Z86E33/733/E34
Z86E43/743/E44
CMOS Z8
®
OTP
Microcontrollers
Product Specification
PS022901-0508
Copyright ©2008 by Zilog
®
, Inc. All rights reserved.
www.zilog.com
Warning:
DO NOT USE IN LIFE SUPPORT
LIFE SUPPORT POLICY
ZILOG'S PRODUCTS ARE NOT AUTHORIZED FOR USE AS CRITICAL COMPONENTS IN LIFE
SUPPORT DEVICES OR SYSTEMS WITHOUT THE EXPRESS PRIOR WRITTEN APPROVAL OF
THE PRESIDENT AND GENERAL COUNSEL OF ZILOG CORPORATION.
As used herein
Life support devices or systems are devices which (a) are intended for surgical implant into the body, or (b)
support or sustain life and whose failure to perform when properly used in accordance with instructions for
use provided in the labeling can be reasonably expected to result in a significant injury to the user. A
critical component is any component in a life support device or system whose failure to perform can be
reasonably expected to cause the failure of the life support device or system or to affect its safety or
effectiveness.
Document Disclaimer
©2008 by Zilog, Inc. All rights reserved. Information in this publication concerning the devices,
applications, or technology described is intended to suggest possible uses and may be superseded. ZILOG,
INC. DOES NOT ASSUME LIABILITY FOR OR PROVIDE A REPRESENTATION OF ACCURACY
OF THE INFORMATION, DEVICES, OR TECHNOLOGY DESCRIBED IN THIS DOCUMENT.
Z I L O G A L S O D O E S N O T A S S U M E L I A B I L I T Y F O R I N T E L L E C T U A L P R O P E RT Y
INFRINGEMENT RELATED IN ANY MANNER TO USE OF INFORMATION, DEVICES, OR
TECHNOLOGY DESCRIBED HEREIN OR OTHERWISE. The information contained within this
document has been verified according to the general principles of electrical and mechanical engineering.
Z8, Z8 Encore!, Z8 Encore! XP, Z8 Encore! MC, Crimzon, eZ80, and ZNEO are trademarks or registered
trademarks of Zilog, Inc. All other product or service names are the property of their respective owners.
PS022901-0508
CMOS Z8
®
OTP Microcontrollers
Product Specification
iii
Revision History
Each instance in Revision History reflects a change to this document from its previous
revision. For more details, refer to the corresponding pages and appropriate links in the
table below.
Date
May 2008
Revision Level Description
01
Original issue.
Page No
All
PS022901-0508
Revision History
CMOS Z8
®
OTP Microcontrollers
Product Specification
iv
Table of Contents
Architectural Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Functional Block Diagram . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Pin Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Electrical Characteristics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Absolute Maximum Ratings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Standard Test Conditions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Capacitance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
DC Electrical Characteristics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Handshake Timing Diagrams . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Pin Functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
EPROM Programming Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Application Precaution . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Standard Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Functional Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Package Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Ordering Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
20
20
21
21
22
34
37
37
38
38
46
77
79
Customer Support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 80
PS022901-0508
Table of Contents
CMOS Z8
®
OTP Microcontrollers
Product Specification
1
Architectural Overview
Zilog’s Z86E33/733/E34, E43/743/E44 8-Bit One-Time Programmable (OTP) Microcon-
trollers are members of Zilog’s single-chip Z8
®
MCU family featuring enhanced wake-up
circuitry, programmable Watchdog Timers, Low Noise EMI options, and easy hardware/
software system expansion capability.
Four basic address spaces support a wide range of memory configurations. The designer
has access to three additional control registers that allow easy access to register mapped
peripheral and I/O circuits.
For applications demanding powerful I/O capabilities, the Z86E33/733/E34 have 24 pins,
and the Z86E43/743/E44 have 32 pins of dedicated input and output. These lines are
grouped into four ports, eight lines per port, and are configurable under software control to
provide timing, status signals, and parallel I/O with or without handshake, and address/
data bus for interfacing external memory.
Note:
All signals with an overline are active Low. For example, B/W, for
which WORD is active Low, and B/W, for which BYTE is active Low.
Power connections follow these conventional descriptions:
Connection
Power
Ground
Circuit
V
CC
GND
Device
V
DD
V
SS
Features
Table 1
lists the features of Z86E33/733/E34, E43/743/E44.
Table 1. Z86E33/733/E34, E43/743/E44 Features
ROM
(KB)
4
8
16
4
8
Device
Z86E33
Z86733
Z86E34
Z86E43
Z86743
RAM
1
(Bytes)
237
237
237
236
236
I/O
Lines
24
24
24
32
32
Speed
(MHz)
12
12
12
12
12
PS022901-0508
Architectural Overview
