are adjusted for minimum insertion
loss at the filter centre frequency, f
C
. Note that insertion loss, bandwidth, and passband shape are dependent on
the impedance matching component values and quality.
Unless noted otherwise, specifications apply over the entire specified operating temperature range.
The specifications of this device are based on the test circuit shown above and subject to change or
obsolescence without notice.
All equipment designs utilizing this product must be approved by the appropriate government agency prior to
manufacture or sale.
Our liability is only assumed for the Surface Acoustic Wave (SAW) component(s) per se, not for
applications,processes and circuits implemented within components or assemblies.
2.
3.
4.
5.
