AZ9431
15 AMP
MINIATURE
PC BOARD RELAY
FEATURES
•
•
•
•
•
•
High performance
Low seated height
6 kV surge version available
Flux tight and sealed versions available
Class B insulation (130°C) standard, Class F (155
°
C) available
UL, CUR file E43203
CONTACTS
Arrangement
Ratings
Medium Duty
SPST N.O. (1 Form A)
SPDT (1 Form C)
Max. switched power: 240 W or 1200 VA
Max. switched current: 10 A
Max. switched voltage: 150* VDC or 300 VAC
Max. switched power: 360 W or 2500 VA
Max. switched current: 15 A
Max. switched voltage: 150* VDC or 300 VAC
A
A
A
A
A
at
at
at
at
at
120 VAC, General Use
24 VDC, General Use
250 VAC, General Use
120 VAC, General Use
24 VDC, General Use
GENERAL DATA
Life Expectancy
Mechanical
Electrical
Operate Time
Release Time
1 x 10
6
1 x 10
5
at 10 A 120 VAC res.
10 ms max.
5 ms max.
(with no coil suppression)
Heavy Duty
UL/CUR Ratings
Medium Duty
10
10
Heavy Duty
10
15
15
Dielectric Strength
3000 Vrms contact to coil (6 kV version)
(at sea level for 1 min.)
1500 Vrms contact to coil
1000 Vrms across contacts
Insulation Resistance
Dropout
Ambient Temperature
Operating
Storage
Vibration
100 megohms min. at 500 VDC,
50% RH
Greater than 10% of nominal coil voltage
At nominal coil voltage
-40°C(-40°F) to 100°C(212°F)
-40°C(-40°F) to 155°C(311°F)
0.062" DA at 10–55 Hz
10 g
P.B.T. polyester
Tinned copper alloy, P.C.
270°C (518°F)
5 seconds
80°C (176°F)
30 seconds
10 g
*
Note: If switching voltage is greater than 30 VDC, special
precautions must be taken. Please contact the factory.
Material
Resistance
Medium Duty: Silver cadmium oxide
Heavy Duty: Silver tin oxide
< 100 milliohms initially
(24 V, 1 A method)
Shock
Enclosure
COIL
Power
At Pickup Voltage
Max Continuous
Dissipation
Temperature Rise
(at nominal coil voltage)
Terminals
Max. Solder Temp.
203 mW
1.7 W at 20°C (68°F)
22°C (40°F)
Max. 130°C (266°F) Class B
Max. 155°C (311°F) Class F
Max. Solder Time
Max. Solvent Temp.
Max. Immersion Time
Weight
Temperature
NOTES
1.
2.
3.
4.
All values at 20°C (68°F).
Relay may pull in with less than “Must Operate” value.
Unsealed relays should not be dip cleaned.
Specifications subject to change without notice.
5/26/05W
AZ9431
RELAY ORDERING DATA
STANDARD RELAYS
COIL SPECIFICATIONS
Nominal
Coil
VDC
5
6
9
12
18
24
48
Max.
Continuous
VDC
10.9
13.0
19.5
26.0
39.1
52.1
104.3
Coil
Resistance
±10%
70
100
225
400
900
1,600
6,400
Must
Operate
VDC
3.8
4.5
6.8
9.0
13.5
18.0
36.0
ORDER NUMBER*
Medium Duty 10 Amp contact)
Unsealed
Sealed
AZ9431–1C–5D
AZ9431–1C–5DE
AZ9431–1C–6D
AZ9431–1C–9D
AZ9431–1C–12D
AZ9431-1C-18D
AZ9431–1C–24D
AZ9431–1C–48D
AZ9431–1C–6DE
AZ9431–1C–9DE
AZ9431–1C–12DE
AZ9431-1C-18DE
AZ9431–1C–24DE
AZ9431–1C–48DE
Heavy duty (15 Amp contact)
Unsealed
Sealed
AZ9431–1CH–5D AZ9431–1CH–5DE
AZ9431–1CH–6D
AZ9431–1CH–9D
AZ9431–1CH–6DE
AZ9431–1CH–9DE
AZ9431–1CH–12D AZ9431–1CH–12DE
AZ9431–1CH–18D AZ9431–1CH–18DE
AZ9431–1CH–24D AZ9431–1CH–24DE
AZ9431–1CH–48D AZ9431–1CH–48DE
*Substitute “1A” or “1AH” in place of “1C” or “1CH” to indicate 1 Form A. Add suffix “F” for Class F version. Add “H” to AZ9431 for 6 kV version.
MECHANICAL DATA
PC Board Layout
.762 Max
[19.25]
.612 Max
[15.25]
.134
[3.40]
.059
[1.49]
.236[6.0]
.602 Max
[15.29]
.185
[4.70]
.012
[.30]
.472
12.00
.480
[12.20]
.559
[14.20]
VIEWED TOWARD TERMINALS
.014
[.36]
Wiring Diagram
4 .016
2
3
2
3
.039
[1.0]
4 x .032
[0.8]
1
1
5
4
5
FORM
C
FORM
A
VIEWED TOWARD TERMINALS
Dimensions in inches with metric equivalents in parentheses. Tolerance: ± .010"
5/26/05W
