XDSL SPLITTER FILTER MODULE
POTS Central Office Splitter for standard ADSL applications
Complies with option A of ETSI specification TS 101-952-1-1
Part of a standard series which has footprint compatibility
ADSL2+ compatible
Low profile version of B8049: 12.5 mm height
NL version: RoHS-6 compliant
Electrical Specifications @ 25°C
PARAMETER
POTS Impedance
POTS Insertion Loss
POTS Insertion Loss Distortion relative to 1 kHz
POTS Return Loss
POTS Group Delay
FREQUENCY
100Hz to 4kHz
1kHz
200Hz to 4kHz
300Hz to 2kHz
2kHz to 3.4kHz
3.4kHz to 4kHz
200Hz to 4kHz
100Hz to 4kHz
4kHz to 30kHz
30kHz to 1.1MHz
1.1MHz to 3.0MHz
3.0MHz to 5.0MHz
32kHz to 2.2MHz
270Ω + 750Ω / 150nF
-1.0dB MAX
-1.0dB MAX
-14dB MIN
-12dB MIN
-8dB MIN
200µs MAX
-46dB MIN
-25dB MIN
-45dB MIN
-30dB MIN
-20dB MIN
-55dB MIN
100mA MAX
40Ω MAX
1.0kΩ MIN
Longitudinal Balance
ADSL Insertion Loss
DC Current
Total DC Resistance
Line Side Impedance
40kHz to 2.2MHz
Mechanical
B8049E/ B8049ENL
1.929 MAX
49,00
B8049E / B8049ENL
(Date Code)
(Country of Origin)
SUGGESTED BOARD LAYOUT
1.760
44,70
.524
13,30
MAX
4 X Ø 1.25
.492 MAX
12,50
.394
10,00
Pin 1
Weight
. . . . . . . . . . . .11 grams
Tray
. . . . . . . . . . . . . . .35/tray
Dimensions:
Inches
mm
Unless otherwise specified,
all tolerances are ± .010
0,25
.030 ± .005
0,76 ± 0,13
1.760 ± .010
44,70 ± 0,25
1
2
4
3
.138 ± .020
3,50 ± 0,50
Schematic
2
3
ADSL
&
LINE
1
PHONE
4
Pulse North China
Room 1503
XinYin Building
No. 888 YiShan Rd.
Shanghai 200233
China
Tel: 86 21 54643211/2
Fax: 86 21 54643210
.394 ± .008
10,00 ± 0,20
For More Information:
Pulse Worldwide
Headquarters
12220 World Trade Dr.
San Diego, CA 92128
U.S.A.
www.pulseeng.com
Tel: 858 674 8100
Fax: 858 674 8262
Pulse
Europe
Einsteinstrasse 1
D-71083 Herrenberg
Germany
Pulse China Headquarters
B402, Shenzhen
Tech-Innovation International
Tenth Kejinan Rd.
High-Tech Industrial Park
Nanshan District, Shenzhen
China
Tel: 86 755 33966678
Fax: 86 755 33966700
Pulse South Asia
150 Kampong Ampat
#07-01/02
KA Centre
Singapore 368324
Pulse North Asia
No. 26
Kao Ching Rd.
Yang Mei Chen
Taoyuan Hsien
Taiwan, R. O. C.
Tel: 886 3 4641811
Fax: 886 3 4641911
Tel: 49 7032 7806 0
Fax: 49 7032 7806 12
Tel: 65 6287 8998
Fax: 65 6280 0080
Performance warranty of products offered on this data sheet is limited to the parameters specified. Data is subject to change without notice. Other brand and product
names mentioned herein may be trademarks or registered trademarks of their respective owners. © Copyright, 2007. Pulse Engineering, Inc. All rights reserved.
www.pulseeng.com
B882.E (8/07)
